Side 1/4

QUICK START

OPPERATION GUIDE

HR72X

CD/MP3/USB/SD/

MMC CARD Player

With XLR Outputs

Rolls Corporation

Salt Lake City, UT

09/15

www.rolls.com

SPECIFICATIONS:

INPUTS: CD/SD CARD/MMC CARD/USB

OUTPUTS: 2 - RCA

2 - XLR balanced outputs

POWER: ROLLS PSU115/PS15 - 15V DC 1000mA

JACK SIZE: 5.5mm X 2.1mm DC TIP NEG.

OUTPUT LEVEL: -10dbv NOMINAL

SIZE: 6.75" X 1.7" X 8" (W-H-D)

SOFT TACT BUTTONS: Power, SD/USB,Shu. Enter, Repeat, Mute,

Stop/Eject, Folder, Play/Pause, Reverse, Forward, Prog.

LINE OUT VOLUME CONTROL

ACCEPTS 12 CM AND 8 CM DISCS LIKE (CD-R )

MV-CD3 : ACCEPTS 12 cm AND 8 cm DISCS

Weight: 2.5 lbs. (1.3 kg)

INTRODUCTION

Thank you for your purchase of the Rolls HR72X CD/MP3 Player. The HR72X

is a 1/2 rack space CD/MP3 disc player. Intended mainly for installation applica-

tions, the HR72X plays standard audio CDs as well as CDs formatted with MP3

les. The single rack space height makes it convenient to install in almost any

professional audio rack.

FEATURES:

• Plays standard CDs as well as discs with MP3 les

•Plays les from SD cards

•Plays USB ash disk

• XLR Balanced line lever left and right outputs

• RCA Output

• Track programming with optional remote

• Repeat All, 1, and Shufe play

• Output Level control

INSPECTION

1. Unpack and Inspect the HR72X package

Your HR72X was carefully packed at the factory in a protective carton. None-

theless, be sure to examine the unit and the carton for any signs of damage

that may have occurred during shipping. If obvious physical damage is noticed,

contact the carrier immediately to make a damage claim. We suggest saving

the shipping carton and packing materials for safely transporting the unit in the

future.

2. For complete Warranty information and registration, please visit our web site;

www.rolls.com. Click on the REGISTER YOUR WARRANTY HERE line. Or, com-

plete the Warranty Registration Card and return it to the factory.

SPECIFICATIONS:

SOFT TACT BUTTONS: Power, SD/USB,Shu. Enter, Repeat, Mute, Stop/Eject,

Folder, Play/Pause, Reverse, Forward, Prog.

ACCEPTS 12 CM AND 8 CM DISCS LIKE (CD-R )

MV-CD3 : ACCEPTS 12 cm AND 8 cm DISCS

Connectors: Stereo XLR balanced, and stereo RCA Outputs

Dimensions: 6.75" X 1.7" X 8" (W-H-D)

Weight: 2.5 lbs. (1.3 kg)

ROLLS PSU115/PS15 switching power supply included

- Repeat / Shufe

-Normal opperation of the HR72X will play through all folders (MP3) and tracks,

then stop.

-To play the disc over and over, press the REP button on the remote once. The

display will show the REPEAT ALL in the display.

-To play one track continuously, press the REP button until the Track Play Status

reads REPEAT 1. If the REPEAT status is on alone (MP3 mode) the current

folder will repeat.

For Shufe (random on the optional remote) play, press the RAN button until the

Track Play Status reads SHUFFLE.

-If the Track Play Status displays none of the above, the disc will play through

one time and stop.

OPTIONAL ROLLS #172R REMOTE SOLD SEPARATELY

Some functions can only be accessed by

the optional remote ROLLS part #172R.

-The Custom Program option can only be

accessed by the optional remote.

To access the Custom Program feature insert

a disc and press the PROG button on the

remote. The display will show PROGRAM in

the top right corner of the display. Enter the rst

track number on the remote you wish to play.

If this is the only track you wish to play press

the PLAY button and the unit will play only that

track. If you are programing more than one

track use the blue arrow button on the remote

to program other tracks after selecting the track

number. The LCD Display will show you what

number you are programing. If you want the

HR72X to repeat the Custom Programed tracks

you must, after Programing the tracks and

pressing PLAY press the REP (Repeat) button

to REPEAT ALL.
