RA235

STEREO 35 WATT

POWER AMPLIFIER

Quick Start Guide

ROLLS CORPORATION

SALT LAKE CITY, UTAH

10/10

CHANNEL 2

INPUT

CHANNEL 1

INPUT

WARNI NG: DO NO T EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE

NO USER SERVICABLE PARTS INSIDE.

MODEL RA235

SERIAL NUMBER

235 -

OUTPUTS

CHANNEL TWO CHANNEL ONE

120VAC 50/60Hz 100VA

1.5A Fuse

RISQUE DE CHOC - NE PAS ENLEVER

INTRODUCTION

Thank you for your purchase of the ROLLS RA235 35 Watt Power Ampli er. The

RA235 is a virtually indestructible single rack space ampli er intended for musi-

cians and studio owners alike. The unit is ideal for home studio applications or

wherever a clean, e cient, medium wattage amp is required. Please read the

following manual carefully to achieve the best results from this product.

DESCRIPTION

FRONT PANEL

VOLUME 1 / VOLUME 2: This control adjusts the output level of the correspond-

ing channel.

PWR: LED indicating the unit’s power status.

CLIP: These LEDs light in the event of overload in the corresponding channel.

REAR PANEL

CHANNEL 2

INPUT

CHANNEL 1

INPUT

WARNI NG: DO NO T EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE

NO USER SERVICABLE PARTS INSIDE.

MODEL RA235

SERIAL NUMBER

235 -

OUTPUTS

CHANNEL TWO CHANNEL ONE

120VAC 50/60Hz 100VA

1.5A Fuse

RISQUE DE CHOC - NE PAS ENLEVER

120 VAC 50/60 HZ 15 VA: IEC Power Cord. Connect to a properly grounded

AC source. NOTE: REPLACE THE FUSE WITH ONLY THE PROPER RATED

FUSE. INSTALLING A FUSE OTHER THAN THE RECOMMENDED RATING

WILL DAMAGE THE UNIT.

Outputs: Spring loaded terminals to be connected to 8 Ohms speaker loads only.

MAIN INPUTS: 1/4” and RCA jacks to be connected to line level signals to be

ampli ed. Note: Do not directly connect the output of a phono player as those

devices require special equalization.

For MONO operation, plug one RCA connector between the two RCA jacks. Either

Channel One or Channel Two 1/4” inputs may also be used as the MONO input.

BURN WARNING!

THE FRONT PANEL OF THE RA235 IS THE HEAT DISTRIBUTION FOR THE

OUTPUT STAGES. IF THE UNIT IS OPERATED AT HIGH VOLUMES, IT MAY

GET HOT.

INSTALLATION

Mount the RA235 in a safe and sturdy rack. Connect the output of the signal

source to the selected input of the RA235, and connect the Outputs to your

speakers.

Plug the AC cord into a properly grounded AC outlet.

Send signal to the RA235 and adjust the VOLUME controls for a comfortable

listening level.

SPECIFICATIONS

Recommended Load: 8 Ohms minimum

Frequency Response: 5 Hz to 40 kHz

Equiv. Input Noise: 100 microVolt typical, A weighted

600 Ohm input

S/N Ratio: 114 dB @ 35 Watts

Gain: 34 dB

Input Impedance: 47 k Ohms

Size (W x H x D): 19” x 1.75” x 5” (48 x 4.5 x 12.7)

Weight: 5.5 lbs (2.5 kg)

SCHEMATIC
