DEW POINT SENSOR

Model: TPS10

Quick guide

www.saluscontrols.com

SALUS Controls is a member of Computime Group

In order to maintain a policy of continuous product development, SALUS Controls plc

reserves the right to change the specification, design and materials of the products listed

in this brochure without prior notice.

V01

III/2025

Installation

First secure the

connection cable with

plastic clamps

Tour pipe

cooling

Plastic flange

Note: For mounting, the sensor must be placed with the smooth side of the sensor on

the back, with the entire sensor surface, on the cooling media lap and secured with

the plastic clamps included in the package.

Fix the power cable first and then the sensor (see installation example in the adjacent

sketch).

Electrical connection

TPS10 is supplied with a high quality connection cable (LiYY) 2x0.14 mm with a

length of 10 m, which can be extended up to 20 m.

Compatibility with other Salus products

Introduction

The TPS10 is based on the conductivity measurement principle and is used to detect t h e risk of

condensation when conditions are favourable for dew point formation. By means of a special, highly

flexible, high-tech foil with special thermal properties an excellent response sensitivity is achieved.

The sensor is mounted on the lap pipe of the cooling circuit. As the temperature difference between

the cooling medium and the surrounding air increases even at low air humidity there is a risk of

condensation.

The TPS10 can be used in conjunction with our products such as the RM-16A power relay; (utilising

the COM - NO potential free input), the SR600 intelligent relay (S1 - S2 input) or the WLS600 flood

sensor. Together they form a sensitive measuring device that reacts to this condensation long before the

human eye can detect this moisture in droplet form.

Information on product safety and functionality

When mounting the sensor to a pipe, DO NOT pass the mounting clamps through the openings in the

sensor foil. The front of the sensor with the comb conductor pattern is required for moisture sensing

and must be exposed. It must not be covered by insulation or come into contact with other electrical

elements or other electrically conductive parts.

Dimensions

32 mm

66 mm

25 mm

SALUS Controls, Units 8-10,

Nor eld Business Park,thfi

Forge Way Parkgate,

Rotherham, S60 1SD

SALUS Controls GmbH,

Dieselstrasse 34,

63165 Mühlheim am Main,

Germany

SR600

WLS600 RM-16A

KL08RF/CB12RF
