Side 1/222

RD-6506

AUDIO/VIDEO RECEIVER

OPERATING INSTRUCTIONS

INSTRUCCIONES DE FUNCIONAMIENTO

RECEPTOR DE AUDIO/VIDEO

RECEPTEUR AUDIO/VIDEO

MODE D'EMPLOI

АУДИО/ВИДЕО ПРИЕМНИК

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ

AUDIO/VIDEO RECEIVER

BEDIENUNGSANLEITUNG

6505(G) cover_5lan_cover.qxp 2011-04-14 오전 9:43 페이지 1

ENGLISH

Introduction

: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

This symbol is intended to alert the user to the presence of

ninsulated "dangerous voltage" within the product's

enclosure that may be of sufficient magnitude to constitute

risk of electric shock to persons.

his symbol is intended to alert the user to the presence of

important operating and maintenance (servicing)

instructions in the literature accompanying the appliance.

Caution regarding installation

Note : For heat dispersal, do not install this unit in a confined space such as a bookcase or similar enclosure.

Be sure to leave a space around this unit equal to, or greater than, shown below.

Left, right and rear sides : 20 cm, top side : 40 cm

: TO REDUCE THE RISK OF ELECTRIC SHOCK,

O NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

CAUTION

WARNING

Do not block ventilation openings or stack other equipment on the top.

READ THIS BEFORE OPERATING YOUR UNIT

N / STANDBY

UTO / MANUAL

URROUND

TEREO

IDEO

UDIO

OUND

NPUT

AUDIO ASSIGNSPEAKER

N / OFF

TONE CH.LEVEL SETUP ENTER / MEMO BANDPRESETTUNE

HONES

UX 1 AUX 2

OWER

AUDIO / VIDEO RECEIVER R

505

N OFF

ETURN

AIN MENU

ASTER VOLUME

CAUTION

FOR YOUR SAFETY

Units shipped to Australia are designed for operation on 230 V AC only.

To ensure safe operation, the three-pin plug supplied must be inserted only into a standard three-pin power point

which is effectively earthed through the normal household wiring. Extension cords used with the equipment must

be three-core and be correctly wired to provide connection to earth.

Improper extension cords are a major cause of fatalities. The fact that the equipment operates satisfactorily

does not imply that the power point is earthed and that the installation is completely safe. For your safety, if

in any doubt about the effective earthing of the power point, consult a qualified electrician.

PAN-EUROPEAN UNIFIED VOLTAGE

All units are suitable for use on supplies 220-240 V AC.

EUROPE

AUSTRALIA

220 V

240 V

•

Leave a space around the unit for sufficient ventilation.

•

Avoid installation in extremely hot or cold locations, or in an area

that is exposed to direct sunlight or heating equipment.

•

Keep the unit free from moisture, water, and dust.

•

Do not let foreign objects in the unit.

•

The ventilation should not be impeded by covering the ventilation

openings with items, such as newspapers, table-cloths, curtains,

etc.

•

No naked flame sources, such as lighted candles, should be

placed on the unit.

•

Please be care the environmental aspects of battery disposal.

•

The unit shall not be exposed to dripping or splashing for use.

•

No objects filled with liquids, such as vases, shall be placed on

the unit.

• Do not let insecticides, benzene, and thinner come in contact

with the set

•

Never disassemble or modify the unit in any way.

■Notes on the AC power cord and the wall outlet.

•

The unit is not disconnected from the AC power source(mains)

as long as it is connected to the wall outlet, even if the unit has

been turned off.

•

To completely disconnect this product from the mains,

disconnect the plug from the wall socket outlet.

•

When setting up this product, make sure that the AC outlet you

are using is easily accessible.

•

Disconnect the plug from the wall outlet when not using the unit

for long periods of time.

Information for Users on Collection and Disposal of

Old Equipment and used Batteries

These symbols on the products, packaging, and/or

accompanying documents mean that used electrical

and electronic products and batteries should not be

mixed with general household waste. For proper

treatment, recovery and recycling of old products and

used batteries, please take them to applicable

collection points, in accordance with your national

legislation.

By disposing of these products and batteries correctly,

you will help to save valuable resources and prevent

any potential negative effects on human health and the

environment which could otherwise arise from

inappropriate waste handling.

For more information about collection and recycling of

old products and batteries, please contact your local

municipality, your waste diposal service or the point of

sale where you purchased the items.

[Information on Disposal in other Countries outside the

European Union]

These symbols are only valid in the European Union. If

you wish to discard these items, please contact your

local authorities or dealer and ask for the correct

method of diposal.

Note for the battery symbol (bottom two symbol examples):

The sign Pb below the symbol for batteries indicates

that this batteries contains lead.

RD-6506(G)_ENG_110330_RD-6506(G)_ENG 2011-04-14 오전 9:29 페이지 2

Produkt Specifikationer

Mærke:	Sherwood
Kategori:	Modtager
Model:	RD-6506
Bredde:	435 mm
Dybde:	359 mm
Højde:	143 mm
Vægt:	8600 g
Brugervejledning:	Ja
Produktfarve:	Sort
Wi-Fi:	Ingen
Lyddekodere:	Dolby Digital, Dolby Pro Logic II, DTS, DTS 96/24
Ethernet LAN:	Ingen
Strømforbrug (typisk):	200 W
Sammensat videoindgang:	2
Fjernbetjening inkluderet:	Ingen
Frekvensområde:	20000 - 50000 Hz
Lyd-output kanaler:	5.1 kanaler
Understøttede radiobånd:	AM, FM
RDS Tuner inkluderet:	Ja
Sammensat videoudgang:	1
Signal/støjforhold:	95 dB
FM båndbredde:	87.5 - 108 MHz
Kampatibilitet med Apple-docking:	Ikke understøttet
HSMI-indgang:	3
Antal HDMI-udgange:	1
Digital lyd koaksial indgang:	2
AM båndbredde:	522 - 1611 kHz
Digital akustisk og optisk indgang:	1
Indgangsimpedans:	47000 ohm (Ω)
Udgangseffekt pr. kanal (20-20KHz @8 Ohm):	- W
Optisk drev inkluderet:	Ingen
Udgangseffekt pr. kanal (1KHz @6 Ohm):	100 W
Indgangsfølsomhed:	250 mV
