Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: January 12, 2022 10:19 AM

Product Diagram (D86A2-4-PORT-8K-KVM)

Front View

Rear View

4-Port USB 3.2 Gen 1 KVM Switch - DisplayPort - 8K 60Hz

Port Function

Port Selection LED

Indicators

• Solid Green: connected (power on)PC 1-4

• Solid Red: Selected (power on) PC

2Power LED • Solid Green: is powered onKVM Switch

Console USB HID Port

(Front)

• Connect a USB Human Interface Devices (HIDs)

(e.g. Keyboard, Mouse, Trackpad, Number

Keypad, or Drawing Tablet)

• Front (x1) and Rear (x3)

4Console USB Hub Port

• Connect a SuperSpeed USB 5Gbps (USB 3.2

Gen 1) Peripheral Device

5Port Selection Buttons • Press and release to select PCs 1-4

Console DisplayPort

Output Port

• Connect to a on a DisplayPort Input Display

7PC DisplayPort Input Ports • Connect to a onDisplayPort Output PCs 1-4

8Power Input Port

• Connect the to power Universal Power Adapter

the KVM Switch

9Console Audio Port

• Connect an (e.g. Speakers or Audio Device

Headset)

10 PC USB Ports

• Connect to a SuperSpeed USB 5Gbps (USB 3.2

Gen 1) Port PCs 1-4 on

11 PC Audio Ports

• Connect to an (for Speaker or Audio Port

Microphone) on PCs 1-4

Product Information

For the latest requirements and to view detailed instructions on all product functionality

in a full user manual, please visit:

www.StarTech.com/D86A2-4-PORT-8K-KVM

11 10

Regulatory Compliance

FCC - Part 15

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could

void the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two

conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique

subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

Warranty Information

This product is backed by a two-year warranty.

For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss

of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the

product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the

limitations or exclusions contained in this statement may not apply to you.

Safety Measures

If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

Se il prodotto p2-ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com

Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT Hoofddorp

The Netherlands

3. (Optional) After connecting the , there are two remainingUSB Mouse/Keyboard Console

USB HID Ports KVM Switch, located on the front and/or rear of the , for connecting up to two

additional .USB HIDs

4. Connect an to the located on the rear of the .Audio Device Console Audio Port, KVM Switch

5. (Optional) Connect up to two SuperSpeed USB 5Gbps (USB 3.2 Gen 1) Peripheral Devices

to the located on the front and rear of the .Console USB Hub Ports, KVM Switch

Connect the PCs

1. Connect a (sold separately) to the , located on , and DisplayPort Cable DisplayPort Port PC 1

to the , located on the rear of the .PC 1 DisplayPort Input Port KVM Switch

2. Connect a SuperSpeed USB 5Gbps (USB 3.2 Gen 1) Cable (Type-A Male to Type-B Male)

(sold separately) to a , located on , and to the , located on the USB-A Port PC 1 PC 1 USB Port

rear of the . KVM Switch

Note: SuperSpeed USB 5Gbps Cable A (or better) is recommended for optimal

performance.

3. Connect a (sold separately) to the , located on , and to 3.5 mm Audio Cable Audio Port PC1

the corresponding , located on the rear of the .PC1 Audio Port KVM Switch

4. Repeat steps 1 to 3 for .PCs 2-4

Operation

Power-On Sequence

1. Connect the from a to the on the Universal Power Adapter Wall Outlet Power Input Port

KVM Switch.

2. Power on all . Peripherals

3. Select by pressing and releasing the corresponding and power PC1 Port Selection Button

on the corresponding . Computer

Note: Computer PC 1 Port Ensure that the connected to the has fully booted to the

operating system before proceeding.

4. Repeat step 3 to connect .PCs 2-4

Requirements

Source PCs

• 4 x Computers

• DisplayPort enabled

• PCs 1-4

• 4 x DisplayPort Cables

• 4 x SuperSpeed USB 5Gbps (USB 3.2 Gen 1) Cables (Type-A Male to Type-B Male)

• 4 x (Optional) 3.5mm Audio Cables (Male to Male)

Console

• 1 x DisplayPort Display

• 1 x DisplayPort Cable

• 1 x USB Mouse

• 1 x USB Keyboard

• 1 x (Optional) Audio Device (e.g. Headphones)

• 1 x (Optional) USB HID Devices

• 1 x (Optional) SuperSpeed USB 5Gbps (USB 3.2 Gen 1) Peripheral Devices

Package Contents

• 1 x KVM Switch

• 1 x Quick-Start Guide

• 1 x Universal Power Adapter (NA/JP, EU, UK, NZ)

• 4 x Rubber Feet

Installation

Connect the Console

Note: Computers, Displays PeripheralsPower o all , and before completing the following

installation steps.

1. Connect a to the , located on the rear DisplayPort Display Console DisplayPort Output Port

of the using a (sold separately). KVM Switch, DisplayPort Cable

2. Connect a and a to the , located on the USB Mouse USB Keyboard Console USB HID Ports

front and rear of the .KVM Switch

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Skifte
Model:	D86A2-4-PORT-8K-KVM
Bredde:	130 mm
Dybde:	220 mm
Højde:	44 mm
Vægt:	1000 g
Produktfarve:	Sort
Indbygget skærm:	Ingen
Pakkevægt:	1600 g
Pakkedybde:	212 mm
Pakkebredde:	409 mm
Pakkehøjde:	87 mm
HD-type:	8K Ultra HD
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 85 %
HDCP:	Ja
Udgange til hovedtelefoner:	4
Strømforbrug (typisk):	36 W
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	7680 x 4320 pixel
Husmateriale:	Stål
Hurtig installationsvejledning:	Ja
High Dynamic Range (HDR) understøttet:	Ja
Strømkilde:	DC
DC-in-stik:	Ja
LED-indikatorer:	Ja
Udgangsspænding:	12 V
Udgangsstrøm:	3 A
Bæredygtighedscertifikater:	CE, RoHS, Trade Agreements Act (TAA)
Hovedkassen højde (udvendigt):	245 mm
Hovedkassens længde (udvendigt):	427 mm
Hovedkassens bredde (udvendigt):	545 mm
Indgangsstrøm:	1 A
DisplayPort-version:	1.4
Antal DisplayPorts:	4
Produkter pr. hovedkasse (udvendigt):	60 stk
Overholdelse af bæredygtighed:	Ja
Gennemsnitstid mellem fejl (MTBF):	130000 t
Strømstiktype:	Type M
Stativ-montering:	Ingen
HDCP-version:	1.4/2.2
Antal kontrollerede computere:	4
Tastatur porttype:	USB
Mus porttype:	USB
Video porttype:	DisplayPort
Lydforbindelse:	Ja
Genvejstaster:	Ja
Konsol porte:	3.5mm headphone, DisplayPort, USB A
Trykknap:	Ja
Kompatible strømplug typer:	EU, JP, UK, US
Antal USB 2.0 type-A hub porte:	4
Gummifødder:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub porte:	2
Dataoverførselshastighed (maks.):	5000 Gbit/sek.
Antal USB 3.2 Gen 1 (3.1 Gen 1) Type-B porte:	4
Chipsæt:	GL-3523
Skanningsinterval:	3, 8,15, 30 sek./side
Daisy kæde:	Ingen
IP kontrol:	Ingen
Antal konsol displayporte:	1
