Side 1/2

Hotkey Command Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Hotkey Command Revision: August 14, 2024

4-Port USB Keyboard and Mouse Switch with Mouse Roaming

Product IDs

P4A20132-KM-SWITCH

Product Information

For the latest software, manuals, product information, technical specications, and

declarations of conformance, please visit:

www.StarTech.com/P4A20132-KM-SWITCH

Hotkey Commands

Hotkey commands are keystroke sequences that initiate computer/device functions

and can be used to initiate KVM Switch functions. A hotkey command sequence must

be initiated by the HK_LCode (HotKey Leading Code), followed by 1-2 additional

keystrokes. Successful hotkey command inputs result in a high-pitch beep. Unsuccessful

hotkey command inputs result in a low-pitched beep.

Notes:

- All keystroke combinations must be entered in rapid succession.

- Press and release the indicated keys, unless otherwise specied.

- Numbers entered during the hotkey sequence cannot be entered using a number pad

HK_LCode

Option 1

• Scr Lck + Scr Lck

Option 2.1

• Left Ctrl + Left Ctrl

Option 2.2

To change from Left Ctrl to Right Ctrl:

• Left Ctrl + Left Ctrl + Alt (Hold) + Right Ctrl + Release Alt

To change back to Left Ctrl:

• Right Ctrl + Right Ctrl + Alt (Hold) + Left Ctrl + Release Alt

Option 3

• Left Shift (Hold) + Num Lck + Num Lck + Release Left Shift

Hotkey Command Function

HK_LCode 1 ~ 4 + • Select PC 1 ~ 4

HK_LCode 0 + • Return to the last selected PC Port

HK_LCode + F5

• Enable/Disable the binding of PC and Audio Switching.

• Bound by default forcing PC and Audio to switch

together

• Unbound = PC Audio stops following the selected PC

when switching (1 beep)

• Bound = PC Audio matches the selected PC (2 beeps)

HK_LCode + A • Force the Audio selection to the current PC Port

HK_LCode + Alt (Hold)

+ A + 0

• Disable the USB Audio Output and Microphone ports

HK_LCode + Alt (Hold)

+ A + 1

• Enable the USB Microphone Port only

HK_LCode + Alt (Hold)

+ A + 2

• Enable both USB Audio Output and Microphone ports

HK_LCode + Alt (Hold)

+ R

• Enables (1 beep)

or Disables (2

beeps) Borderless

Circulation

• Disabled by

default

HK_LCode + Alt (Hold)

+ Q + 9

• Enables Mouse

Roaming and

resumes previous

layout selection

Mouse Roaming

Mouse Roaming is the ability to use a single keyboard and mouse to control multiple

computers or devices. It enables seamless movement of the mouse cursor from one

computer’s screen to another without needing to physically switch a KM Switch or mouse

between computers.

Hotkey Command Function

HK_LCode Alt (Hold) +

+ Q + 0

• Disable Mouse

Roaming (1 beep)

HK_LCode Alt (Hold) +

+ Q + 1

• Enables Mouse

Roaming in 4 x 1

Mode

HK_LCode Alt (Hold) +

+ Q + 2

• Enables Mouse

Roaming in 2 x 2

Mode

HK_LCode Alt (Hold) +

+ Q + 3

• Enables Mouse

Roaming in 1 + 3

Mode

HK_LCode Alt (Hold) +

+ Q + 4

• Enables Mouse

Roaming in 1 x 4

Mode

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Skifte
Model:	P4A20132-KM-SWITCH
Bredde:	130 mm
Dybde:	220 mm
Højde:	34 mm
Vægt:	800 g
Produktfarve:	Sort
Indbygget skærm:	Ingen
Pakkevægt:	180 g
Pakkedybde:	245 mm
Pakkebredde:	295 mm
Pakkehøjde:	63 mm
HD-type:	Ikke understøttet
Opbevaringstemperatur (T-T):	-10 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 80 %
Udgange til hovedtelefoner:	6
Skærmvisning (OSD):	Ingen
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	- pixel
Hurtig installationsvejledning:	Ja
DC-in-stik:	Ja
LED-indikatorer:	Ja
Udgangsspænding:	12 V
Udgangsstrøm:	5 A
Bæredygtighedscertifikater:	RoHS, Trade Agreements Act (TAA)
Hovedkassen højde (udvendigt):	302 mm
Hovedkassens længde (udvendigt):	510 mm
Hovedkassens bredde (udvendigt):	613 mm
Indgangsstrøm:	0.6 A
Ekstern strømadapter:	Ja
Produkter pr. hovedkasse (udvendigt):	6 stk
Overholdelse af bæredygtighed:	Ja
Gennemsnitstid mellem fejl (MTBF):	156000 t
Strømstiktype:	Type M
Antal kontrollerede computere:	4
Tastatur porttype:	USB
Mus porttype:	USB
Lydforbindelse:	Ja
Genvejstaster:	Ja
Konsol porte:	3.5mm headphone, 3.5mm mic, USB A
Trykknap:	Ja
Kompatible strømplug typer:	AU, EU, UK, US
Antal USB 2.0 type-A hub porte:	3
Antal mikrofon-indgange:	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub porte:	2
Dataoverførselshastighed (maks.):	5 Gbit/sek.
Antal USB 3.2 Gen 1 (3.1 Gen 1) Type-B porte:	4
Chipsæt:	GL3523
IP kontrol:	Ingen
