Side 1/4

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

October 4, 2023 9:58 AM

2-Port Dual Monitor KVM Switch - DisplayPort - 4K 60Hz - Serial Control

Product IDs

P2DD46A22-KVM-SWITCH

Product Information

For the latest software, manuals, product information, technical specications, and declarations of conformance, please visit:

www.StarTech.com/P2DD46A22-KVM-SWITCH

Hotkey Commands

Hotkey commands are keystroke sequences that initiate computer/device functions and can be used to initiate KVM Switch

functions. A hotkey command sequence must be initiated by the HK_LCode (HotKey Leading Code), followed by 1-2 additional

keystrokes. Successful hotkey command inputs result in a high-pitched beep. Unsuccessful hotkey command inputs result in a

low-pitched beep.

Notes:

- All keystroke combinations must be entered in rapid succession.

- Press and release the indicated keys, unless otherwise specied.

HK_LCode

Option 1.1

• Scr Lck + Scr Lck

Option 1.2

To change the HK_LCode:

• HK_LCode + H + CapsLk, NumLk, Left Ctrl or Right Ctrl

• Alternatively, press and hold the front Host Selection Button for PC2, until 2 beeps are emitted, then press the desired leading

hotkey of CapsLk, NumLk, Left Ctrl or Right Ctrl

Hotkey Command Chart

Hotkey Command Function

HK_LCode + Space • Bring up the On Screen Display (OSD) Menu.

HK_LCode + 1 ~ 2

HK_LCode + F1 ~ F2

• Select PC 1 or PC 2.

HK_LCode + W

• Disable the binding between PC (USB/Video) and Audio

when switching between PC 1 or PC 2.

• Allows switching of PC Ports USB and Video functions,

while Audio does not switch.

HK_LCode + Q

• Enable the binding of PC (USB/Video) and Audio

switching. (Enabled by default)

• Audio will switch with the PC Ports USB and Video

functions.

HK_LCode + F5 ~ F6

• Audio Unbound: Selects only the audio and mic source

between PC 1 or PC 2, does not switch USB and Video.

• Audio Bound: Select PC 1 or PC 2 and their respective

USB/Video/Audio Ports.

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

October 4, 2023 9:58 AM

HK_LCode + V

• Disable the binding between PC (USB/Video) and Serial

when switching between PC 1 or PC 2.

• Allows switching of PC Ports USB and Video functions,

while Serial does not switch.

HK_LCode + C

• Enable the binding of PC (USB/Video) and Serial

switching. (Enabled by default)

• Serial will switch with the PC Ports USB and Video

functions.

HK_LCode + F9~F10

• Serial Unbound: Selects only the Serial source between

PC 1 or PC 2, does not switch USB and Video.

• Serial Bound: Select PC 1 or PC 2 and their respective

USB/Video/Serial Ports.

HK_LCode + Up Arrow

Key

HK_LCode + Down

Arrow Key

• Select the next/previous PC Port.

• If Audio is unbound, the audio will not switch

• If Serial is unbound, the serial ports will not switch

HK_LCode + B

• Enable or Disable the Beep that indicates HotKey Com-

mand Inputs. (Enabled by default)

HK_LCode + H + 0~9

• Start Autoscan and set time delay.

• “x” = 1 - 10sec, 2 - 20sec, 3 - 30sec, 4 - 40sec, 5

- 50sec, 6 - 60sec, 7 - 70sec, 8 - 80sec, 9 - 90sec, 0 -

100sec

• Press any key to stop Autoscan

HK_LCode + R • Reset all Hotkey Commands to factory defaults

Serial Commands

The following Serial Commands are intended to be used with the KVM Serial Connection Port, allowing control over the function

of the KVM Switch. The Host Device that controls the KVM Switch requires the following parameters:

Baudrate: 115200bps

Parity: None

Data Bits: 8

Stop Bits: 1

Serial Command Function

sw 1~2 • Switch the active PC Port

audio 1~2 • Switch the active Audio Port

com 1~2 • Switch the active RS232 Port

bind 2~3

• Bind selected peripheral with the active PC Port

• 2 = Audio

• 3 = RS232

unbind 2~3

• Unbind selected peripheral from the active PC Port

• 2 = Audio

• 3 = RS232

hotkey 0~4

• Change the hotkey prex

• 0 = ScrLk

• 1 = CapsLk

• 2 = NumLk

• 3 = Left Ctrl

• 4 = Right Ctrl

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Skifte
Model:	P2DD46A22-KVM-SWITCH
Bredde:	130 mm
Dybde:	255 mm
Højde:	40 mm
Vægt:	1100 g
Produktfarve:	Sort
Indbygget skærm:	Ingen
Pakkevægt:	2100 g
Pakkedybde:	331 mm
Pakkebredde:	246 mm
Pakkehøjde:	175 mm
HD-type:	4K Ultra HD
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 90 %
Udgange til hovedtelefoner:	3
Skærmvisning (OSD):	Ja
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	3840 x 2160 pixel
Husmateriale:	Steel, Zinc
Hurtig installationsvejledning:	Ja
Kabler inkluderet:	DisplayPort, USB Type-A to USB Type-B
Strømkilde:	DC
LED-indikatorer:	Ja
Udgangsspænding:	12 V
Udgangsstrøm:	3 A
AC-adapter inkluderet:	Ja
Hovedkassen højde (udvendigt):	274 mm
Hovedkassens længde (udvendigt):	385 mm
Hovedkassens bredde (udvendigt):	370 mm
Plug and play:	Ja
Indgangsstrøm:	1 A
DisplayPort-version:	1.2
Antal DisplayPorts:	4
Ekstern strømadapter:	Ja
Produkter pr. hovedkasse (udvendigt):	2 stk
Gennemsnitstid mellem fejl (MTBF):	80907 t
Stativ-montering:	Ingen
Antal serielle porte:	3
Antal kontrollerede computere:	2
Tastatur porttype:	USB
Mus porttype:	USB
Video porttype:	DisplayPort
Lydforbindelse:	Ja
Genvejstaster:	Ja
Konsol porte:	3.5mm headphone, 3.5mm mic, DisplayPort, USB A
Trykknap:	Ja
Antal mikrofon-indgange:	3
Antal konsol USB porte:	4
Dataoverførselshastighed (maks.):	5 Gbit/sek.
Antal USB 3.2 Gen 1 (3.1 Gen 1) Type-B porte:	2
Serie porttype:	DE-9 (DB-9)
Skanningsinterval:	10, 20, 30, 40, 50, 60 sek./side
Daisy kæde:	Ingen
IP kontrol:	Ingen
Antal konsol displayporte:	2
