Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: July 18, 2019 11:29 AM

Product Diagram (ITB20D3250)

Component Function

1Power Connector (side) • Used to power the .Adapter

2LED Indicator

• Indicates that the is powered Solid: Adapter

On.

• Indicates that the is not receiving O: Adapter

power.

3Terminal Block Wires

• Used to connect and power a .Device

• = PositiveRed Wire

• = NegativeBlack Wire

• = 20VOutput

• = 3.25A 65WCurrent

Requirements

For the latest requirements, please visit www.startech.com/ITB20D3250

• (Optional) Small Flat Head Screwdriver x 1

• Device with a Two or Three Conductor Terminal Block Connector x 1

Using the Two Conductor Terminal Block Connector

1. Remove the from the , you want Two Conductor Terminal Block Connector Device

to power.

2. Plug the on the into the Two Conductor Terminal Block Connector Adapter

Terminal Connector Device on the .

Note: Ensure the polarity of the input power is correctly matched with the Terminal

Block Pins Device’s to ensure proper functionality. Refer to the vendor manual for

further information on properly wiring the .Device

Universal 65W DC Power Adapter | 20V 3.25A | Industrial

Two Conductor Terminal Block Connector

Using the Three Conductor Terminal Block Connector

1. Using a small screwdriver (Flat Head), loosen the screws on the Two Conductor

Terminal Block Connector Terminal Block Wiresand carefully remove the from

the . Two Conductor Terminal Block Connector

2. Using a small screwdriver, loosen the screws on the Three Conductor Terminal

Block Connector Terminal Block Wires (included) and carefully insert the into the

Three Conductor Terminal Block Connector (Red Wire = Positive and Black Wire =

Negative).

Note: Ensure the polarity of the input power is correctly matched with the Terminal

Block Pins Device’s to ensure proper functionality. Refer to the vendor manual for

further information on properly wiring the .Device

3. Tighten the screws on the , to secure Three Conductor Terminal Block Connector

the into the .Terminal Block Wires Three Conductor Terminal Block Connector

Three Conductor Terminal Block Connector

4. Plug the on the into the Three Conductor Terminal Block Connector Adapter

Terminal Connector Device on the .

Powering the Adapter

• Connect the to the on the and to an Power Cord Power Connector Adapter AC

Electrical Outlet.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a three-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

Safety Measures

• If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

2500 Creekside

Parkwy

Lockbourne, Ohio

43137

U.S.A.

Connecting the Adapter to a Terminal Block

1. Before terminating the make sure that the is disconnected from Adapter Adapter

the .Power Cord

2. Refer to the vendor manual that came with the in order to properly terminate Device

the . Adapter

Note: The are Red Wire = Positive and Black Wire = Negative. The Terminal Wires

Output is 20V and the Current is 3.25A 65W.

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	USB HUB
Model:	ITB20D3250
Bredde:	53 mm
Dybde:	115 mm
Højde:	35 mm
Vægt:	291 g
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Pakkevægt:	843 g
Pakkedybde:	166 mm
Pakkebredde:	242 mm
Pakkehøjde:	55 mm
Opbevaringstemperatur (T-T):	-20 - 80 °C
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Driftstemperatur (T-T):	0 - 40 °C
Strømforsyningstype:	Indendørs
Hurtig installationsvejledning:	Ja
Kabler inkluderet:	Vekselstrøm
Udgangseffekt:	65 W
Certificering:	REACH, CE, FCC, UL, PSE
Udgangsspænding:	20 V
Udgangsstrøm:	3.25 A
Harmoniseret systemkode (HS):	85044095
Bæredygtighedscertifikater:	RoHS
Indgangsspænding:	110 - 240 V
Formål:	Universel
Indgangsstrøm:	1.4 A
Stik:	Terminalblok
Mærke kompatibilitet:	StarTech.com
Inkluderede strømstik typer:	ANZ, EU, JP, NA, UK
