Safety instructions

Read the operating instructions

carefully and especially observe

the safety information. If you do

not follow the safety instructions

and information on proper han-

dling in this manual, we assume

no liability for any resulting per-

sonal injury or damage to prop-

erty. Such cases will invalidate

the warranty/guarantee.

a) General information

• The device is not a toy. Keep it out of the

reach of children and pets.

• Do not leave packaging material lying

around carelessly. This may become dan-

gerous playing material for children.

• -Protect the appliance from extreme tem

peratures, direct sunlight, strong jolts,

high humidity, moisture, ammable gases,

steam and solvents.

• -Do not place the product under any me

chanical stress.

• If it is no longer possible to operate the

product safely, take it out of operation and

protect it from any accidental use. Safe

operation can no longer be guaranteed if

the product:

- is visibly damaged,

- is no longer working properly,

- has been stored for extended periods in

poor ambient conditions or

- -has been subjected to any serious trans

port-related stresses.

• Please handle the product carefully. Jolts,

impacts or a fall even from a low height can

damage the product.

• Consult an expert when in doubt about the

operation, safety or connection of the ap-

pliance.

• -If you have questions which remain un

answered by these operating instructions,

contact our technical support service or

other technical personnel.

b) Installation / connection

Caution, safety hazard!

The product should only be installed by

people with relevant electrical knowledge

and experience! *)

If it is not installed properly, you risk:

• your own life

• the life of user of the electrical device

If it is not installed properly, you risk severe

damage to property, e.g. by re.

You face the risk of personal liability for per-

sonal injury and material damage.

Always consult an electrician!

*) Technical knowledge required to perform

the installation:

For the installation, the following specialist

knowledge is required in particular:

• The “Five safety rules”: Disconnect from

the mains; protect against accidental

switch-on; ensure there is no voltage;

earth and short-circuit; cover or protect

adjacent live parts

• Use of suitable tools, measuring devices

and personal protective equipment, where

necessary

• Analysis of measurement results

• Use of electrical installation materials to

meet the requirements for disconnection

• IP protection ratings

• -Installation of electrical installation materi

als

• Type of power supply (TN system, IT

system, TT system) and the correspond-

ing connection criteria (classic earthing,

protective earthing, necessary additional

measures etc.)

If you are not a professional, do not do it your-

self, have it performed by a specialist.

Further warnings:

• -The construction of the product corre

sponds to the protection-class II (double

or reinforced isolation). Ensure that the in-

sulation of the housing is neither damaged

nor destroyed.

• -During installation, all poles must be dis

connected from the mains voltage, e.g.,

via RCD. There must be an appropriately

rated fuse or circuit breaker between the

RCD and the product.

• The device must be voltage-free during

installation and connection. Furthermore,

turn off the automatic circuit breaker and

the earth leakage circuit breaker to discon-

nect all the poles from the mains voltage.

Secure it against unauthorised reconnec-

tion, e.g., with a warning sign. Check to

make sure there is no voltage with a suit-

able measuring instrument (e.g., a digital

multimeter).

• Never connect the product to the power

supply immediately after it has been trans-

ferred from a cold room into a warm one

(e.g., during transport). The condensation

that forms might destroy the device. More-

over, there is danger of electric shock!

• -Allow the product to reach room tempera

ture. Wait until the condensation has evap-

orated. This might take several hours. Only

after this, should it be installed, connected

to the mains supply and put into use.

• -Do not use the product in rooms with ad

verse environmental conditions, where

combustible gases, vapours or dust are

or may be present! There is a danger of

explosion!

c) Ingress protection

• This device has an IP20 ingress protection

rating and is suitable for dry rooms only.

• There is protection against touching live

components and ingress from foreign par-

ticles >12.5 mm.

• There is no protection against water, com-

bustible gases, and vapours.

Operating Instructions

Room thermostat Touch 2

Item No. 2480785

Intended use

The heating thermostat is intended for temperature control in conjunction with an electric heat-

er. The product operates under the mains voltage; a mains operated load can be connected

and switched on or off by temperature control.

It is equipped with an internal and external sensor (probe). The external sensor can be used to

measure the temperature in a different location to the thermostat, such as on the oor with an

electric oor heating system.

A keypad lock can be activated to protect against incorrect operation, and a backup (non-

removable) capacitor supplied with the unit serves to preserve data in case of power failure.

This device has an IP20 ingress protection rating and is suitable for dry rooms and indoor use.

Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be avoided under all

circumstances.

For safety and approval purposes, you must not rebuild and/or modify this product. If you use

the product for purposes other than those described above, the product may be damaged. In

addition, improper use can result in short circuits, res, electric shocks or other hazards. Read

the instructions carefully and store them in a safe place. Make this product available to third

parties only together with its operating instructions.

This product complies with the statutory national and European requirements. All company

Delivery content

• Thermostat

• 2x mounting screws

• External sensor

• Operating instructions

Up-to-date operating instructions

Download the latest product information at www.conrad.com/downloads or

scan the QR code shown. Follow the instructions on the website.

Explanation of symbols

The symbol with the lightning in the triangle is used if there is a risk to your health,

e.g. due to an electric shock.

The symbol with the exclamation mark in the triangle is used to indicate important

information in these operating instructions. Always read this information carefully.

The arrow symbol indicates special information and advice on operation.

The product is only intended to be installed and used in dry indoor rooms; it must not

get damp or wet.

The product is designed according to protection Class II (reinforced or double insu-

lation, protective insulation).

Observe the operating instructions!

Installation

1 2 43

N L

NTC

L1 N1

Load

1. To remove the front panel, slide the front part with the display upwards . The two parts (A)

are connected by a ribbon cable . (B)

The ribbon cable can be disconnected if needed. Be careful not to damage it.

2. On the back of the wall thermostat there are 6 terminals for connecting the:(C)

- The main power supply

- Electrical load

- External NTC temperature sensor

• Connect the mains power supply to the corresponding inputs 3 and 4.

• Connect the load (e.g., an electric radiator or electric oor heating) to corresponding outputs

1 and 2.

If the load requires a protective earth connection it must be connected separately.

The thermostat complies with protection class II and does not by itself require a

protective earth connection.

3. If using an external temperature sensor (probe), it should be connected to terminals 5 and

6 . There is no polarity so it does not matter which way you connect the wires.(C)

When laying out the connection cable, make sure it is protected from sharp edges.

Never fasten the connection cable with nails, screws or similar.

4. Insert the wall thermostat into the ush-mounted/ surface-mounted box and fasten it using

the included screws .(D)

Make sure that the cables are not damaged when inserting the wall thermostat into

the ush-mounted/surface-mounted box.

5. Reconnect the ribbon cable if needed. It can only be connected on way, do not use force

when plugging in!

6. Align the front panel and push it down . It should lock into place.(E) (F)

7. Switch on the voltage supply.

8. The wall thermostat is now operational.

Operating elements

a) Display

1 Six period program

2 External sensor active

3 Automatic mode

4 Manual mode

5 Holiday mode

6 Time

7 Weekday (1 = Monday, 7 = Sunday)

8 Target temperature setting

9 Open window (activated)

10 Measured temperature

(internal or external probe)

11 Keypad lock

12 Heating

b) Icons

Icon Description Icon Description

Visible when the keypad is locked.

Disappears when keypad is unlocked.

Auto mode: Weekly schedule program

is running.

Visible when heating is ON.

Disappears when heating is OFF. Manual mode.

The open window icon shows if it has

been activated.

Auto mode temporary manual

override.

External NTC sensor (probe) tempera-

ture shown.

Advanced setting "N2” should be set:

"Advanced settings" → "BN" → "N2".

Holiday mode: Set the number of days

you will be away and a temperature.

c) Touch controls

Function

Power ON / OFF.

• Touch to switch between “auto” and “manual” mode.

• Advanced options setting: Turn power off, then touch and hold 3 - 5 sec.

• Programmable setting: Turn power on, then touch and hold 3 - 5 sec.

• With the power off, touch and hold for approx. 3 - 5 secs to enter general settings.

• Conrms a setting.

• During normal operation touch to set the time and day of week.

• During normal operation, touch and hold 3 - 5 sec to enter “holiday mode” settings.

• With the power off, touch and hold for approx. 3 - 5 secs to enter advanced settings.

• Touch to increase a value.

• Touch and hold to display the temperature measured by the external temperature sensor.

- External sensor must be connected.

- Advanced setting “N3” should be enabled. Refer to "Advanced settings" → "BN" →

"N3".

• Touch to temporarily override “auto” mode and increase the temperature (auto settings

will be retained when exiting manual override).

• Touch to decrease value.

• Touch and hold to activate/deactivate the keypad lock.

• Touch to temporarily override “auto” mode and increase the temperature (auto settings

will be retained when exiting manual override).

Produkt Specifikationer

Mærke:	Sygonix
Kategori:	Termostat
Model:	Touch 2

Har du brug for hjælp?

Hvis du har brug for hjælp til Sygonix Touch 2 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Termostat Sygonix Manualer

Sygonix 1593775 Manual

27 August 2024

Sygonix HT 100BT Manual

27 August 2024

Sygonix HT100 Manual

27 August 2024

Sygonix TX 2 Manual

27 August 2024

Sygonix MH-912 Manual

27 August 2024

Sygonix Touch 2 Manual

14 Juli 2024

Sygonix tx.5 Manual

14 Juli 2024

Sygonix tx.4 Manual

14 Juli 2024

Sygonix tx.2 Manual

14 Juli 2024

Termostat Manualer

Nyeste Termostat Manualer

Honeywell RTH21B Manual

14 Juni 2025

Tado Wireless Temperature Sensor X Manual

9 Juni 2025

Fantini Cosmi CH123E Manual

26 Marts 2025

Netatmo Smart Radiator Valve Manual

26 Februar 2025

Netatmo Smart Thermostat Manual

26 Februar 2025

Rose LM TER-9 Manual

5 Februar 2025

Rose LM TH-H Manual

1 Februar 2025

Danfoss React M30x1.5 Manual

1 Februar 2025

Danfoss React RA click Manual

1 Februar 2025

Vemer Tuo 4G Manual

29 Januar 2025
