TOA 900 SERIES II

POWER AMPLIFIER

Operating Instructions

P-906MK2

P-912MK2

P-924MK2

P-906MK2

P-912MK2

P-924MK2

TO REDUCE THE RISK OF ELECTRICAL

SHOCK, DO NOT REMOVE COVER.

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

THE LIGHTNING FLASH WITH

ARROWHEAD WITHIN A TRIANGLE IS

INTENDED TO TELL THE USER THAT

PARTS INSIDE THE PRODUCT ARE A

RISK OF ELECTRIC SHOCK TO

PERSONS.

THE EXCLAMATION POINT WITHIN A

TRIANGLE IS INTENDED TO TELL

THE USER THAT IMPORTANT

OPERATING AND SERVICING

INSTRUCTIONS ARE IN THE PAPERS

WITH THE APPLIANCE.

Please follow the instructions in this manual to obtain the optimum results from this unit.

We also recommend that you keep this manual handy for future reference.

TOA Corporation

Contents

General description

Features

Nomenclature

Front panel

Rear panel

Input connections

Output connections

Rack mounting

Operation

Volume adjustment

Installation

Servicing

Specifications

Appearance (P-906MK2/P-912MK2)

Appearance (P-924MK2)

General Description

The TOA P-906MK2, P-912MK2 and P-924MK2 Power Amplifiers deliver up to 60 watts, 120 watts and 240

watts of power respectively at less than 0.5% total harmonic distortion (THD) from 20 to 20,000 Hz

(transformerless 4-ohm output). The power amplifiers have a high-impedance direct input and an input port

(edge connector) to accept one plug-in module. Module selection is determined by application among the

TOA plug-in modules.

The power amplifiers have a low-cut switch for a cutoff frequency of 60 Hz, and an input-level switch for input

sensitivity of 1V (0 dBV) or 100mV (–20 dBV). Output terminals provide connections for 4-ohm and 8-ohm

speakers, plus 25-volt and 70-volt speaker distribution outlets. With plug-in modules, the power amplifiers

may be used as a PA amplifier.

The power amplifiers can be rack mounted by using optional rack mounting bracket MB-25B(P-906MK2,

P-912MK2) and MB-35B(P-924MK2). The optional perforated panel PF-511 provides suitable ventilation,

finished in color to match the power amplifiers.

Features

1. Wide frequency response : 20 ~ 20,000 Hz ± 1 dB

2. Low distortion and noise level

3. Excellent output regulation

4. A full range of plug-in modules

5. Self-protecting circuitry design

6. Varied output impedances : 4 ohms, 8 ohms, 25 and 70 volts

7. Input level switch (selectable 1000 mV/100 mV)

8. Portable or rack mounting type

– 2 –– 2 –
