SPECIFICATIONS
STARKER AIR BTF CHASSIS
x28
Motherboard & SSD Screws
PSU Screws
HDD Screws
Motherboard Standoff Screws
Cable Ties
x6
x8
x1
x5
PACKAGE CONTENTS
1
ACCESSORY
3
QSG
2
ACCESSORY CONTENTS
Power
Button
Reset
Button
Hybrid
Audio Port
USB 3.2
Type A x2
CHASSIS I/O PORTS
STARKER AIR BTF
MID-TOWER CHASSIS
x3
Nut Setter
GPU Length
CPU Air Cooler Height
PSU Length
Up to 390mm
Up to 180mm
Up to 220mm
Mini-ITX
Micro-ATX
ATX
DIMENSIONS and COMPATIBILITY
A
A 3mm Tempered Glass Panel
Steel Panel
(Magnetic) Dust Filter
Magnetic Front Panel
Pre-installed 4 x 120mm ARGB Fans
PCI Expansion Bracket
Removable Hard Drive Cage
2.5”/3.5” HDD/SSD Trays
E-ATX Bracket
B
C
D
E
F
G
H
I
Learn More
Color Black / White
Form Factor
E-ATX / ATX / m-ATX / ITX
ATX / m-ATX (Reverse Connector Motherboards)
Material
SPCC / 3 mm Tempered Glass
Dimension (H x W x D)
496 x 242 x 464 mm
3.5" Drive Bays
2+1
Compatibility
Graphic Card Length
CPU Air Cooler Height
PSU Length
Pre-Installed Fans
4 x 120 mm ARGB Fans
PCIe Slots
7 Horizontal / 4 Vertical
2.5" Drive Bays
2+2
Front
Top
Rear
PSU Shroud
Side
Fan Support
120 mm x 3 / 140 mm x 3
120 mm x 3 / 140 mm x 2
120 mm x 1 / 140 mm x 1
120 mm x 3
120 mm x 2 (with E-ATX bracket removed)
Front
Top
Rear
Radiator Support
360 / 280 / 240 mm
360 / 280 / 240 mm
140 / 120 mm
2 x USB 3.2 Type A, 1 x USB 3.2 Type C,
1 x Hybrid Audio Port
1 x LED Button, 1 x Reset Button, 1x Power Button
I/O Ports
390 mm
180 mm
220 mm
Warranty 2 Years
PRE-SET LIGHTING EFFECTS
MODE DESCRIPTIONS
Mode 1 Mode 2 Mode 3 Mode 4 Mode 5
Red Green Blue Purple Yellow
Mode 6 Mode 7 Mode 8 Mode 9 -12 Mode 13
White Orange Neon Green
Lighting effect
No. 1-4
Off
LED
Button
USB 3.2
Type C
464 mm 242 mm
496 mm
Please consult your user manual of motherboard manufacturer, then connect these leads to the panel
header on the motherboard.
USB 3.2 Connection: Please refer to the motherboard manual for more information on the
connection.
Audio Connection: Please refer to the motherboard installation to avoid the device error and
cause the motherboard sound device to be damaged.
USB 3.2 Type C Connection: Please refer to the motherboard manual for more information
on the connection.
E-ATX
C
A
B
D
E
F
G
H
C
C
C
E
I
x2
VGA Card Standoffs (23.5mm)
REMOVING THE GLASS SIDE PANEL
POWER SUPPLY INSTALLATION
FAN MOUNTS
Side Fan Mount:
1.
2.
PSU Shroud Fan Mount:
1.
2.
1
2
E-ATX BRACKET & STORAGE INSTALLATION
1 2
2.5”
2.5”
3.5”
