LED door Luminaires In

Wall Mount

120V / 60HzAC

Page 1 of 2 1 R1 806 276

Model #: BW L30DNS051412 1SN

Model #: BW 051412L30D1SB NS

Limited Factory Warranty

AFX Inc. hereby warranty that this xture is free from defects in materials and workmanship when installed and used under normal operating

conditions for a period of 5 years from date of shipment from factory. This warranty covers all component parts and extends only to replacement of

defective xture or components; it does not cover failure due to improper installation, misuse, mishandling or damage incurred in transit.

Safety Precautions

 Read all safety precautions and installation instructions carefully before installing or servicing this xture. Failure to comply with these instructions could result

in potentially fatal electric shock and/or property damage.

 It is recommended that a qualified electrician perform all wiring. This xture must be wired in accordance with all national and local electrical codes.

 Do not handle any energized xture or attempt to energize any xture with wet hands or while standing on a wet or damp surface or in water.

 This xture is designed for use in a 120VAC, 60Hz fused circuit only. This xture is compatible with a TRIAC (forward-phase or leading-edge) / ELV (reverse-

phase or trailing-edge).

 To reduce the risk of electrical shock, and to assure proper operation, this xture must be adequately grounded. To accomplish proper grounding, there must

be a separate ground wire (green) contact between this xture and the ground connection of your main power supply panel.

 This xture is intended to be used for general indoor lighting in dry or damp locations.

 Disclaimer

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and Canadian ICES-

005 (B) / NMB-005 (B). These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment

generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiver antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult with the dealer or an experienced radio/TV technician for help.

Any modications to this xture may void the warranty and interfere with the safe operation of the luminaire.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

Assembly Instructions

Step 1 Preparing for installation–

A. at fuse or circuit breaker box before installing or servicing any part Disconnect electrical power

of this xture.

B. Carefully remove the xture from the carton, remove components from hardware kit.

C. Install mounting bracket (1) to the junction box (not included) using two screws (2) to secure it.

Wiring All wiring must take place inside junction box (not included) –

Caution: Make sure power is o at fuse or circuit breaker box. Check power wires for damage or

scrapes. If power supply wires are within three inches of the LED driver, use wire suitable for at

least 90°C (194°F). Most dwellings built before 1985 have supply wire rated to 60°C. Note:

Consult a qualied electrician to ensure correct branch circuit conductor before installing.

Step 2 Wiring xture –

A. Make all wire connections to appropriate wire. Secure with wire nuts (provided).

B. Connect the green wire from the xture to the supply power source ground wire.

C. Connect the white wire from the xture to the white (N) wire from For none-dimming xture.

supply power source. Connect the black xture wire to the black (L) wire from supply power

source.

D. Connect the white wire from the xture to the white (N) wire from dimming For TRIAC dimming.

source per dimmer wiring instructions. Connect the black wire from the xture to the black (L) wire

from dimmer supply power source per dimmer wiring instructions.

E. Pull on each wire lead to make sure connections are secure. Make certain no Do not mix wires.

bare wires are exposed outside of wire connectors. Tuck all connections neatly into the junction

box.

Step 3 Mounting fixture –

A. Place xture ) over the xture mounting plate (1), aligning the holes on top and bottom. Then (3

use two screws (4) to secure the xture in place.

Step 4 Restore power at fuse or circuit breaker box.–
