Visidec Freestanding | Dual horizontal

The Visidec Freestanding Dual Horizontal is a compact and durable desk stand that

holds two monitors with position and height adjustability. The minimal footprint and

integrated cable management ensure a flexible and clutter-free work environment.

Detachable display mounting heads support a wide variety of VESA compatible

monitors with Quick Release for easy installation / maintenance and Quick Shift for

easy adjustment. The heads feature a ball joint that allows tilt/ pan adjustment and

landscape to portrait screen rotation. Integrated tension control ensures touch-screen

support and the product ships with security screws to deter unauthorized screen

removal.

Product key features:

Holds two displays, each up to 635mm (35") wide and 12kgs (26.5lbs) in weight

Made from strong die cast aluminum with a steel base

Ball joint mechanism allows +/-20° of tilt and pan adjustment as well as 360° screen rotation

Integrated tension control for touch-screen compatibility

Provides up to 449mm (17.68") of height adjustment

Provides up to 635mm (25") of horizontal adjustment with easy Quick Shift operation.

Quick Release mounting heads enable easy display installation and maintenance with security

screws to deter unauthorized removal.

Small 422mm (16.25”) wide by 305mm (12”) deep footprint

Provides a choice of internal and external cable management

Comes with display mounting hardware

VFS-DH

Atdec Global www.atdec.com.au

Atdec North America www.atdec.com

Suits 75x75 & 100x100mm

(opt. 200x100mm support)*

Suits displays up to

12kgs (26.5lbs)

Tool-less tilt &

pan adjustment

Quick Release

mounting head

Adjustable screen

orientation

Holds two displays

Freestanding desk

mount

Allows positional

adjustment

VESA

* Also supports 200x100mm via optional adaptor plate

Height

adjustable

Quick Shift donut

mechanism for easy

horizontal adjustment

Ball joint

mechanism

allows display

adjustment up

to 20° in any

direction

Small foot

Strong die cast

aluminium construction

with sturdy steel base

Internal & external cable management

Quick Release mechanism for easy

display attachment/removal with a

security feature.

Product information, single unit

Package information, master pack

Package information, single unit

Technical drawings

Load capacityProduct Code

Material Color

Silver12kg (26.5lbs) per displayVFS-DH

Extruded anodized aluminium

construction with a steel base

and plastic trim.

Size

Ship weight UPC code Contents

Stand, mounting heads (x2),

security screws (x2) &

display mounting hardware

881493005129

53cm x 34cm x 11cm

(20.25" x 13.5" x 4.25")

5.8kg (13.2lbs)

Size

Ship weight UPC Units per master pack

3881493005174

53cm x 36cm x 34cm

(21" x 14" x 14")

20kg (40.6lbs)

475 mm

(18

16” )

682mm (27 ”)

Max Height

449mm (17

16” )

42 mm

8”)

42 mm

8”)

422mm

(16

8”)

89 mm

(3½”)

305mm

12”

M h 5 mm (25”)ax. widt 63

75mm

100mm

75mm

100mm

305 mm

(12” )

302 mm

(12” )

22 2mm

4” )

422mm

(16

8”)

Base Dimensions

Included VESA attachment

Optional Accessories

AC-AP-2010

200x100 Adaptor Plate

Other models in this range

VFS-DV

Freestanding Dual Vertical

VFS-Q

Freestanding 2 X 2 Quad

Atdec mounts are designed, developed and tested in Australia. We manufacture an extensive

range of display and projector mountings for a variety of user types and situations. While all

efforts have been made to ensure the information in this brochure was correct as of the date

of printing, we reserve the right to change specifications without notice. Please refer to the

web site for our full range along with the latest details on specifications, compatibility and

Atdec Global www.atdec.com.au

Atdec North America www.atdec.com

Produkt Specifikationer

Mærke:	Atdec
Kategori:	Flad panel støtte
Model:	Visidec VFS-DH
Produktfarve:	Sort
Monteringstype:	Skrivebord
Maksimal vægtkapacitet:	12 kg
Maksimal skærmstørrelse kompatibilitet:	- "
Antal understøttede skærme:	2
Minimal skærmstørrelse kompatibilitet:	- "
Montering interface kompatibilitet (min.):	75 x 75 mm
Montering interface kompatibilitet (maks.):	100 x 100 mm
