Side 1/5
AtlasSound.com 1/4
1601 JACK MCKAY BLVD. ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
©2011 Atlas Sound L.P. All rights reserved. Atlas Sound and Strategy Series are trademarks of Atlas Sound L.P. All other trademarks are the property of their respective owners. ATS001372 RevF 8/11
Strategy Series® II In-Ceiling 6" Coaxial Speaker System
FAP62T
Specifications
Power Rating 50 Watts
Transformer Taps 2, 4, 8, 16, & 32 Watts & 8 BypassΩ
Frequency Response 63Hz – 20kHz (±7dB)
Sensitivity (1W / 1M) 88dB
Woofer 6" Poly Cone Butyl Rubber Surround
Woofer Magnet Weight 14 oz (398g)
HF Driver 19mm Coaxially Mounted PEI Dome Tweeter
Diameter 121⁄2" (318mm)
Overall Height 8.48" (215mm)
Enclosure Volume 475 in3
Cut-out Dimensions 11" (279mm)
Features
UÊ ÊÝÌi`i`ÊÜÊÀiµÕiVÞÊ,iëÃiÊvÀÊÌiÊ{ÇxÊ
3 Optimally Tuned
and Ported Deep Drawn Galvanized Steel Enclosure
UÊ Ê>ÃÞÊÃÌ>>ÌÊÊÀ«Ê/iÊÀÊ-iiÌÀVÊi}ÃÊ6>Ê,}É6,>Ê
/iÊÀ`}iÊ>`ʺ}Êi}»ÊÕÌ}Ê-ÞÃÌiÊVÕ`i`®Ê
UÊ ÊÀÌÊÕÌi`Ê/>«Ê-iiVÌÀÊ-ÜÌVÊvÀÊ>ÃÞÊ-ÞÃÌiÊ/Õ}Ê
Adjustments Include Transformer Bypass Setting for 8 Direct Ω
Coupled Operation
UÊ Ê1µÕiʺ/À>«ÊÀ»Ê«ÕÌÊ-iVÌÊÜÃÊvÀÊ/ÀÕ}Ê`ÕÌÊ,ÕÃÊ
with Rigid or Flex Conduit
UÊ Ê{Ê*iÊiÌ>V>Liʺ*iÝ»Ê-ÌÞiÊiVÌÀÊÜÃÊ>ÃÞÊ*Ài7À}Ê
and Is Convenient for Daisy Chaining Additional Strategy Series Full
Range Speakers or Subwoofers
UÊ Êº*ÀiÃÃÊÌ»ÊÀiÃÊi`ÊiÌÌiÀÊÌÊÌi«À>ÀÞÊÀVÌiVÌÕÀi
UÊ Ê>Vi`Ê+Õ>ÌÞÊÇä°Ç6ÊÉÊ£ää6ÊÌiÀ>Ê/À>ÃvÀiÀÃÊâiÊ
ÃiÀÌÊÃÃÊ>`Ê>Ì>ÊÜÊÀiµÕiVÞÊ,iëÃiÊ7iÊ
*ÀÛ`}ÊVÀi>Ãi`Ê"ÕÌ«ÕÌÊvÀÊ}iÀÊ-*Ê««V>ÌÃ
UÊ Ê1ÊÃÌi`Ê£{nä
Applications
Atlas Sound’s FAP62T combines superior coaxial loudspeaker perfor-
mance with even dispersion and easy installation. A low profile enclosure
and wide coverage make the FAP62T a perfect choice for low ceilings.
The FAP62T will satisfy the needs of owners, architects, contractors,
and consultants by delivering true, high fidelity sound reproduction
in an attractive and easy-to-install system. The FAP62T is ideal for
high-intelligibility voice, music, and signal reproduction in commercial,
industrial, and institutional applications.
General Description
The FAP62T's 110° dispersion angle can reduce the number of
l oudspeakers necessary to achieve coverage in distributed systems with
low ceilings.
The loudspeaker component matches the performance of the legen dary
Atlas Sound FA136 driver. High quality construction 6" coaxial cone type
`ÀÛiÀÊVÕ`iÃÊ>Ê£»ÊÛViÊVÊ>`Ê«Þ«À«ÞiiÊViÊÜÌÊ>ÊLÕÌÞÊÀÕLLiÀÊ
surround. The 19mm coaxially mounted tweeter is constructed of PEI. A
high sensitivity of 88dB average (92dB peak) means less power may be
ÀiµÕÀi`ÊÌÊ>ViÛiÊÌiÊ`iÃÀi`Ê-*°Ê/ÃÊÕ`ëi>iÀÊÃÊv>VÌÀÞÊ>ÃÃi-
bled in an optimally tuned and ported deep drawn enclosure and includes
a specially designed 32 watt low saturation 70.7V / 100V transformer.
A convenient front mounted selector switch allows tap selection with-
out the need to remove the speaker from the ceiling. This switch also
includes a transformer bypass setting for 8 direct coupled operation.Ω
FAP62T
AtlasSound.com 2/4
1601 JACK MCKAY BLVD. ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
©2011 Atlas Sound L.P. All rights reserved. Atlas Sound and Strategy Series are trademarks of Atlas Sound L.P. All other trademarks are the property of their respective owners. ATS001372 RevF 8/11
Mounting Accessories
Mounting is simplified with Strategy Series®ÊÃÌÞiʺ}Êi}»ÊÌ>LÃÊÌ>ÌÊ
allow easy installation into drop tile or drywall ceilings with provided tile
LÀ`}iÊ>ÃÃiLÞ°Ê/iÊÌiÊLÀ`}iÊVÃÃÌÃÊvÊÌÜʺ6»ÊÃ>«i`ÊvÀi`Ê
mounting rails and a C-Ring assembly. The C-Ring can be attached to the
rails with the screws provided to extend support to the T-bar grid in sus-
pended ceiling applications. Multiple hole locations are provided to allow
the C-Ring to be positioned to the outer edge of the tile if necessary.
For existing dry-wall applications the tile bridge C-Ring and support rails
can be inserted into the hole cut for the FAP62T. For easy positioning
Ìiʺ6»ÊÃ>«i`ÊÃÕ««ÀÌÊÀ>ÃÊ>ÌVÊÌiÊÃ>«iÊvÊÌiÊ,}ÊÌ>LÃÊvÀÊ
easy maneuvering and location when working “blindly" above the deck.
A uniquely designed “easy access" input panel on the side of the enclo-
sure allows for “thru" conduit runs using flexible or rigid conduit. Below
this cover resides a detachable Phoenix / Euro style locking four-pole
connector, which provides for easy daisy chain wiring to other full range
Çä°Ç6ÊÕ`ëi>iÀÃÊÀÊÌ>ÃÊ-Õ`Ê*-1ÊÃÕLÜviÀðÊ/iÊ«>V>}iÊ
includes an attractive press-fit grille, which nicely matches contemporary
architecture.
For new construction drywall ceiling applications, the optional FAP62-TR
trim ring is available. This unit provides a marked location for drywall
installers to cut around essentially reserving the desired location in the
ceiling until final installation of FAP62T. Mounting holes are provided to
accommodate 16" or 24" OC stud / joist mounting.
A support ring is also provided on the top of the FAP62T enclosure to
facilitate an auxiliary support cable.
NOTE: IT IS MANDATORY THAT THIS SECONDARY SUPPORT
BE UTILIZED IN DROP CEILINGS FOR SAFETY AND SEISMIC
CONSIDERATIONS.
Architect & Engineer Specifications
The loudspeaker system shall be Atlas Sound FAP62T. System shall
include a high performance 6" coaxial loudspeaker, ported bass reflex
enclosure and press-fit grille for conventional ceiling installation.
Frequency response for the system shall be 63Hz – 20kHz (±7dB).
Sensitivity shall be 88dB average.
Õ`ëi>iÀÊÃ>ÊLiÊV«ÀÃi`ÊvÊ>ÊȸÊV>Ý>ÊViÊÌÞ«iÊ`ÀÛiÀ°ÊiÊ
shall be constructed of polypropylene with a butyl rubber surround. The
19 mm tweeter shall be constructed of PEI. Magnet shall be a minimum
of 10 oz (264 g) and the voice coil diameter shall be 1" (25 mm).
Transformer shall be a 70.7V / 100V type with 2, 4, 8, 16, and 32 watt
primary taps (@70.7V) with a front mounted tap selector switch to include
transformer bypass setting for 8 direct coupled operation.Ω
Enclosure shall be a deep drawn steel enclosure design. Internal volume
shall be 475 in3. To facilitate connection in conduit systems, enclosure
shall be equipped with an access panel covering a recessed terminal cup.
This cover shall provide a combination 3⁄4" (19mm inside diameter) / 1"
(25mm inside diameter) knock-out on the side access and a top access
compression fitting / strain relief to facilitate flexible conduit up to 22mm
outside diameter or 1" (25mm inside diameter) conduit when the com-
pression fitting is removed.
External wiring shall be accomplished via a removable lockable wir-
ing connector with screw-down terminals to provide both secure wire
termination and pre-wiring capability before loudspeaker installation. The
4 pole locking connector shall facilitate in/out connections and shall be
located in the recessed area behind the conduit access panel.
Seismic support eye shall be provided on top of enclosure for additional
suspension point when used in drop tile ceilings. Construction of enclo-
sure shall be a minimum of 18-gauge deep drawn galvanized metal.
The system shall include a support backing plate to reinforce the ceil-
ing material and tile support rails for use on either 2' x 4' (609mm x
1219mm) or 2' x 2' (609mm x 609mm) suspended ceiling tiles. This
assembly can all be installed from beneath the ceiling tile.
Overall front face diameter shall not exceed 12
1⁄2" (318mm); overall depth
from the bottom of the ceiling shall not exceed 8.48" (215mm).
Grilles shall be press-fit, manufactured from 24-gauge perforated steel
mesh and finished in white epoxy. Round grill shall be 10.48" (266mm)
diameter.
The loudspeaker shall be the Atlas Sound FAP62T.
C-Ring / V-Rails
FAP62-TR
