SM12CXT
High Performance Coaxial Loudspeaker
SM12CXT-B
Features
• High Performance Atlas Sound Compression Driver Coaxial
Loudspeaker in Versatile, Flyable, Wood Enclosure
• Multiple (12)
1
⁄4"-20 Inserts, Providing Fly Points for a Variety of
Mounting Configurations
• Includes Internal, High Efficiency 60 Watt 70.7V/100V Transformer
(May Be Bypassed For 8Ω Operation)
• Barrier Strip Input For 70.7V/100V/8Ω or Parallel 4 Pole Speak-On Input
for 8Ω Operation Only
• Unique Input Panel Allows Use of Standard 4" Square Box Cover (Raco
753 or Eq.) For Applications Where Flex Conduit is Required
for Termination
• Fuse Protection for Low and High Frequency Drivers
• Attractive, Heavy-Duty Grille Assembly
• Durable Black or White, Rough-Coat Finish
• Optional Brackets for Wall Mounting
• Pre-Drilled With T-Nut Inserts for Omnimount™ Bracket Wall Mounting
Applications
The SM12CXT is optimized for high ceiling applications such as arenas,
convention centers, gymnasiums, and auditoriums. The extreme high
efficiency and higher "Q" of the 12CX with its powerful 12" speaker and
1" exit compression driver, provides the increased available SPL often
required in these high ceiling applications. In 70.7V/100V systems this
high efficiency can also result in lower tap settings.
General Description
SM Series loudspeakers offer quality sound reproduction and
contemporary styling. The SM12CXT features the 12CXT60—a 250W
loudspeaker that combines a 12" diameter, low frequency transducer and
a 1" exit compression driver. The speaker has a curvilinear, treated-paper
cone for lower harmonic distortion, and a built-in crossover network
for proper frequency transition between the two reproducers. The low
frequency transducer and the high frequency driver feature permanently
aligned voice coils for low distortion performance. The copper coils have
Polyimide voice coil formers.
The SM12CXT features a wood enclosure with a metal grille. Internal
hardware, for flying, includes multiple (12)
1
⁄4"-20 inserts for overheard
suspension in almost any orientation.
A 90˚ conical pattern (2kHz octave band) and amazing efficiency make
the SM12CXT a perfect choice for a wide variety of applications
including school auditoriums, gymnasiums, cafeterias, church sanctuary
systems, and more.
This perforated top panel is designed for use on the Atlas Sound FMA
and 700 series floor mount vertical equipment racks.
Specifications
Power Rating (Rms) 250 Watts
Frequency Response 55Hz – 15kHz (± 5dB)
Sensitivity (1W/1M) 99dB
Power Taps 7.5, 15, 30, & 60 Watts & 8Ω
Height 19" (483mm)
Width 14
1
⁄2" (368mm)
Depth 14
1
⁄16" (357mm)
Weight 39 Lbs (17.7kg)
Dispersion Angle 90°
Finish Rough-Coat, Black or White
