Side 1/16
Zone 120BT / Zone 240BT / Zone 360BT
Please read the manual before using the product
USER´S
MANUAL
15
Zone 120 BT
Zone 240 BT
Zone 360 BT
Player
USB
Type
OTG2.0 full-speed
controller
Connectors
USB 2.0 Type-A
SD/MMC Connectors
Non-self-locking so card
slot
Bluetooth
Version
Bluetooth Ver20+EOR
Max range
10m (without
interference)
Trans
Frequencies
2402-2480MHz
Music formats
MP3/WAW/WMA/FLAC
(8/16/24bit)
File system
FAT16 or FAT32
FM Section
Tuning range
87.5MHz to 107.9MHz
Antenna input
75Ω unbalanced
Outputs
Low impedance
4Ω
Constant Voltage impedance
167Ω-Zone 60BT
84Ω-Zone 120BT
42Ω-Zone 240BT
28Ω-Zone 360BT
Indicators
LED
Power/Zone/Output
LCO
Player
Sound
Protect
Protection
DC-Short Circuit
Over Healing
Over Load
Limiter
Cooling system
Fan cooled
Amplifier technology
Class A/B
Power supply
Master
AC230V-240V/50-60Hz
Standby
DC24V
Zone 120BT / Zone 240BT / Zone 360BT
USER´S
MANUAL
1 14
Index
Introduction..................................................................................................................2
System Black Diagram................................................................................................2
Precautions...................................................................................................................2
Safety requirements......................................................................................................2
Caution servicing..........................................................................................................3
EC Declaration of Conformity.....................................................................................3
Caution..........................................................................................................................4
Chapter 1: Pin connections and connectors............................................................4
Connection standards.................................................................................................4
Chapter 2: Front & rear panel.....................................................................................5
Front panel overview....................................................................................................5
Front panel description.................................................................................................5
Rear panel overview.....................................................................................................8
Rear panel description.................................................................................................8
Chapter 3: Setting up the system..............................................................................10
Connection the loudspeakers...................................................................................11
Connection the audio sources..................................................................................12
Phantom power..........................................................................................................13
To start playing music form MP3................................................................................13
To start playing music via Bluetooth .........................................................................13
Chapter 4: Additional information............................................................................14
Technical specifications.............................................................................................14
ATTENTION
• Do not operate the amplifier or disconnect power cable during firmwave
update Firmware update takes about10seconds
• No files other than firmware in USB storage device or SD card.
• Do not perform this procedure unless firmware update is necessary Also make
sure you read the information supplied with updates before updating the
firmware.
Chapter 4
Additional information
Technical specifications
RMS Output
Power
1 kdiE.TriD %o
Zone 120BT
120 Watt
Zone 240BT
240 Watt
Zone 360BT
360 Watt
Frequency response
20Hz-20KHz
Signal to Noise Ratio
>90dB
THD+N
<0.5%
Common Mode Rejection
<0.5%
Crosstalk
>70dB
Inputs
MiC1-2
Type
2x Balanced mic / Une
Sensitivity
-50dB
Connectors
2xXLR/6.3mmJack combo
Phantom power
15VDO
Priority
Yes
LINE 1/MIG3
Type
Balanced mic/line
Sensitivity
-50dB
Connectors
XLBi6.3mm Jack combo
Priority
YES
LINE2-3
Type
2x Stereo ling
Sensitivity
-30dB
Connectors
2x RCA
Chime/Fire/TEL
Type
Priority mic inputs
Connectors
Euro terminal block-
5.08mm
