TECHNICAL DATA

Veritas 2160BH

smart mixer amplier

BoseProfessional.com 1 OF 5

For additional specications and application information, visit BoseProfessional.com. Specifications are subject to change. 09/2025

Product Overview

The award-winning Veritas series from Bose Professional delivers superior background/foreground music, paging and

multimedia for commercial applications.

Bluetooth

5.0 wireless input and user-intuitive OLED screen with quick-start

QR code simplify setup—whether you’re a pro installer or a DIYer. With four models to choose from, Veritas ampliers

offer the perfect combination of power, performance and exibility.

The ultimate choice for large-scale 70V/100V distributed audio systems, the 2160BH efciently powers multiple zones with

premium sound clarity and reliable, consistent coverage. Ideal for hotels, conference centers, and multi-room installations,

the 2160BH offers high output with advanced features for integrators handling complex, high-demand applications.

Applications

Retail stores

Restaurants and bars

Hospitality venues

Conference centers

Schools

Auxiliary zones

Key Features

Premium amplication with advanced DSP for optimized performance

Bluetooth

connectivity and RCA connectivity—no wire splicing required

Intuitive front-panel OLED screen for easy setup and control

Embedded quick-start QR code in the OLED screen simplies installation

Supports high-impedance (70/100V) applications

Multi-zone exibility—support for two independent zones

Remote level control with Bose Professional or third-party wall controllers

Dynamic EQ adjusts bass levels to achieve a fuller sound even at low volumes

Up to 30 selectable EQ presets ensure Bose Professional signature sound

performance and long-term reliability

Opti-Voice paging feature ensures clear speech intelligibility

TECHNICAL DATA

Veritas 2160BH

smart mixer amplier

BoseProfessional.com 2 OF 5

For additional specications and application information, visit BoseProfessional.com. Specifications are subject to change. 09/2025

Technical Specications

POWER RATING

Amplier Power 2 × 160 W at 70V/100V

AUDIO PERFORMANCE

Frequency Response 20 Hz – 20 kHz (+0/-3 dB, @ 1 W reference 1 kHz)

THD+N ≤ 0.5 % (at rated power)

Channel Separation (Crosstalk) ≤ -58 dBu (below rated power, 1 kHz)

Dynamic Range 88 dB

INTEGRATED DSP

A/D & D/A Converters 24-bit, 48 kHz

Processing Functions Volume, tone controls, Opti-Voice paging, loudspeaker EQ, Dynamic EQ

Loudspeaker Presets

70 Hz high-pass lter, 80 Hz high-pass filter, AMU105, AMU108, DesignMax (all models),

EdgeMax (all models), FreeSpace FS (all models), subwoofer

Audio Latency 10.4 ms (any input to speaker output or aux output)

AUDIO INPUTS Line Inputs Page Inputs

Input Channels (2)balanced, (2)unbalanced (1)balanced mic/line

Connectors (2)RCA stereo pairs, (2)5-pin Euroblock (1)4-pin Euroblock

Input Range -8 dBu to +22 dBu -58 dBu to +12 dBu

Adjustment Range -20 dB to +20 dB 0 dB to +50 dB

Input Impedance 20 kΩ 2 kΩ

Maximum Input Level 22 dBu 12 dBu

Sensitivity -8 dBu -58 dBu

Nominal Input Level 4 dBu -38 dBu

AUDIO OUTPUTS Loudspeaker Outputs Auxiliary Outputs

Output Channels (2)loudspeaker (1)unbalanced line

Connectors (2)2-pin inverted Euroblock (1)RCA stereo pair

Output Impedance n/a 400 Ω

Nominal Output Level 2 × 160 W at 70V/100V 2 dBu

INDICATORS & CONTROLS

Power LED Solid blue (powered on), blinking blue (standby mode)

Input Signal LED Green (-34 dBu to +10 dBu), red (> +10 dBu). Input gain level set to 5.

Output Limit LED

Green (-40 dBFS to -2 dBFS), red (> -2 dBFS). Approximately 100W/channel. For each

output, 160W is 0dBFS.

Bluetooth

LED

Off (no

Bluetooth

device connected), blinking blue (ready to pair to a

Bluetooth

device),

solid blue (connected to a

Bluetooth

device)

Display OLED, 16-bit grayscale, 96 × 96 resolution

Controls, Front Panel Power on/off switch, input select switch (A/

Bluetooth

/B), rotary encoder

Controls, Rear Panel

Amplier mode DIP switches, input gain knobs (A, B, page), page threshold knob, mute

connector, ControlCenter ports, 70V/100V switch
