Hazard: Improper use or failure to follow instructions can result in explosive failure causing serious eye or other

injury. For safe use of this product you must read and follow all instructions. Do not leave a pressurized sprayer in the hot

sun. Heat can cause pressure build-up. Do not store or leave solution in tank after use. Always wear goggles, gloves, long

sleeve shirt, long pants and full foot protection when spraying. Never use any tool to remove pump if there is pressure

in sprayer. Never stand with face or body over top of tank when pumping or loosening pump to prevent ejecting pump

assembly and/or solution from striking and injuring you. Never pressurize sprayer by any means other than the original

pump. Do not attempt to modify or repair this product except with original manufacturer’s parts. Never spray ﬂammable

materials or heat, pressure, or gas producing chemicals. Always read and follow manufacturer’s instructions before

use with this sprayer as some chemicals may be hazardous when used with this sprayer.

WARNING!

Sk-1113-1

1. Hose to Tank

2. Nozzle / Extension Wand

Attach nozzle to shut-oﬀ handle or extension wand per

Fig. 2A-2D depending on the style of extension wand

included with sprayer.

3. Filter

e ﬁlter helps prevent clogging while spraying. It is located on the end of the outlet tube

inside your sprayer tank.To clean ﬁlter, remove the discharge assembly from the tank

(Fig.1A). Make sure the ﬁlter is positioned at the bottom of the tank as pictured (Fig. 3A).

Note: Filters are not supplied with deck sprayers.

1) Check tightness of hose nut to be sure hose is securely attached to the tank outlet. Do:

2) Inspect hose for deterioration, cracks, softness, or brittleness. If any of these conditions are found, replace hose Do:

before using. Replace with original manufacturer’s parts only.

3) Remove pump (see Filling, Pressurizing and Spraying Instructions), inspect interior and exterior of tank for signs of Do:

deterioration of body and bottom. Any sign of deterioration indicates possible tank weakening and could result in

explosive bursting under pressure. If any of these signs are found, discard tank immediately and replace. Do not attempt

to patch leaks, etc., as this could result in serious injury.

4) Follow Filling, Pressurizing and Spraying Instructions, except use water only (Pump plunger 10-20 strokes and Do:

inspect for leaks).

5) Direct shut-oﬀ away from you and open to make sure discharge is not clogged. Do:

6) If unit passes this test, release pressure (see Pressure Releasing Instructions), empty tank, and proceed with Filling, Do:

Pressurizing and Spraying Instructions.

5. Pre-Use Check

6. Filling

1) Turn pump handle counterclockwise and remove pumpDo:

2) Prepare spray solution following all directions and safety warnings on chemical label.Do:

3) Fill tank to no more than the proper gallon marker. Do NOT: overﬁll to accommodate pump.Do:

4) Check pump to make sure that no grass or dirt is stuck to barrel. Replace pump in tank and tighten securely.Do:

8. To Release Pressure

Sprayers with no pressure release valve

Do: With pump facing away, turn locked handle counterclockwise until air begins to escape. Stop turning handle when

you hear air escaping. Point pump away until all air has escaped.Do:

9. Care, Storage and Maintenance

1) Rinse tank thoroughly with water only, empty, reﬁll with water. Follow Filling, Pressurizing and Spraying Do:

Instructions, except pump unit only 8-10 strokes.

2) Open shut-oﬀ and allow water to run through discharge assembly. Do:

3) Release pressure (Follow Pressure Release Instructions), remove pump and empty sprayer. Do:

4) Store sprayer tank upside down, with pump removed, in a warm dry location. Do:

5) Periodically oil pump by dropping 10-12 drops of light oil down pump rod through opening in cover.Do:

WARNING: Handling the brass parts of this product will expose you to lead, a chemical known to the State

of California to cause birth defects and other reproductive harm. Wash hands after handling.

Congratulations!

You have just purchased a quality Chapin product.

Questions?

Do Not Return To Store.

Call us @ 1-800-950-4458 or www.chapinmfg.com

¡Felicitaciones!

Usted acaba de adquirir un producto de calidad Chapin.

Registre su pulverizador en línea en www.chapinmfg.com

¿Preguntas?

No regrese a la tienda;

llámenos al 1-800-950-4458 o visite www.chapinmfg.com

Félicitations!

Vous avez acheté un produit de qualité Chapin.

Enregistrez dès que possible votre pulvérisateur en ligne à l'adresse suivante:

www.chapinmfg.com

Questions ?

Ne retournez pas au magasin.

Appelez-nous 1-800-950-4458 ou visitez le www.chapinmfg.com

010328 (A) R0110

Note: Your particular sprayer may not include all parts pictured above.

Nota: Es posible que este pulverizador en particular no incluya todas las partes que se ilustran arriba.

Remarque : Votre pulvérisateur particulier pourrait ne pas inclure toutes les pièces illustrées plus haut.

Discharge/ Tool Holder Assembly

• Insure the tool holder is assembled to the tank adapter before mounting the discharge assembly (Fig.1A). e Tool Holder

snaps into the groove of the tank adapter. Figure 1D shows how the shield and cup are mounted (Not all models are pro

vided with tool holder, spray shield and measuring cup).

• Insert the outlet tube portion of the discharge assembly into the tank adapter (Fig. 1A).

• Firmly insert the outlet tube portion into the tank adapter (Fig. 1B) leaving no gap between the tank adapter and outlet

tube adapter. Firmly tighten the retaining nut to the tank adapter (Fig. 1C).

WARNING!

To prevent hose from blowing oﬀ, hose must cover both barbs on the outlet tube adapter and touch ﬂange

(Fig. 1B) before hose nut is securely tightened (Fig. 1C).

Retaining Nut -

Securely tightened.

Tool

Holder

Measuring

Cup

Spray

Shield

Tool

Holder

Outlet

Tube

Discharge

Assembly

Filter

4. Shield Attachment to Wand

Snap shield onto wand as shown. Using the spray shield will help protect your plants

etc. from over spray. (Not all models are provided with spray shield).

Parts, Piezas, Pièces

6-2001

Hose Kit: 2 nuts, 2 barbs and hose

Juego de manguera: 2 tuercas ,2 lengüetas y manguera.

Nécessaire de tuyau: Deux écrous, deux ardillons et tuyau

6-5364

Measure Cup

Taza para medir

Tasse à mesurer

6-2000

Shut-oﬀ Handle

Mango de cierre

Poignée du robinet

6-5385

Spray Shield

Pantalla de pulverización

Bouclier de pulvérisation

6-6003

Nozzle

Boquilla

Buse

7. Pressurizing and Spraying

Do: Turn handle clockwise

to tighten. Push handle

down, turn 1/4 turn coun-

terclockwise to release.

Do: Pump until

you feel resistance.

Do: Push handle, down, turn

1/4 turn clockwise to lock.

Begin spraying. Re-pump

sprayer as required to maintain

spray force.

Do: Turn end of nozzle

to adjust spray pattern.

010842

Tool Holder

Soporte para la

herramienta

Porte-outils

No Gap

Tank

Adapter

Outlet

Tube

Adapter

6-4645

Relief Valve

Válvula de descarga de

presión

Soupape de

décompression

6-4566

Four Position Nozzle

Boquilla de 4 posiciones

Buse à 4 positions

6-3337

Straps

Tirantes

Sangles

6-7756

Extension wand (brass)

Vara de extensión

Lance de rallonge

301120-4

Fan Nozzle

(brass tip)

Boquilla

Buse

3-4843

Fan Nozzle Pack

Paquete de boquilla a

chorro

Ensamble de buse à jet

éventail

Filter

Pull handle straight up.

Insert notches from

underside of handle

into plunger grooves

and turn counter-

clockwise.

Remove plunger and diaphragm.

Clean plunger, diaphragm

and body. Flip diaphragm and

replace.

Tighten plunger clockwise until

ﬂush to top of shut-oﬀ body.

Do not over-tighten or unit

may not spray. Slide forks un-

der plunger, push handle down

until it snaps into place.

11. Troubleshooting

Tank pressurizes but does not spray.

11A 11B 11C

Handle

Plunger

Body

Diaphragm

11D

Plunger ﬂush

with body

WARNING:

Release pressure in tank before troubleshooting.

Clean Nozzle Assembly (Fig. 11E)

-Remove nozzle cap. Clean and re-assemble.

Clean shut-off (Fig. 11A- 11D)

10. Fatigue-Free Spraying

For constant spraying, push down on shut-oﬀ handle and move grey locking

mechanism away from you. To release, squeeze handle and move the grey locking

mechanism back towards you. ( Not all models are provided with this feature).

2F2E

Red,

Fine spray for

ﬁner washes

Blue,

Medium spray for

sealers

Yellow,

Course spray for semi-

transparent stains

Attach cap to shut-oﬀ handle or extension wand (Fig. 2F-2G).

Do: Point valve away from you when releasing pressure.

1 piece style

Deck Sprayers Only ( Fig. 2D-2G)

Insert nozzle into cap (2E).

10A

Locking

mechanism

Sprayers with pressure release/relief valve

Fig. 8A: Lift and hold the cap OR, turn the valve slowly counterclock-

wise until air is completely exhausted.

Fig. 8B: Pull up stem until air is completely exhausted.

11E

Nozzle Cap

6-7749

Extension wand (poly)

Vara de extensión

Rallonge

6-8156

Relief Valve

Válvula de descarga de presión

Soupape de décompression

Repair Parts Kit Gaskets and Seals (not included),

Juego de piezas de reparación, empaquetaduras y juntas (no incluido)

Kit de pièces de réparation, joints et garniture d’étanchéité (non inclus) 6-1925

301272-1

Nozzle

(brass tip)

Boquilla

Buse
