Side 1/4
15WATT HOWITZER
Guitar Preamp & Power Amp
Congratulations on your purchase of the 15WATT HOWITZER guitar amplifier!
The 15Watt Howitzer produces an ample 15 watts but is small enough to throw in
a bag and carry anywhere. At 15 watts, the Howitzer’s sweet sound and extreme
portability will make it an integral part of any rig. The 15Watt Howitzer was
designed for guitar but can handle other instruments as well. It includes a preamp
section with GAIN, BASS, MID, and TREBLE controls to dial in your perfect sound.
The BRIGHT switch adds a bit more sparkling highs to your output. An FX Loop,
on the SEND/RETURN jacks, allows for effects to be placed between the 15Watt
Howitzer’s preamp section and VOL knob. Please read this manual to get the most
out of your 15Watt Howitzer.
CONTROLS
VOL Knob – Controls the volume or loudness of the amplifier. As you turn the
VOL knob clockwise, the 15Watt Howitzer’s output gets louder. This knob acts as
a master volume control and interacts with t the output level. the GAIN knob to se
GAIN Knob – This knob controls the amount of gain and overdrive that is
generated by the preamp. As you turn GAIN clockwise, the overall signal will get
louder and start to distort. When the knob is turned fully clockwise, the sound will
be a warm overdriven tone. WARNING: as you turn the GAIN knob up, the output
level might increase significantly, compensate by turning down VOL.
BASS Knob – Controls the loudness of low frequencies in the preamp section of
the amplifier. As you turn BASS up, the low-end increases.
MID Knob – Controls the mid frequency loudness in the preamp section of the
amplifier. As you turn MID up, the middle frequency band increases in level.
TREBLE Knob – This knob controls the loudness of high frequencies in the
preamp section of the amplifier. As you turn TREBLE up, the high-end increases.
WARNING: THE 15Watt Howitzer IS A POWER AMP, NOT AN EFFECTS PEDAL.
Do not connect the OUTPUT 8-16Ω jack of the 15Watt Howitzer to the input of
another amplifier, effects pedal, mixer, computer, computer interface or other
similar device. Connect the output of the 15Watt Howitzer to an 8 -16 Ω
speaker cabinet ONLY.
BRIGHT/NORM Switch – When engaged, the BRIGHT switch adds a subtle
top boost or presence to your signal. When in the NORM position, the top boost is
defeated.
CONNECTIONS
INPUT Jack – Plug the output of your guitar, effects pedal or any other
instrument into the INPUT jack using a standard ¼” instrument cable. The input
impedance presented at the INPUT jack is 1 MΩ.
SEND/LINE OUT Jack – The SEND/LINE OUT jack outputs the Howitzer’s
preamp section. Connect SEND/LINE OUT to the beginning of your FX loop or use
it as a direct output.
The SEND/LINE OUT jack is post preamp but before the VOL knob. If used as a
line output—with nothing plugged into the RETURN jack—sound will still be
produced from the speaker connected to the OUTPUT 8-16 Ω jack. The output
impedance of the SEND/LINE OUT jack is 470Ω.
RETURN Jack – The RETURN jack connects directly to the power amp section
of the Howitzer. Plug your FX loop output into the RETURN jack.
The RETURN jack can also be used as a direct input into the power amp. Plug
directly into the RETURN jack to bypass the Howitzer’s preamp section. When
using the RETURN jack as a direct power amp input, the preamp section will not
effect the tone. The VOL knob still controls the overall loudness of the amp and
the BRIGHT/NORM switch provides a slight high-end boost to the Return signal.
The input impedance presented at the RETURN jack is 1 MΩ.
OUTPUT 8–16Ω Jack – Connect the 15Watt Howitzer’s OUTPUT jack directly
to a speaker cabinet with impedance of 8Ω Ω – 16 only.
24VDC/1.0A POWER Jack – See the following page for information on
powering your 15Watt Howitzer.
N & SOTES PECIFICATIONS
• Audio input impedance at INPUT and RETURN jack: 1MΩ
• Audio output impedance at SEND/LINE OUT jack: 470Ω
• Output power at OUTPUT 8-16Ω Ω jack: 15W at 8
• Current draw: 1A at 24.0VDC
