22500

Dual Stereo Looper

Congratulations on your purchase of the Electro-Harmonix 22500 Dual

Stereo Looper. Although the 22500 has a compact footprint it is loaded

with numerous powerful features, including:

• Dual Stereo Loops with either independent or locked loop lengths

• Sequential Looping enables verse/chorus switching

• Parallel Looping allows simultaneous playback of two loops

• Selectable Microphone input with adjustable gain and Phantom Power

• Reverse and Octave functions at the touch of a button

• Undo-Redo your last overdub

• Overdub with adjustable feedback amount

• Create loop lengths that are completely free-form, locked to each other

or quantized to internal rhythms

• 100 Loop Banks per SD Card, each bank containing up to 2 loops

• Rhythm Guide with 16 built-in drum loops

• Footswitch selectable for All Stop, Tap-Tempo, or Rhythm Start/Stop

• USB Port enables backup/restore to PC or MAC

• Includes high capacity SD Memory Card for up to 12 hours of loop time

• Optional external Bank-Up/Down Foot Controller (sold separately)

• 9.6VDC/500mA power supply included

WARNING:

Your

22500

comes equipped with an Electro

Harmonix 9.6

500mA power supply. The 22500 requires 240mA at 9VDC with a center negative

plug and does not accept batteries. Using the wrong adapter may damage your

unit and void the warranty. Please do not exceed 10.5VDC on the power plug.

22500 QUICK START GUIDE

MODES Selecting / Types / Use−

MODE SELECTION & KNOB: OVERDUB:

TRIGGER:

R TYPE:

R LEVEL:

ERASE:

• Press and release the MODE knob

to select or deselect modes.

• When a particular mode LED is lit

solid, the mode is selected. Turn

MODE to adjust the value seen on

the display.

• If a mode LED is blinking, no mode

is selected. Turn the MODE knob to

scroll through all the modes.

• When you land on the MODE you

want to adjust, press and release the

MODE knob to enter into the mode.

The selected LED goes solid.

• At this point you can turn the MODE

knob to adjust its value. After doing

so, press and release the MODE

knob to exit out of the mode. The

selected mode LED blinks.

BANK mode allows you to select the

current loop bank. Each SD Card can

hold up to 100 banks, numbered 00

to 99.

LOOP mode is where you change

settings for Loop Lock/Freeform,

Loop Lock Multiply, Quantize,

Parallel/Sequential, and 1-Shot.

LOOP:

Very much like a Feedback control on

a delay effect, the OVERDUB value

sets the loop audio volume loss for

each pass while overdubbing. Set to

100 so the loop never loses volume.

Trigger the start of loop recording

automatically when you start playing

your instrument. Use TRIGGER

mode to set the threshold level. As

the Trigger threshold is set higher,

less signal volume is required to

trigger loop recording.

R(hythm) TEMPO mode displays and

allows adjustment to the tempo. The

displayed tempo is in BPM and

represents the current tempo for

Loops A and B and the Rhythm loop.

R(hythm) TYPE mode displays and

allows you to select a Rhythm. The

22500 comes supplied with 16

Rhythms from the factory. You may

also add your own Rhythm loops, see

page for more information.

R(hythm) LEVEL mode sets the

volume of the Rhythm loop. The

range is 0 to 100.

R LEVEL has a second page which

displays “COPY”. COPY mode

initiates the copy of the factory

default rhythms to the SD Card.

ERASE mode erases either Loop A or

Loop B or both loops simultaneously.

See pages - for an in-depth

explanation of modes.

16 23
