DELUXE MEMORY MAN - 1100 TT

TAP TEMPO ANALOG DELAY with FX LOOP,

MODULATION and EXPRESSION PEDAL

CONTROL

Congratulations on your purchase of the Electro-Harmonix Deluxe

Memory Man 1100- (1100- ). The 1100- is designed with high TT TT TT

quality bucket brigade ICs for an analog delay sound equal to the

original Deluxe Memory Man. In addition to Tap Tempo control of the

delay time, the 1100- also includes delay time modulation, an effects TT

loop in the feedback path of the delay block, an input gain control, tap

tempo divide and optional expression pedal control over five parameters:

Delay Time, Feedback, Modulation Depth Rate and Blend. The 1100- , TT

is true bypass.

-CONTROLS and INDICATORS -

KNOBS

DELAY Knob –Sets the delay time from ms to m As you turn the 52 1100 s.

DELAY knob clockwise, the delay time will increase. If you tap in the delay time,

the DELAY knob’s setting will be ignored until you move it again. If you turn the

DELAY knob after tapping in a delay time, the DELAY knob’s setting will

supersede the last tap tempo that was entered. Turning the DELAY knob, while

listening to your echoes, will bend the pitch of your notes. The DELAY knob can

also be used to set the maximum delay time for expression pedal control. N.B.:

the TAP DIVIDE button functions have no effect on the DELAY knob; pressing

TAP DIVIDE when the DELAY knob controls the delay time does not change the

delay time.

WARNING: Your Deluxe Memory Man - comes equipped with an 1100 TT

Electro-Harmonix 9.6DC-200BI power supply (same as used by Boss® &

Ibanez®: 9.6 Volts DC 200mA). The Deluxe Memory Man w/ Tap Tempo

requires 200mA at 9VDC with a center negative plug. The 1100- does not TT

take batteries. Using the wrong adapter may damage your unit and void the

warranty.

FEEDBACK Knob Controls the amount of signal that is circulated from the –

output of the delay block to its input. Turning the FEEDBACK knob clockwise

increases the number of echoes. Setting the FEEDBACK control to its maximum

clockwise position will cause the - to run-away, or self-oscillate. 1100 TT

Alternatively setting the FEEDBACK knob to its minimum position will yield just

one echo or repeat for each of your notes The FEEDBACK knob is also used to .

set the maximum amount of feedback for expression pedal control.

DEPTH Knob –Sets the amount of modulation that is applied to the delay time.

As you turn the DEPTH knob clockwise, the amount of modulation increases.

Turn the DEPTH down to the full Counter-Clockwise (CCW) setting to turn

modulation off. The DEPTH knob is also used to set the maximum amount of

modulation for expression pedal control.

RATE Knob – The RATE knob’s main function is to set the rate or speed of

modulation. As you turn the RATE knob clockwise the modulation rate will

increase. The DEPTH knob must be set above the full CCW position to hear the

RATE knob change modulation speed. Additionally the RATE knob sets the

maximum rate of modulation for expression pedal control.

GAIN Knob – Sets the input gain for the - . As you turn the GAIN knob 1100 TT

clockwise, the input gain increases The total gain range is - dB to +20dB. The . 13

gain block is the first stage that the input signal goes through in the circuit. Both

the dry and wet signals mixed by the BLEND knob go through the gain block.

BLEND Knob –The BLEND knob is a wet/dry control allowing you to vary the

mix between direct and delayed signals at the OUTPUT jack of the - . Set 1100 TT

the BLEND knob to the full clockwise position for an output that is 100% wet. Set

BLEND to full counter-clockwise for an output that is 100% dry. Setting BLEND

anywhere in between will mix the wet and dry signals together. Additionally the

BLEND knob sets the maximum wet/dry mix for expression pedal control.

SWITCHES & LEDs

BYPASS Footswitch and STATUS LED – The BYPASS FSW is used to toggle

the - between effect mode and true bypass mode. The red STATUS LED 1100 TT

will light up when in effect mode and turn off in bypass.

EXP. MODE Button and LEDs – The EXP. Mode button cycles through the six

available expression modes: BLEND, RATE, DEPTH, FEEDBACK, DELAY and OFF.

Each time you press the EXP. MODE button the - will advance to the next 1100 TT

expression mode LED. An expression pedal must be plugged into the EXP. PEDAL

jack to make use of these modes. A lit LED for one of the modes indicates the

expression pedal will control that parameter. For example, if the RATE LED is lit,

the expression pedal controls the modulation rate, from slowest (expression

pedal = toe up), to the RATE knob’s current setting (expression pedal = toe

down). When no EXP. MODE LEDs are illuminated the expression pedal is

disabled while it remains plugged into the - . The setting for the EXP. 1100 TT

MODE is saved and recalled when power cycling.
