Side 1/12
1
EPITOME
MULTI-EFFECT PEDAL featuring
MICRO POG, STEREO ELECTRIC
MISTRESS, & HOLY GRAIL PLUS
Congratulations on your purchase of the Electro-Harmonix Epitome multi-effect
pedal. The Epitome combines three of the most popular and advanced Electro-
Harmonix pedals: the Micro POG octave generator, the Stereo Electric Mistress
flanger/chorus pedal, and the Holy Grail Plus reverb unit.
The effects on the Epitome can function independently, together, or can interact
with each other in a unique manner by engaging SHIMMER mode. The three
separate footswitches, one for each section, allow for individual control over
which effect is on or off. Each effect has its own dedicated knobs and switches,
all of which are tweakable at any moment; there are no menus or hidden
settings to scroll through.
Shimmer mode reroutes the Epitome’s effects in a way that would not be
possible with the three separate effects pedals. In Shimmer mode, the octaves
from the Micro POG are separated from the Dry signal allowing the Holy Grail
Plus to only reverberate the octaves. Additionally, Flerb mode in the Holy Grail
Plus changes to an echo effect, where the Micro POG is placed in the feedback
path of the delay to create echoes that change octaves with each repeat.
Using the Epitome like having three separate effects pedals on your is
pedalboard, without the need for additional cables or separate power supplies,
all in the footprint of one medium sized pedal. The Epitome’s footprint is 5.75” x
4.75”.
WARNING: Your Epitome comes equipped with an Electro-Harmonix
9.6DC-200BI power supply (same as used by Boss® & Ibanez®: 9.6
Volts DC 200mA). The Epitome requires mA at 9VDC with a center 185
negative plug. The Epitome does not take batteries. Using the wrong
adapter may damage your unit and void the warranty.
2
- CONTROLS, INDICATORS, & I/O -
MICRO POG SECTION
DRY Knob - Controls the output volume of the DRY signal. The DRY signal is
the signal present at the INPUT jack. As this knob is turned clockwise, the
volume of the DRY signal increases. If the Holy Grail Plus is set to ECHO Mode,
the DRY knob sets the delay’s feedback for the dry signal. See page 5 for more
info on the ECHO mode.
SUB OCTAVE Knob - Controls the output volume of the SUB OCTAVE signal.
The SUB OCTAVE signal is one octave below the original input signal, half the
frequency of the input signal. As this knob is rotated clockwise, the volume of
the SUB OCTAVE signal will increase. If the Holy Grail Plus is set to ECHO Mode,
the SUB OCTAVE knob sets the delay’s feedback for the SUB Octave signal. See
page 5 for more info on the ECHO mode.
OCTAVE UP Knob - Controls the output volume of the OCTAVE UP signal. The
OCTAVE UP signal is one octave above the original input signal or twice the
frequency of the original input signal. The volume of the OCTAVE signal UP
increases as this knob is rotated clockwise. If the Holy Grail Plus is set to ECHO
Mode, the OCTAVE UP knob sets the delay’s feedback for the upper octave
signal. See page 5 for more info on the ECHO mode.
STEREO ELECTRIC MISTRESS SECTION
RATE Knob - This knob controls the speed or rate of the LFO signal that
modulates the flanger. It also controls the rate of the Chorus effect. Turning the
RATE knob clockwise increases the rate of modulation. When the RATE knob is
turned down, between fully counter-clockwise and the 10 o’clock position, the
Stereo Electric Mistress will enter Filter Matrix mode. In Filter Matrix mode the
LFO signal is disconnected from the Flanger and Chorus so that you can
manually modulate the Flanger/Chorus by turning the RATE knob. Keep the
RATE knob below 10 o’clock to keep it in Filter Matrix mode.
FLANGER Depth Knob - Controls the amount of Flange that is mixed with the
direct signal. The more you turn the knob clockwise, the more pronounced the
flanger effect will be. Turning the FLANGER knob down completely bypasses the
flanger.
CHORUS Depth Knob - Controls the amount of the chorus sound. The more
you turn the knob clockwise, the more pronounced the chorus effect will be.
Turn the CHORUS knob down completely to bypass the chorus effect.
Hint - The Flanger and Chorus effect can be used together. While each individual effect
produces rich sweeping textures, together they can produce dramatically different and
warm soundscapes that are not available when one effect is used alone. page 5 for See
more information on the Stereo Electric Mistress sounds.
