GRAPHIC FUZZ

-OPERATING INSTRUC - TIONS

The is an operated unit which has several unique features GRAPHIC FUZZ AC

including graphic equalization which are not found on any other fuzz/

distortion/overdrive products on the market today.

The GRAPHIC FUZZ has been specially designed for low noise/low hum operation. An

LED indicator shows when the effect is in either the ON or modes. This unit BYPASS

is sensitive to the dynamics of your playing, that is, the effect wil be louder when you

play harder and will be quieter when you strum or pick more softly.

To operate, plug the unit into a standard AC outlet. Plug your guitar into the INPUT

jack. Plug your amplifier into the jack. OUTPUT

Six slide pots allow you to adjust the output level by as much as + or 15 dB in the –

125 Hz, 250 Hz, 500 Hz, 100 Hz, 2000 Hz, and 4000 Hz frequency bands. This allows

for great tonal flexibility.

The small switch at the top of the unit makes the GRAPHIC FUZZ a ON-FUZZ-OFF

dual purpose effect. In the ON position, the fuzz effect is on. In the OFF position, the

fuzz is off and the unit can be used as a graphic equalizer using the six slide pots

already mentioned.

The slider controls the output volume level. VOLUME

The envelope shaping capabilities of the unit are controlled by two slide pots labeled

DYNAMICS SUSTAIN and . The DYNAMICS slider controls the sensitivity of the unit

to your playing style. When the slider is down, the unit behaves like a conventional

fuzz box with the output volume at a more or less constant level. As the slider is

moved up, the unit becomes increasingly more sensitive to the dynamics of your

playing. It will get louder as you play harder and will get softer as you play more

gently. The SUSTAIN slider is only effective when the DYNAMICS slider is up. It

controls how long a note is sustained. Maximum sustain is achieved when the Sustain

slider is all the way up.

The footswitch allows you to control the amount of distortion in the OVERDRIVE

output signal.

The footswitch allows you to bypass the entire unit without having to physically CUT

disconnect it. The red LED will light up when the unit is engaged and will go off when

the unit is bypassed.

TECHNICAL SPECIFICATIONS:

Power: -120V AC, 50-60 Hz 95V

Input Impedance: 200K ohm

Input Level: 200 mV to 1V rms

Output Impedance: 1K ohm

Output Level: 1Vnom. 7V max.

Overdrive Gain Range: 28 dB

Sustain Time Range: 100ms to 10 sec

Equalizer Controls: 15 DB 

Only use the US96DC-200BI power supply adaptor that was supplied with the

unit. Use of any other adaptor will damage the unit and void the warranty.

- WARRANTY INFORMATION -

Please complete and return the enclosed warranty card within 10 days of purchase.

Electro-Harmonix will repair or replace, at its discretion, a product that fails to

operate due to defects in materials or workmanship for a period of one year from

date of purchase. This applies only to original purchasers who have bought their

product from an authorized Electro-Harmonix retailer. Repaired or replaced units will

then be warranted for the unexpired portion of the original warranty term. If you

should need to return your unit for service within the warranty period, please include

a brief description of the problem as well as your name, address, telephone number,

copy of your receipt, and a check or money order for shipping and handling:

United States - $12

Canada - $15

Europe and other countries - $25

Ship to:

Europe

EHX CUSTOMER SERVICE JOHN WILLIAMS

ELECTRO-HARMONIX ELECTRO-HARMONIX UK

c/o NEW SENSOR CORP. 13 CWMDONKIN TERRACE

47-50 33RD STREET SWANSEA SA2 0RQ

LONG ISLAND CITY, NY 11101 UNITED KINGDOM

Tel: - - Tel: +44 179 247 3258 718 937 8300

Email: info@ehx.com Email: electroharmonixuk@virginmedia.com

To hear demos on all EHX pedals visit us on the web at www.ehx.com

Email us at info@ehx.com
