Side 1/4

KNOCKOUT

Attack Equalizer

Congratulations on your purchase of the Electro-Harmonix KNOCKOUT

ATTACK EQUALIZER! The Knockout is one of the most specific and

powerful tonal adjustment systems that you will ever use. What does that

mean exactly? The KNOCKOUT consists of one Low-Pass filter, one High-

Pass filter and a direct dry signal… each with its own knob. When combined

they yield a very specific and focused tonal sculpture. Extreme and very

specific adjustments are not only simple to set up but also yield a very rich

and defined tone that cannot be obtained from an amplifier or much more

complex equalizing systems. The curves of the filters were specifically

selected for their musical value. They may be used independently to

reinforce a specific area but their real value can be heard when all three are

used together. Get ready for the professional sound that you have been

waiting for.

- CONTROLS -

LOW Knob –The LOW knob is a volume control for the low or bass

frequencies. The further you turn the LOW knob clockwise, the louder the

low frequencies will be. The LOW knob controls the output volume from the

Knockout’s 7-Pole Low-Pass Filter. The low pass filter has a fixed cutoff

frequency of 85 Hz. The LOW knob is responsible for contouring the bottom

end in relation to the total sound.

DRY Knob – The DRY knob is a volume control for the signal present at the

Input Jack. The output volume of the dry signal will increase as this knob is

rotated clockwise. Use the DRY knob in conjunction with the LOW and HIGH

knobs to create your tone.

HIGH Knob – The HIGH Knob is a volume control for the high or treble

frequencies. The further you turn the HIGH knob clockwise, the louder the

treble frequencies will be. The HIGH knob controls the output volume from

the Knockout’s 6-Pole High-Pass Filter. The high pass filter has a fixed cutoff

frequency of 6.5kHz. The HIGH knob is responsible for contouring the high

end to the total sound.

STATUS LED – This LED indicates the current state of the unit. When the

LED is lit up, the box is in effect mode. When the LED is off, the box is in

TRUE BYPASS mode.

INPUT Jack – This ¼” jack is the audio input to the KNOCKOUT. The input

impedance presented at the Input Jack is 390 k . 

OUTPUT Jack – This ¼” jack is the output signal that is sent to your

amplifier, another pedal or to your recording setup.

- OPERATION NOTES -

The KNOCKOUT was designed to work with any Instrument level signal from

any instrument or voice. The simplicity of the setup is brilliant. It is basically

a balancing act, which revolves around the Dry signal. Both the LOW and the

High knobs deal with radical amounts of gain. The Dry signal is like the

mediator between both filters. Each element is critical to the overall sound. It

pays to experiment in you search for the right setup for each situation. You

will come across many interesting textures that you may want to write down

and store for recall.

Remember that there is a value in each pot. The and DRY, LOW HIGH

elements may each be used independently or in any combination. With the

KNOCKOUT, a little adjustment goes a long way.

Power, from the internal 9-volt battery or external battery eliminator, is

activated by plugging into the input. The input cable should be removed

when the unit is not in use to avoid running down the battery.

The optional 9V power supply from Electro-Harmonix is US96DC-200BI

(same as used by Boss ™ & Ibanez™). 9.6 volts/DC 200ma. The barrel

connector on the front of the Knockout is for the 9-volt battery eliminator

capable of delivering a minimum of 50 mA of current at 9VDC. The inner ring

of the 9-volt battery eliminator must be negative, the outer ring positive. The

unit’s battery may be left in or taken out when the eliminator is in use.
