STEREO POLYPHASE

PHASE SHIFTER

Congratulations on your purchase of the Stereo Polyphase, an envelope

follower and LFO controlled phase shifter. The Stereo Polyphase is a

spectacular phase shifter that uses optocouplers to produce a smooth,

liquidy tone that can elevate your playing out of this world. Unlike most

phase shifters, the Stereo Polyphase FEEDBACK control gives you the

ability to vary the sound of the phase shifter, so that you have the final say

on the character of the phase shifter’s tone.

The Stereo Polyphase allows for optimal user control in three modes of

operation. In ENV mode the Stereo Polyphase is a phase shifter controlled

by an envelope follower. In LFO mode the Stereo Polyphase is a phase

shifter controlled by a low-frequency oscillator. In EXP mode use an

expression pedal (not included) to control the phase shifter. You may also

use an expression pedal in LFO mode or in ENV mode to control the range

of the phase shifter. Hook up the Stereo Polyphase in stereo (each output

to a separate amp/mixer channel) for a broad stereo image.

— — POWER

— — CONTROLS

FEEDBACK Knob Controls the amount of signal fedback from the output of the phase –

shifter circuit back into the input of the phase shifter circuit. As you turn the feedback control

up, the phase shift effect will sound more pronounced and even sound ‘pe ky’ at high settings. a

The FEEDBACK knob is always active.

MODE Knob – When set to ENV the phase shifter is controlled by an envelope follower.

When set to LFO the phase shifter is controlled by a low-frequency oscillator. When set to

EXP the phase shifter is controlled by an expression pedal (not included).

WARNING:

Your unit comes equipped with a 24 Volt/100mA AC external power

adapter.

Use only the power adapter supplied

, and make sure it is appropriate to

your location (USA, Europe, Japan, Australia). Use of the wrong adapter can cause

damage to the unit or to you, and will void the warranty. Connect the included

24VDC/100mA AC Adapter to the Power Jack, located at the top-center of the Stereo

Polyphase.

GAIN Knob/OVERLOAD LED –Active ONLY in ENV mode. Controls the sensitivity of

the envelope follower circuit. In ENV mode, an envelope follower controls the phase shifter.

This means that the amplitude of the input signal (your instrument) will determine the

response of the phase shifter. Use the GAIN knob to set the amplitude of the envelope

follower circuit. When the output of the GAIN knob exceeds the maximum amount of phase

shift, the OVERLOAD LED will light up. When you rst begin using the ENV setting, we

suggest you turn the GAIN knob up enough so that the OVERLOAD LED briey lights up on

most of your notes. Please note the OVERLOAD LED may light up when the mode knob is

set to either LED or EXP modes but the envelope follower will not modulate the phase shifter

in these modes.

START Knob – Sets the START point of the phase shifter’s range.

STOP Knob –Sets the STOP point of the phase shifter’s range.

A Note on RANGE of modulation:

The dierence between the START and STOP knobs determines the RANGE of modulation.

For maximum RANGE set and START knob to minimum and the STOP knob to maximum,

or vice versa. As you move the START and STOP knobs closer together, you will decrease the

RANGE of modulation. These knobs can also be used together to voice the phase shifter. If

you put both knobs at their minimum positions and turn them simultaneously to the maximum

position, while playing, you will hear the range of sounds available to you.

A Note on DIRECTION of modulation:

The relative position of the START and STOP knobs also determines the DIRECTION of

modulation. For example, when using the ENV setting, if START is below STOP, when you

pluck a note the phase shifter will jump up from the START position to the STOP position,

then slowly descend back to the START. The opposite will happen if STOP is set below

START.

RATE Knob – Active in LFO mode only. Controls the speed of modulation by adjusting the

LFO’s rate of oscillation.

Toggle Switc h –In ENV mode the toggle switch determines the speed at which the phase

shifter reacts to your playing. When set to FAST the envelope follower will respond quickly to

your playing. When set to SLOW the envelope follower will respond slowly to your playin g.

In LFO mode the toggle switch determines the shape of oscillation. In the UP position the

LFO will produce a triangle wave, giving the phase shifter a smooth modulation from the

START to STOP settings. In the DOWN position the LFO will produce a square wave

oscillation and the phase will jump between the START and the STOP settings.
