STEREO TALKING MACHINE

Vocal Formant Filter

Congratulations on your purchase of the Electro-Harmonix Stereo Talking Machine, a

highly customizable envelope-controlled digital vowel filter. The Stereo Talking

Machine (STM) utilizes multiple moving filters to turn your guitar in a growling,

gurgling, snarling monster.

- Special Features of the Stereo Talking Machine -

• Nine selectable voices: Seven human vowel filter combinations, a classic wah-wah filter,

and the legendary dual band filter of the EHX Bassballs

• Ability to reverse the sweep of each voice, doubling your sound options

• Attack/Decay knobs to separately control the rise and fall speeds of the filter sweep

• Sensitivity control to adapt the effect’s response to your playing style

• Stereo Outputs for true stereo imaging and panning

• Expression Pedal option to manually control filter sweep

• Programmable distortion to make your guitar really growl

• Programmable internal LFO for automatic filter modulation

• Effects Loop side-chain

• 9 fully programmable presets

– – VOICE DESCRIPTIONS

Each voice option in the STM sweeps between two distinct filter settings, mimicking

the way a human mouth moves to form particular vowel sounds. The direction of the

filter sweep can be reversed using the SENSITIVITY knob.

Sensitivity +

Sensitivity -

F d ee

Cer l ea

EE ER-

Hurry

Peer

AH-I

Glide

Papaya

AH- OO

Fact l ua

N ow

I-A

H ght ei

B net ayo

E ra

F ar

OW- EE

F d eu

Chewy

The WAH and BB voice options simulate a classic wah-wah pedal filter and the EHX

Bassballs filter respectively.

WARNING: Your Stereo Talking Machine comes equipped with an Electro-

Harmonix 9.6DC-200 power supply (same as used by Boss® & Ibanez®: 9.6 Volts

DC 200mA / Center Negative). The Stereo Talking Machine requires 185mA at

9VDC with a center negative plug. The STM does not take batteries. Using the

wrong adapter may damage your unit and void the warranty.

– QUICK START GUIDE –

This Quick Start Guide will help you get started using your Stereo Talking

Machine immediately. For detailed information on all of the Stereo Talking

Machine's features and functions, please refer to the rest of this owner’s manual.

Setup

1. Using an unbalanced instrument cable, plug the output of your instrument

into the INPUT jack on the right side of the STM.

2. Connect an unbalanced instrument cable from the MONO/L output jack on

the left side of the STM to the input jack of an amplifier.

3. Connect the included AC Adaptor to a wall outlet and plug its barrel

connector into the 9V power jack at the top of the STM.

4. Turn on the amplifier and turn up your instrument’s volume. Press the

BYPASS footswitch so that the STATUS LED is lit; the STM is now activated.

A. Preset Settings

Press and release the PRESET footswitch to cycle through the STM’s preset

settings. Each factory preset has been carefully prepared to utilize the deep

sonic capabilities of the STM. You may overwrite the factory presets with

your own sound creations whenever you like.

B. Manual Settings

1. To begin, turn the STM’s knobs to the following positions:

BLEND:

Full Clockwise

VOICE:

Full Clockwise (OW- EE)

ATTACK:

12 o’clock

DECAY:

12 o’clock

SENSITIVITY:

1 o’clock

2. Ensure the PRESET LED (bottom left) is off. If it is on, turn the white

PRESETS knob clockwise until the PRESET LED shuts off. This action

deactivates the currently loaded preset.

3. Ensure the auxiliary functions (indicated by the leftmost orange LED) are

off. If they are on, press the white PRESETS knob to deactivate them.

4. Play your instrument at the intensity you would like to trigger the filter

sweep. While playing, turn up the SENSITIVITY knob until the Sweep Level

LEDs light up completely after each note you play.

5. To change the sweep speed of the filters, adjust the ATTACK and DECAY

knobs.

6. Adjust the VOICE knob to try different voicings or filter types.

– – SWEEP LEVEL LEDs

The two rightmost orange LEDs under the PRESETS knob indicate the position

of the filters at any given moment. When the LEDs are both unlit, the filters are

at their rest position (ex: set to OW for the positive OW-EE voice). When the

LEDs are both lit, the filters are in their maximum position (ex: set to EE for the

positive OW-EE voice). The LEDs sweep on and off, visually representing the

audible sweep of the filters as the input signal triggers the envelope sweep, the

expression pedal manually moves through the filters or as the internal LFO

automatically modulates the filters.
