Wiring diagram:
230 V/ 50 Hz
L
N
max.
16 A
L N
FUNCTION BUTTON ( R ) :
SHORT PRESSING (for about 1.5s)
- coding.
LONG PRESSING (for about 5s)
- RESET deleting the code from the
memor y (the LED1 and LED2
flash simultaneously).
WS301 is suitable for switching on electric equipment. Transmitters, se-
ries WS3xx, can be used as a remote control (WS310-stick, WS320-
door contact transmitter, the current channel list on www.elbock.cz).
To be installed in internal rooms. Do not locate near power lines! The device
can only be installed by a person with adequate qualification!
The installation must be executed in a voltage-free state!
1. Switch off the main circuit breaker and connect it to the receiver according
to the diagram;
2. Switch on the main circuit breaker; the LED1 lits up on the receiver; BASIC MODE;
3. Pressing the FUNCTION BUTTON for about 5 sec, will erase the memory
(LED1 and LED2 simultaneous long flash), RESET MODE;
4. Pressing the FUNCTION BUTTON for about 1.5 sec, will get the receiver
into a setting mode for SWITCH ON (LED2 flashing);
5. Press the appropriate button, based on a transmmitter, for transmitting of
a code for SWITCH ON, LED1 flashing and receiver waits for SWITCH OFF.
6. In next step press the same button (or another), on the transmitter, for
transmitting of code for SWITCH OFF;
WS301
7. For setting COUNTING MODE proceed in a similar way;
(!When setting other functions do not use RESET - otherwise, the previ-
ous settings will be erased, it is possible to set up to 16 control buttons!)
8. Pressing the FUNCTION BUTTON for about 1.5 sec, will get the receiver
into a setting mode for SWITCH ON (LED2 flashing);;
9. Press the appropriate button, based on a transmmitter, for transmitting of
a code for SWITCH ON, LED1 flashing and receiver waits for SWITCH OFF.
10. Wait for 20sec, then the receiver is on SETTING TIME MODE (LED1 flashing
and LED2 lit); (!Setting range of time is 1s to 8 hours!)
11. Start to count down of the time,for which the device should be switched on. After the
expiry of the time you have requested press the transmitter button to SWITCH OFF.
