DESCRIPTION
- New amplifier with unique FONESTAR design, high reliability and precision during playback.
- An exceptional finish with a brushed aluminium front and high contrast high visibility LCD display.
- Stylish and practical design, can be integrated into any furniture, whether for home or professional use.
- A wide range of playback options (Bluetooth
®
, USB/MP3 y FM) and auxiliary audio inputs which make it
highly versatile and adaptable.
- Two microphone inputs to use as Karaoke and sing over your favorite songs.
CONTROLS AND FUNCTIONS
FRONT PANEL
POWER CONSUMPTION: 90 W
AC~230 V/50 Hz
SPEAKER OUTPUT (4-16 Ω)
15 + 15 W RMS
1
2 3 4 5 7 8
9
10 11 12 13 14 15 16
6
1.- POWER: on/off switch for the amplifier.
2.- {: a long press decreases the volume of the player. A short press in Bluetooth
®
or USB mode skips to
the previous audio track; in FM mode it skips to the previous stored frequency.
3.- 12: in Bluetooth
®
or USB mode it plays/stops audio playback; in FM mode, it auto-stores all detected
frequencies with sufficient signal quality.
4.- }: a long press increases player volume. A short press, in Bluetooth
®
or USB mode skips to the next
audio track, in FM mode skips to the next stored frequency.
5.-
: in USB mode, allows you to select the repeat mode: ONE OR ALL.
6.- Player information display.
7.-
: in USB mode, activates random play (RAND).
8.- MODE: short presses of this button allow you to change the mode on the player to choose the desired
audio source: Bluetooth
®
, aux, FM radio, or USB device.
9.- VOL: headphone output volume control.
10.- USB port for audio file playback.
11.- ECHO: control that adds an echo or reverb effect to the MIC 1 and MIC 2 microphone signal.
12.- MIC TONE: adjusts the equalization of MIC 1 and MIC 2 signals, allowing you to enhance or attenuate
frequencies to improve sound.
13.- MIC VOL: control that regulates the volume of MIC 1 and MIC 2 microphone inputs.
14.- BASS: boosts/attenuates low frequencies.
15.- TREBLE: boosts or attenuates high frequencies.
16.- BALANCE: allows to adjust the sound to achieve a balanced result by giving more emphasis to the L
or R channel on the output signal.
