11/17 Model 3500/3500D Page 1 of 5

1455 Kleppe Lane Sparks, NV 89431-6467 (775) 359-4712 Fax (775) 359-7424

E-mail: Info@hawsco.com  website: www.hawsco.com

Model 3500/3500D

Drinking Fountain

INSTALLATION, OPERATION

MAINTENANCE INSTRUCTIONS

No. 2077448 (16)

LIMITED WARRANTY

HAWS warrants that this specific product is guaranteed against defective material or

poor workmanship for a period of one year from date of shipment. HAWS liability

under this warranty shall be discharged by furnishing without charge F.O.B. HAWS

Factory any goods, or part thereof, which shall appear to the Company upon

inspection to be of defective material or not of first class workmanship, provided that

claim is made in writing to Haws within a reasonable period after receipt of the

product. Where claims for defects are made, the defective part or parts shall be

delivered to the Company, prepaid, for inspection. HAWS will not be liable for the

cost of repairs, alterations or replacements, or for any expense connected therewith

made by the owner or his agents, except upon written authority from HAWS, Sparks,

Nevada. HAWS will not be liable for any damages caused by defective materials or

poor workmanship, except for replacements, as provided above. Buyer agrees that

HAWS shall not be liable for general, special, or consequential damages claimed to

arise under the contract of sale. The drinking fountain manufactured by HAWS is

warranted to function if installation and maintenance instructions provided are

adhered to. The units also must be used for the purpose for which they were

intended.

NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,

PROVIDED OR GIVEN BY HAWS.

NOTE TO INSTALLER: Please leave this information with the Maintenance Department.

SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS

MODEL PLEASE CALL:

TECHNICAL SUPPORT: 1-800-766-5612

FOR CUSTOMER SERVICE: 1-888-640-4297

11/17 Model 3500/3500D Page 2 of 5

RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable

wrench, 10" pipe wrench, 5/32” pinned hex key wrench (supplied), 9/16”, 1/2", 7/16” socket

wrench or open- end wrench.

LOCATION OF UNIT: The Model 3500/3500D Drinking Fountain is a wheelchair accessible

drinking water facility. The height dimensions shown, meet current ADA requirements. When

installing this unit, local, state or federal codes should be adhered to. If height other than

shown is required, then dimensions must be adjusted accordingly.

SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6 ATM)

flowing pressure. Where sediment or mineral content is a problem, an inlet filter is

recommended.

PLUMBING CONNECTIONS: Inlet is 3/8“O.D. compression fitting. Waste outlet is female 1-

1/2” slip PVC pipe.

MAINTENANCE: Periodically clean the strainer. Refer to 5874 Series Valve Operation and

Maintenance Sheet for more information.

TROUBLESHOOTING

PROBLEM

REPAIR CHECKLIST

Insufficient bubbler flow.

1a.

Check that inlet screwdriver stop valve is

wide open.

Verify minimum 30 psi flowing supply

pressure.

Clean inlet strainer. See 5874 Series

Valve Manual.

Adjust valve to increase flow. Use front

adjust screw or see 5874 Series Valve

Manual.

General Notes:

Before tightening nut and ferrule assembly, push tubing into fitting until it bottoms out

to ensure correct engagement with O-Ring.

For more information about Haws products, see our website: www.hawsco.com

HAWS

and other trademarks used

in these materials are the exclusive property of Haws Corporation.
