Modular Ice Machine

Item #:

Project:

Qty:

AIA#:

618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com

Cube Dimensions*

* approximate size in inches, image not to scale

Features

• Durable stainless steel exterior

• Flaker - Up to 750 lbs. of ice production per

24 hours

• Cubelet - Up to 653 lbs. of ice production per

24 hours

• Mount two units, side-by-side, in only 44” of floor

space for double the amount of ice production

• 2 second flush cycle every hour

• Flush cycle removes sediment for cleaner ice

• Ultrasonic sensor opening

Advanced CleanCycle24

design

Environmentally friendly R290

hydrocarbon refrigerant

Stainless steel auger with greaseless

bearing

Available on Bins:

• Ambient Temp Range 45 - 100°F

• Water Temp Range 45 - 90°F

• Water Pressure 10 - 113 PSIG

• Voltage Range 108-127V

• If GFCI is required, a GFCI breaker MUST be used

in lieu of GFCI receptacle

Operating Limits

• Icemaker Water Supply Line: Minimum 1/4” Nominal ID

Copper Water Tubing or Equivalent

• Icemaker Drain Line: Minimum 3/4” Nominal ID Hard Pipe

or Equivalent

Water-Cooled Model (Lines Must Be Independent of Icemaker)

• Condenser Water Supply Line: Minimum 1/4” Nominal ID

Copper Water Tubing or Equivalent

• Condenser Drain/Return Line: Minimum 1/4” Nominal ID

Hard Pipe (open drain system) or Copper Water Tubing

(closed loop system) or Equivalent

Plumbing

• Panels easily removed and all components

accessible for service.

• Removable/cleanable air filter (Air-cooled model only)

• Allow 6” (15 cm) clearance at rear and sides, and 24”

(61 cm) clearance at top for proper air circulation and

ease of maintenance/service.

Service

W x D x H

Hoshizaki reserves the right to change specifications without notice.

3 Year Parts & Labor on entire machine. 5 Year Parts on Compressor; air-cooled

condenser coil. Valid in United States, Canada, Puerto Rico and U.S. Territories.

Contact factory for warranty in other countries.

Warranty:

F-822MAK(-C)

F-822M_K(-C)

11/13/25

Item # 13037K

Slim-Line Series

Air-Cooled Cubelet

F-822MAK-C

1/2”

3/8”

3/4”

Top kit may be required. See Bin Spec Sheets. *Two unit application only.

B-1150SS

B-1300SS

B-250SF

B-300SF

B-800SF

B-900SF

B-1500SS*

B-1650SS*

1”

Flaked Cubelet

F-822MAK F-822MAK-C

22" x 24

1/4

" x 26"

F-822MAK

Air-Cooled Flaker

shown on B-500SF bin

B-500SF

B-700SF

Air / Water Temp

Lbs. per 24 hours

Condenser

Model

70°/ 50°F 90°/ 70°F

ICE PRODUCTION

Potable

Gal. per 100 lbs.

Condenser

Gal. per 100 lbs.

Heat

Rejection

BTU/hr.

Voltage

WATER USAGE

90°/ 70°F 90°/ 70°F

ELECTRICAL

90°/ 70°F

kWh Used

per 100 lbs.

Amperage

750

653

F-822MAK

F-822MAK-C

560

525

Air

12.0

N/A

3.95

4.45

20A

9.7A

9.7 A

115V/60/1

6,400

181 / 190

Circuit

Wires

(including ground)

Net / Ship

Weight (lbs.)

Refrigerant

Charge Amount

5.3 oz.

Power cord not included. Must be hard-wired at site.

Volume:

28.5” x 26.75” X 32” 14ft

Shipping: (LxWxH)

Min. Circuit/

Max. Fuse

Size

F-822MAK

F-822MAK-C

shown with 24”

Lancer Dispenser
