Side 1/12

FAST ETHERNET

PoE+ SWITCH

INSTRUCTIONS

MODEL 561075

INT-561075-UM-ML1-0715-01

Important: Read before use. • Importante: Leer antes de usar.

intellinetnetwork.com

ENGLISH

Fast Ethernet PoE+ Switch English

CONNECTIONS & INDICATORS

LEDs

The LED indicators — Power,

PoE, Link, Max — make it

easier to monitor the switch

and its connections. Note:

Only Ports 1-4 can provide

power to a connected device;

all powered devices should

also comply with IEEE 802.3af.

Ports

All ports on the switch support

Auto-MDI/MDI-X functionality,

so crossover cables and uplink ports are not needed for connections to PCs,

routers, hubs, other switches, etc. Cat5/5e/6 UTP/STP cables provide optimal

performance; if a status LED doesn’t indicate a link or activity, check the

corresponding device for proper setup and operation.

Power

Use the power cord to connect to an AC outlet and conﬁrm that the power

LED is lit.

INSTALLATION

The switch includes brackets and screws for optional rack mounting:

1. Disconnect any cables from the switch.

2. Position a bracket over the mounting holes on one side of the switch and

secure it in place with screws (Page 11).

3. Repeat Step 2 on the other side of the switch.

4. Position the switch in the rack and screw the brackets to the rack.

5. Reconnect any cables.

Prior to use, it is recommended that the switch be placed/positioned on a level

surface with at least 25 mm (approx. 1”) of clearance for ventilation; away from

sources of electrical noise: radios, transmitters, broadband ampliﬁers, etc.; and

within 100 m (approx. 328’) of network devices it’s to be connected to.

For speciﬁcations, go to intellinetnetwork.com.

LED Status Operation

PWR On Power on

Oﬀ Check the AC connection; turn the power on

PoE On Port is linked to a PSE/PoE device

(Ports 1-4) Oﬀ No PSE/PoE device is linked

LNK On Valid port connection

Blinking Valid port connection; data transmitted/received

Oﬀ No link established

MAX On The combined power output of Ports 1-4 is at

the 70W maximum

Blinking The combined power output of Ports 1-4 has

exceeded the 70W maximum

Oﬀ The combined power output of Ports 1-4 is

below the 70W maximum

1 2 3 4

1 2 3 4 5 6 7 8

PoE MAX

PWR LNK
