Knog Bilby Manual

Knog Lommelygte Bilby

Læs gratis den danske manual til Knog Bilby (1 sider) i kategorien Lommelygte. Denne vejledning er vurderet som hjælpsom af 22 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 11.5 anmeldelser. Har du et spørgsmål om Knog Bilby, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

BUTTON 1

BUTTON 2

OPERATION

GET STARTED

WHEN LIGHT IS ON WHEN LIGHT IS OFF

CHARGING

ADJUSTABLE

HEADSTRAP

CHECKING BATTERY LEVEL

LOCK

Turn On: Long press of button 1

Turn O: Press and hold both buttons

Bilby comes locked

The silicone strap adjusts with a toggle. Once

you’ve found your size you can set and forget

or adjust on the fly

The reading lights show the battery level. When Bilby is

turned o, quick press any button.

MODES

Short press of button 1 to scroll through modes. The

light will slowly dim to extend runtime, if you wish to

go back to full output of your chosen mode press the

mode button once.

Modes: Spot, Wide, Low, Red, Reading

BOOST MODES

Double click either button to activate boost mode,

the Bilby will power up to maximum.

Button 1 - Spot and low (240 Lm)

Button 2 - Spot and wide (400 Lm)

The light will slowly dim to extend runtime, to boost

to full output double click again.

BRIGHTNESS

Short press of button 2 to scroll through brightness

settings. Brightness: Max, High, Med, Low

TILT FUNCTION

Hold down the button 1 to tilt the light down.

Hold down the button 2 to tilt the light up.

LOW BATTERY

When the battery is low the light output with drop to

increase runtime.

MODEMAKER

The Bilby is compatible with the ModeMaker app to

allow customisation of the light modes. Open Mode

Maker, plug the USB into your computer, drag and drop

the modes that you want and select upload.

CARE & MAINTENANCE

To clean: wipe with cloth, don’t use harsh

chemicals, air dry, don’t sun dry.

WARRANTY

The light is guaranteed for 2 years against

manufacturing defects only.

See the website for more details KNOG.COM

reading lights / battery indicator

Lights will flash while

charging showing the battery

level it has charged to. Four

flashing LEDs indicate it is

fully charged.

If you accidentally press any button when the Bilby is

locked the red light will flash twice.

To lock/unlock: Hold both buttons for 3 seconds. White

light will flash twice to show that Bilby is unlocked. Red

light will flash twice to show that Bilby is locked.

Fully charge the Bilby before the first use.

Pop out the inner pod to access the USB.

Then charge in any USB charge port.

Charge time: 4 hr.

25%

50%

75%

100%

SETTINGS

OUTPUT

(LUMEN)

RUNTIME

(HOURS)

Boost Right High 400 5

Boost Right Low 50 60

Boost Left High 9240

Boost Left Low 8035

Ambient Right High 200 14

Ambient Right Low 10525

Ambient Left High 48 22

Ambient Left Low 7 98

Spot High 200 14

Spot Low 10525

Red High 7 32

Red Low 2 103

Reading High 10 17

Reading Low 2 75

OPERATION BUTTON 1 BUTTON 2

Short Press Change Mode

Change

Brightness

Long Press

Tilt Beam

Down

Tilt Beam

Double Press Boost Mode 1 Boost Mode 2

Press & Hold

both buttons

Turn O

OPERATION BUTTON 1 BUTTON 2

Short Press

Battery

Charge Status

Battery

Charge Status

Long Press

Turn Light

Double Press - -

Press & Hold

both buttons

Lock/Unlock Light

To unlock hold both buttons for 3 seconds

QUICK START GUIDE

BILBY

1. LOW 2. SPOT 3. WIDE 4. RED 5. READING

Pop out left

side of the

light first

(to avoid

damaging

the usb on

right side).

USB

Produkt Specifikationer

Mærke:	Knog
Kategori:	Lommelygte
Model:	Bilby
Bredde:	150 mm
Dybde:	28.5 mm
Højde:	250 mm
Vægt:	90 g
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Lampe type:	LED
Husmateriale:	Silikone
Vandtæt op til:	1 m
Vandfast:	Ja
Antal lamper:	5 Lampe( r)
Opladningstid for batteri:	4 t
Genopladeligt batteri:	Ja
Opladningskilde:	USB
Lommelygte type:	Hovedbånd lommelygte
Lysstrøm:	400 lm
