P/N: 2900-301408 Rev 5 www.kramerAV.com

USER MANUAL

MODEL:

KIT-400

4K Auto-Switcher/Scaler Kit

Kramer Electronics Ltd.

KIT-400 – Contents
i

Contents
Introduction  1
Getting Started  1
Overview  2
Typical Applications  4
Defining KIT-400 4K Auto-Switcher/Scaler Kit  5
Defining KIT-400T  5
Defining KIT-400R  6
Mounting KIT-400  8
Connecting KIT-400  9
Connecting the Output to a Balanced/Unbalanced Stereo Audio Acceptor  10
Connecting to KIT-400 via RS-232  10
Connecting an Occupancy Sensor to the TOGL Pin  11
Wiring RJ-45 Connectors  11
Operating and Controlling KIT-400  12
Using Front Panel Buttons  12
Using Remote Control Switches  12
Setting KIT-400T DIP-switches  13
Tunneling RS-232 data between KIT-400T and KIT-400R  13
Using the OSD Menu on KIT-400R  16
Operating via Ethernet  25
Using Embedded Webpages  28
Browsing Webpages  28
Switching and adjusting Port Signals  30
Defining General settings  31
Configuring Network Settings  33
Defining Time and Date  36
Upgrading the Firmware  37
Setting Authentication  39
Defining Video and Audio Settings  41
Defining Receiver Settings  43
Configuring Device Automation  44
Operating via Room Automation Panel  47
Managing EDID  60
Viewing About Page  65
Upgrading Firmware  66
Upgrading KIT-400T  66
Upgrading KIT-400R  66
Technical Specifications  67
Default Communication Parameters  69
KIT-400R Output Resolution Support  69
Default EDID  69
Protocol 3000  76
Understanding Protocol 3000  76
Protocol 3000 Commands  77
Result and Error Codes  93
