P/N: 2900-301566 Rev 2 www.kramerav.com

USER MANUAL

MODEL:

MV-4X

4 Window Multi-viewer/4x2 Seamless Matrix

Switcher

Kramer Electronics Ltd.

MV-4X – Contents
i

Contents
Introduction  1
Getting Started  1
Overview  2
Typical Applications  3
Controlling your MV-4X  4
Defining MV-4X 4 Window Multi-viewer/4x2 Seamless Matrix Switcher  5
Mounting MV-4X  7
Connecting MV-4X  8
Connecting the Output to a Balanced/Unbalanced Stereo Audio Acceptor  9
Connecting to MV-4X via RS-232  9
Wiring RJ-45 Connectors  9
Operating and Controlling MV-4X  10
Using Front Panel Buttons  10
Controlling and Operating Via the OSD Menu  10
Operating via Ethernet  21
Using Embedded Web Pages  25
General Operation Settings  27
Defining the Matrix Mode Parameters  31
Defining the Multi-View Parameters  34
Defining the Auto-Layout Parameters  40
Managing EDID  41
Defining General Settings  44
Defining Interface Settings  46
Defining MV-4X User Access  47
Defining Advanced Settings  48
Defining OSD Settings  51
Configuring a Logo  52
Viewing the About Page  54
Technical Specifications  55
Default Communication Parameters  56
Default EDID  56
Protocol 3000  59
Understanding Protocol 3000  59
Protocol 3000 Commands  60
Result and Error Codes  71
