WP-2UT/R-KIT Quick Start

P/N:

2 9 0 0 - 3 0 1 4 1 1 QS

Rev:

Scan for full manual

WP-2UT/R-KIT Quick Start Guide

This guide helps you install and use your WP-2UT/R-KIT for the first time.

Go to www.kramerav.com/downloads/WP-2UT/R-KIT to download the latest user manual and check if

rmware upgrades are available.

Step 1: Check in the b what’s ox

WP-2UT USB Transmitter

1 C-USB/AB-6 cable

Installation accessories

1 Bracket set

PT-2UR USB Receiver

1 Power adapter and cord

Frame set and faceplate

1 Quick start guide

Step 2: Get to know your -2UT/R-KIT WP

WP-2UT

Feature

Function

USB 2.0 Type B Port

Connect to USB host.

LINK LED

Flashes blue when a link is established.

ON LED

Lights green when locally powered by the power adapter.

Lights orange when powered by PoC.

Ring Tongue Terminal Grounding Screw

Connect to grounding wire (optional).

SRV (Tx, Rx)

5-pin Terminal Block

Connector (with a

common G pin)

Connect for rmware upgrade.

RS-232 (G, Rx, Tx)

Connect for serial extension (9600 baud rate).

Power Supply 2-pin Terminal Block

Connector

Connect to the power supply. Connect GND to GND, + V to + 12 12V.

LINK POC OUT RJ-45 Connector ◄►

Connect to the LINK IN port on the PT-2UR and to power either the device

via the receiver or the receiver by the device.

PT-2UR

WP-2UT

Feature

Function

LINK LED

Flashes blue when a link is established.

AUDIO OUT 3.5mm Mini Jack

Connect to an unbalanced stereo audio acceptor.

USB 2 Type A Ports (1 to 4)

Connect to USB devices.

Connect directly to the power adapter in order to charge USB PT-2UR

devices.

ON LED

Lights green when locally powered by the power adapter. Lights orange

when powered by PoC.

LINK IN RJ-45 Connector

Connect to the LINK OUT port on the WP-2UT and to power either the

device via the transmitter or the transmitter by the device.

PROG (Tx, Rx)

5-pin Terminal Block

Connector (with a

common G pin)

Connect for rmware upgrade.

RS-232 (G, Rx, Tx)

Connect for serial extension (9600 baud rate).

12V DC Power Connector

Connect to the supplied power adapter.

Step 3: Install the -2UT/R-KIT WP

WP-2UT

Insert the device into the in-wall box (note that rst you need to connect the HDBT cable and power) and connect the parts as

shown in the illustrations below:

US-D Version

DECORA® design or similar frames are

included in US-D models. DECORA® is a

registered trademark of Leviton

Manufacturing Co., Inc.

We recommend that you use any of the

following standard 1 Gang in-wall junction

boxes (or their equivalent):

• : 1 Gang US electrical US-D

junction boxes.

PT-2UR

Install PT-2UR using one of the following methods:

• Attach the rubber feet and place the unit on a at surface.

• Fasten a bracket (included) on each side of the unit and attach it to a at surface

(see www.kramerav.com/downloads/PT-2UT/R).

• Mount the unit in a rack using the recommended rack adapter

(see www.kramerav.com/product/PT-2UT/R).

• Ensure that the environment (e.g., maximum ambient temperature &

air ow) is compatible for the device.

• Avoid uneven mechanical loading.

• Appropriate consideration of equipment nameplate ratings should be

used for avoiding overloading of the circuits.

• Reliable earthing of rack-mounted equipment should be maintained.

• Maximum mounting height for the device is 2 meters.
