The Kramer WP- 301xl Wall Plate
Congratulations on purchasing your Kramer WP-301xl Wall Plate which is ideal for
boardrooms and presentation rooms.
The WP-301xl -is a single gang wall plate insert. EDID information can be stored in the
wall plate by using the FC FC-200 XGA EDID Copier Kramer Tool (see the -200 XGA
EDID Copier User Manual). The WP-301xl is supplied with a power supply.
WP- 301xl Wall Plate US Version
Figure 1 and Table 1 define the US version of the . WP- 301xl Wall Plate
Figure 301xl1: -WP Wall Plate US Version Front and Rear Views
Table 1: - WP 301xl Wall Plate US Version Front and Rear Features
# Feature Function
1 ON LED Lights red when receiving power (when no signal is
detected); lights green when receiving a signal
2 -COMPUTER IN 15 pin HD Connector Connect to the computer graphics source
3 AUDIO IN 3.5mm Mini Jack Connect to the audio source
4 -RJ 45 Connector Connect to the SV SV-551/ -552 Processor/Controller
5 DC IN Power Connector Connect to 12V power supply (supplied free)the
Wiring the Twisted Pair 45 Connector -RJ
The US versions of the wall plates are equipped with RJ-45 terminals. Figure 2 defines the
STP pinout using a straight pin to pin 45 connectors cable with RJ- . For STP cable, cable
shielding must be connected/soldered to the connector shield.
EIA /TIA 568B
PIN Wire Color
1 Orange/White
2 Orange
3 Green/White
4 Blue
5 Blue/White
6 Green
7 Brown/White
8 Brown
Pair 1 4 and 5
Pair 2 1 and 2
Pair 3 3 and 6
Pair 4 7 and 8
Figure 2: - RJ 45 Pinout (U.S.)
WP- s 301xl Wall Plate EU/UK Version
Figure 3 and Table 2 define the version of the EU/UK WP- 301xl Wall Plate.
Destination Belgium and
Germany
Destination England and the
rest of Europe (excluding
Belgium and Germany)
Rear panel view
Figure 301xl3: -WP Wall Plate EU/UK Front and Rear Views
Table 2: - WP 301xl Wall Plate EU/UK Front and Rear Features
# Feature Function
1 ON LED Lights red when receiving power (when no signal is
detected); lights green when receiving a signal
2 - COMPUTER IN 15 pin HD Connector Connect to the computer graphics source
3 AUDIO IN 3.5mm Mini Connector Connect to the audio source
4 Block Terminal Connect to SV-551/SV-552 Processor/Controller (see
Figure 4)
5 2-+12V GND pin Power Terminal Block Connect to 12V power supplythe (included)
6 GROUND Connection Ring tongue terminal and grounding screw
Wiring the U.K. and European Terminal BlocksTP
The European wall plates are equipped with an easy plug-in terminal block to attach the
twisted pair cables. Follow the colors of the color-coded sticker on these terminals for
proper connection of the cable.
Figure 4 defines the pinouts for the TP terminal block.
Figure 301xl4: -WP Wall Plate EU/UK TP Terminal Block Pinouts
Notes:
• Use the connector clips when removing the wires, not when inserting them
• Each wire protrudes 9mm in length from the plastic insulation so that it can be easily connected. To
prevent the wires crossing, be sure that each wire is completely inserted
• The cable ground shielding must be connected / soldered to the connector shield
Grounding the Wall Plate
Use the grounding screw to earth the chassis of the unit to the ground of the building. This
prevents static electricity from interfering with the product’s performance.
Figure 5 defines the grounding screw components.
# Item
1 M3X6 screw
2 1/8" Toothed Lock Washer
3 M3 Ring Tongue Terminal
Figure 5: Grounding Screw Components
To ground the : wall plate
1. Connect the r ongue terminal to the building grounding point wireing t . We recommend
using -a green yellow AWG#18 wire, crimped with a proper hand-tool.
2. Insert the M3x6 screw through the toothed lock washers and the tongue terminal in the
order shown above.
3. Insert the M3x6 screw (through the two toothed lock washers and ring tongue terminal)
into the grounding screw hole and tighten the screw.
WP-301xl
Wall Plate
Installation Instructions
For the latest information on our products and a list of Kramer distributors,
visit our Web site at
Uhttp://www.kramerelectronics.comU
PN:
2900- 000771
Rev:
1
Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E- mail: info@kramerel.com
P/N: 2900-000771 1 REV
