Side 1/3

Lowell strives to provide accurate information while reserving the right to change specications and/or improve manufacturing methods without prior notication.

Spec 1607

Model ACR-SEQ6-2009 Rev. 05-11-21 | pg. 1/3

INTERNAL USE ONLY: PN 24209

DESCRIPTION: Model ACR-SEQ6-2009 power distribution

panel with sequencer features nine NEMA outlets—six switched

(controlled by power switch for sequential activation/deactivation)

and three unswitched (always on). Outlets are clearly marked

to assist the integrator with connections. The panel can also be

activated and deactivated by a remote switch or alarm system

that's connected to the plug-in barrier strip INPUT terminal blocks

in the rear. In addition, there's an OUTPUT terminal block where

remote power controls (RPCs) can be connected and controlled by

this panel. RPC devices would occupy steps ve and six in the

sequence order.

The compact steel chassis with black powder epoxy nish is

designed to occupy minimal rack space with overall dimensions

of 19"W x 9"D x 1.75"H (1U). Termination is via an attached nine

foot power cord with NEMA 5-20P plug.

FEATURES:

• Outlets: Unit features a total of nine 15A NEMA outlets, which are

either switched (controlled by switch) or unswitched (always on).

– Front Outlet:

NEMA 5-15R (1 unswitched single)

– Rear Outlets:

NEMA 5-15R (2 unswitched single, 2 switched single,

2 switched duplex)

• Activation & Sequencing: Front rocker switch with momentary

contacts (normally open SPST) plus rear barrier strip termination

blocks for momentary (normally open) remote switches. Switch

initializes the delayed start up sequence, activating the switched

outlets in four steps, plus any remote power controls (RPCs)

connected to the rear terminal block as steps ve and six. A green

LED ashes while the unit is powering up and holds steady when

the cycle is complete. The switch also initializes the delayed shut

down sequence, deactivating RPCs and outlets in reverse order. A

red LED ashes while the unit is powering down and holds steady

when the cycle is complete. Delay between steps can be adjusted

with a screwdriver (0.5–10 seconds).

• Connections for External Controls: Plug-in barrier strip terminal

block inputs in the rear of the panel allow external controls to

activate and deactivate the switched outlets. The terminal block

output allows this panel to control remote RPC units.

– Left Terminal Block—input from Alarm System: Lock On,

Lock Off, and Switch Lock for alarm system or master control

panel.

– Center Terminal Block–output to Remote Power Control

(RPC): External RPC Series devices can be controlled when

connected to the center terminal block. The connected RPCs

would activate/deactivate as Steps 5 and 6.

– Right Terminal Block—input from Remote Switch: Connect

a remote switch with momentary closure.

• 120VAC, 60Hz, 20A (outlets are 15A)Power Rating:

• EMI/RFI Filter: 19dB@500kHz, 42dB@30MHz

• Circuit Breaker Protection: 20A breaker with reset switch

• Attached 9-ft. cord with NEMA 5-20P plugPower Cord:

• 19"W x 9"D x 1.75"H (1U), 11 lbs.Chassis:

• Certication: ETL Listed in US/Canada (UL60065)

• Country of Origin: Made in the U.S.A. with global components

A&E SPECIFICATIONS: The rackmount power distribution panel

with sequencer and remote power control circuitry shall be Lowell

Model ACR-SEQ6-2009. It shall feature a total of nine NEMA 5-15R

outlets (six switched in rear, two unswitched in rear, one unswitched

in front) and a 20A circuit breaker. A rocker style switch in the front

shall sequentially activate switched outlets in four steps, plus any

remote power control devices connected to the rear terminal block

as steps five and six (RPC Series, ordered separately). When pressed

again, the switch shall deactivate devices and outlets in reverse

order. Color coded LEDs on the front panel shall indicate sequencing

status and the delay between steps shall be screwdriver adjustable

(0.5 to 10 seconds). The panel shall have a power rating of 120VAC,

60Hz, 20A with EMI/RFI ltering. The 19"W x 9"D x 1.75"H (1U)

steel chassis shall have a black powder epoxy nish. Termination

shall be via an attached 9 ft. cord with NEMA 5-20P plug.

AC Power Distribution Panel w/Sequencer: ACR-SEQ6-2009

Rear view

Front view

System

circuit

breaker

NEMA

5-15R single

(unswitched)

Power

status

Power

switch

Sequence &

remote trigger status

Delay

adjust

Made in USA

Power cord

(attached)

NEMA

5-15R single

(unswitched)

NEMA

5-15R single

(switched)

Step 2

NEMA

5-15R duplex

(switched)

Step 4

NEMA

5-15R single

(unswitched)

NEMA

5-15R single

(switched)

Step 1

NEMA

5-15R duplex

(switched)

Step 3

INPUT

from

alarm

system

INPUT

from

remote

switch

OUTPUT

to RPC

Steps

5 & 6

Lowell strives to provide accurate information while reserving the right to change specications and/or improve manufacturing methods without prior notication.

Spec 1607

Model ACR-SEQ6-2009 Rev. 05-11-21 | pg. 2/3

INTERNAL USE ONLY: PN 24209

WIRING: Since switch functions are handled by low-voltage, low-current DC signals, almost any type of wire will work (CAT5, mic line,

intercom wire, speaker wire, or phone wire). Shielding is not required but can be used.

Maximum wire distance: 24 ga.=20,000 ft., 22 ga.=31,200 ft., 18 ga.=76,800 ft.

CONNECTIONS for EXTERNAL CONTROLS: Plug-in barrier strip terminal block inputs allow external controls to activate and

deactivate switched outlets. The terminal block output allows this panel to control remote RPC units.

• LEFT TERMINAL BLOCK – Input from Alarm System (or Master Control Panel):

If required by local building code, facility usage, or the Fire Marshal, system switches can be overridden

and the system controlled by contact closures provided by the re alarm panel or another similarly installed

device. A maintained contact between the ‘Com’ terminal and any of the terminals shown will provide the

following functions. CAUTION: Do not allow alarm system to make more than one of the contacts described

below at the same time—it could cause controller board damage

• Lock OFF: A maintained contact between the ‘Com’ terminal and the ‘Lock Off’ terminal will turn the

system off and keep it off regardless of other switch activations. If the system is already off, it will be

kept off.

• Lock ON: A maintained contact between the ‘Com’ terminal and the ‘Lock On’ terminal will turn the

system on and keep it on regardless of other switch activations. If the system is already on, it will be

kept on.

• Switch Lock: A maintained contact between the ‘Com’ terminal and the ‘Switch Lock’ terminal will lock

the system in its current state, either on or off, regardless of any other switch activations.

• CENTER TERMINAL BLOCK – Output to Remote Power Controls (RPC):

Connect Remote Power Controls to Output 5 and Output 6 in the center terminal block. The maximum num-

ber of RPC units that can be connected is 60 for each output, depending on limits of the electrical panel.

Note: Use RPC Series with classic connections. DO NOT use RPC-P Series with pass-through connections.

• RIGHT TERMINAL BLOCK – Input from Remote Switch:

Connect remotely located momentary closure switch(es). Up to ve switches can be utilized.

Surge Protection Active When Lit (-S models only)

Power

Switch

Activated

Common

+24VDC Out

Switch

Common

+24VDC Out

Surge Protection Active When Lit (-S models only)

Power

Activated

5 6

Wiring to remote power controls

(RPC Series with classic connection)

Alarm System

Interface

Switch

Lock

OFF

Com

RPC

Trigger

5 6

Remote

Switch(es)

Switch

OFF

Ind.

V+

Wiring to momentary switch w/1 LED

requires 3 conductors

Wiring to momentary switch w/2 LEDs

requires 4 conductors
