Condenser miniature microphone with

Cardioid polar pattern

The M 300 is a compact condenser microphone in studio quality. The

frequency response of the transmission factor is practically linear for a

wide range of sound incidence and has a smooth treble boost rising to

about 3 dB between 6 and 10 kHz. The miniature microphone is well suited

for vocal and instrumental soloists. lt permits a lifelike recording also at

various sound incidence, e.g. announcer in synchronous studios, speaker,

blower.

The M 300 is designed for studio applications in radio, television

broadcasting and films for live performance and recording of instruments,

vocals and speech and sound reinforcement in the professional and

semiprofessional market also under adverse acoustic conditions, e.g. in

churches.

A new low-noise integrated hybrid circuit and the transformerless circuit

design guarantee an extremely wide dynamic range by a low equivalent

loudness level and a high reliability in operation.

RFI susceptibility is very low.

The microphone is powered by a 3-pin XLR connector with the C 70

microphone cable. The power supply is provided by 48 V phantom

powering, which is internationally standardized as P 48 in DIN 45596 and

IEC 268-15. A two-channel powering is possible with the N 200 power

supply.

The finish of the miniature microphone is dark bronze.

M 300

M I C R OT E C H G E F E L L

F Ü R S T U D I O - U N D M E S S T E C H N I K

K O N D E N S A T O R M I K R O F O N E

SEIT 1928

MICROTECH GEFELL GMBH GEORG NEUMANN PLATZ D-07926 GEFELL TEL. ++49 (0)36649 / 882-0 FAX ++49 ( 36649 / 882 11- - 0)

INTERNET http://www.microtechgefell.de e-mail info@microtechgefell.de

Delivery

Microphone M 300 in wooden case L x B x H

Order-No. 211101

195 x 68 x 43 mm

dark bronze

Windscreen Order-No.

, black Order-No.

satin nickel Order-No.

, Order-No.

Table stand Order-No.

Order-No.

, anthrazit

600018

21 mm 202307

202342

Double mount, 212332

Gooseneck, black 202324

Power supply 202101

202212

, Ø ,

202328

, 212304

202401

dunkel bronze

Popscreen

Microphone holder

Elastic suspension dark bronze

Connection cable

W 20

PO 70

MH 64

EA 20

N 200

C 70

EH 93

TS 64

TD 93

ME 90

Accessories, optional

MICROTECH GEFELL GMBH GEORG NEUMANN PLATZ D-07926 GEFELL TEL. ++49 (0)36649 / 882-0 FAX ++49 ( 36649 / 882 11- - 0)

INTERNET http://www.microtechgefell.de e-mail info@microtechgefell.de

110°

90°

XY-arrangement

ORTF-arrangement

1 kHz 1 kHz

1 kHz

500 Hz 4 kHz 16 kHz

250 Hz 2 kHz 8 kHz

-10

-30

-20

100 200 500 2k1k 5k 10k Hz 20k

0°

180°

30°

60°

90°

120°

150°

180°

210°

240°

270°

300°

330°

0°

-10

-20

30°

60°

90°

120°

150°

180°

210°

240°

270°

300°

330°

0°

-10

-20

30°

60°

90°

120°

150°

180°

210°

240°

270°

300°

330°

0°

-10

-20

Cardioid

Pressure gradient transducer

40 … 18000 Hz

12 mV/Pa

100 Ω

26 dB

16 dB - A

68 dB

78 dB

147 dB

131 dB

3,3 mA

126 g

130 mm x 21 mm

3-pin XLR connector

goldplated contacts

Polar pattern

Acoustical operating principle

Frequency range

Sensitivity at 1 kHz

CCIR

468-4

DIN EN 60 651

CCIR-weighted

(re. 1 Pa at 1 kHz) A-weighted

Total dynamic range of microphone amplifier

Current consumtion (P 48, DIN 45596, IEC 268-15)

Output connector

Weight

Dimensions (L x )∅

Specifications M 300

Condenser studio microphone with cardioid polar pattern

Output impedance

Signal-to-noise-ratio

XY- and ORTF-stereo recording

Delivery

Mached pair of miniature microphone M 300 for XY and ORTF-stereo recording

in a wooden case L x B x H

211174

MH 64.1, double mount TD 93,

condenser

with microphone holder

Order-No.

195 x 68 x 43 mm

dark bronze

picture 2: ORTF-arrangement

picture 1: XY-arrangement

Certificate

Equivalent loudness level

due to inherent noise

Max. SPL for THD 0,5 %

Polar patterns M 300

Frequency responses M 300
