The MT 71 S studio condenser microphone, equipped with our

reliable large-diaphragm capsule, features outstanding

performance, high sensitivity, and improved signal-to-noise ratio

The MT 71 S guarantees particularly clean and colourless sound

reproduction. It is well-suited for instrumental and vocal soloists in

radio and television broadcasting and any other kind of accurate

production.

The pressure gradient transducer is a dual-capacitor design that

uses a single brass back-plate and two large-diameter gold-plated

plastic diaphragms.

The cardioid pattern exhibits a smooth presence boost which

reaches its peak at about 4 dB in the 7 kHz range. This response -

coupled with a slight roll-off at low frequencies - is responsible for

the legendary 'presence' of this microphone.

The direction of maximum sensitivity is perpendicular to the

microphone's axis (side addressed).

The newly developed transformerless circuit design substitutes the

previous transformer for a symmetrical output stage yielding a

superb transient response combined with a high RFI rejection. The

circuit technology also achieves a wider dynamic range by

lowering the self-noise floor and increasing the headroom for loud

signals.

A10dBattenuatorhasbeeninstalledtoreducethesensitivityof

the microphone when placed near very loud sound sources. A

sensitivity reduction for low frequencies can be utilized to suppress

the proximity effect.

The microphone is equipped with a standard 3-pin XLR connector.

The operation voltage for the MT 71 S is provided by 48 V phantom

powering according to the international standards DIN 45 596 and

IEC 268-15.

The microphone is available in a satin nickel or a black matt finish.

MICROTECH GEFELL

FÜR STUDIO - UND MESSTECHNIK

KONDENSATORMIKROFONE

SEIT 1928

MICROTECH GEFELL GMBH GEORG NEUMANN PLATZ D-07926 GEFELL TEL. +49 (0)36649 / 882-0 FAX +49 ( 36649 / 882 11-- 0)

INTERNET http://www.microtechgefell.de e-mail info@microtechgefell.de

MT 71 S

Transformerless condenser microphone

with cardioid polar pattern

Windscreen, anthracite Order-No. 202407

Order-No. 600018

Microphone holder, black Order-No. 202306

black Order-No. 600001

Elastic suspension, satin nickel Order-No. 202318

Elastic suspension, black matt Order-No. 202319

Elastic suspension, modified, anthracite Order-No. 600004

Power supply Order-No. 202101

Connection cable Order-No. 202212

Popscreen, black

Clamp,

W 76

PO 70

MH 75

MKV 9

EA 21

N 200

C 70

AT 8410 a

Accessories, optional

Delivery

Microphone MT 71 S in wooden case L x B x H 275 x 90 x 70 mm

satin nickel Order-No. 211126

black matt Order-No. 211127

cardioid

Pressure gradient transducer

40 ... 18000 Hz

13 mV/Pa ± 3 dB

-10 dB ± 1 dB

150 Ω

22 dB

14 dB - A

72 dB

80 dB

134 dB

144 dB

120 dB

3 mA

285 g

217 mm x 42/21 mm

Polar pattern

Acoustic operating principle

Frequency range

Sensitivity at 1 kHz

Switch position "reduced bass roll-off" at 90 Hz

Rated impedance

Equivalent loudness level CCIR

468-4

DIN EN 60 651

Signal-to-noise ratio CCIR-weighted

(re 1 Pa at 1 kHz) A-weighted

Max. SPL for THD 0,5 %≤

3-pin XLR connector gold-plated contacts

with 10 dB preattenuation

Total dynamic range of the microphone preamplifier

Current consumption (P 48, DIN 45 596, IEC 268-15)

Output connector

Weight

Dimensions (L x )∅

Technical data MT 71 S

Certificate

satin nickel, black matt

Finish

due to inherent noise

Transformerless condenser microphone

MICROTECH GEFELL GMBH GEORG NEUMANN PLATZ D-07926 GEFELL TEL. +49 (0)36649 / 882-0 FAX +49 ( 36649 / 882 11-- 0)

INTERNET http://www.microtechgefell.de e-mail info@microtechgefell.de

Frequency responses MT 71 S

20 50 100 200 500 1000 2000 5000 10000 20000 Hz

- 20

- 10

+10

0°

180°

1 kHz

2 kHz

500 Hz

125 / 250 Hz

16 kHz

4 kHz

8 kHz

1 kHz

30°30°

60°60°

120°120°

150°150°

180°180°

210°210°

240°240°

270°270°

300°300°

330°330°

0°0°

1010

2020

90°90°

Polar pattern
