Side 1/8

MICROTECH GEFELL GMBH GEORG-NEUMANN-PLATZ D-07926 GEFELL TEL. ++49 (0 )36649 / 882-0 FAX ++49 (0)36649 / 882 11

INTERNE T ht t p: //w w w. microte chgefell.d e e-mail info@mi crot echgefell.d e

M I C R O T E C H G E F E L L

K O N D E N S A T O R M I K R O F O N E

F Ü R S T U D I O - U N D M E S S T E C H N I K

SEIT 1928

Large diaphragm dual-capsule

Switchable

Exceptional dynamic range

Equivalent noise level 7 dBA

Transformerless output

Elastic capsule suspension

Muting function

Soundcheck Tool SCT

Optical ready indicator

Colour Code

Satin nickel / dark bronze finish

UM 930

STUDIO CONDENSER

MICROPHONE

with switchable polar pattern

Phantom powering P 48 V

UM 930

The UM 930 switchable pattern studio condenser microphone combines modern large diaphragm

capsule technology with the latest in semiconductor circuit topology.

The optimized dual-capsule assembly opens up new applications in recording techniques.

Among conventional switching technique there is the possibility of attaching a twin-Version, viz. micro-

phones can be used with two directional pattern at the same time.

APPLICATION

The UM 930 is specifically designed to meet the needs of professional and semi-professional users who

demand the highest performance. This microphone is ideally suited for universal miking applications in

broadcast and sound studios.

Applications include vocalists, announcers, dialog pickup and as spot microphones for recording guitars,

keyboards, percussion, wind and string instruments.

The pick-up pattern is perpendicular to the direction of the microphone axis (side addressed). The model

number and pick-up pattern symbol mark the front of the microphone.

UM 930 SCT with Soundcheck Tool

Available for the UM 930 SCT condenser microphone is an 1kHz level checking test signal for checking

a complete sound system following the microphone. The Soundcheck Tool is enabled when the polar

pattern switching ring is placed midway between any of the polar pattern symbols for longer than 4 - 5

seconds, and the green LED illuminates. The level testing signal takes the individual sensitivity of the

microphone, pattern cardioid, and it is equivalent to a sound level of 74 dB. This is 20 dB lower than the

reference level at 1 Pascal, and assists in basic microphone setup during soundcheck. The Soundcheck

Tool reduces the need for frequent voice tests during setup in most cases.

MOUNTING

Shown with its integrated elastic suspension

can be swiveled 135 degrees to both sides

Shown with EA 92 elastic suspension

UM 930 UM 930
