The M 900 and M 910 condenser microphones have been

developed for recordings of instrumental and vocal soloists in the

professional market. Its well balanced frequency response in the

free field as well as in the diffuse field and the appropriate distinct

characteristics ensure clean and colourless recordings of any

sound sources with good selectivity.

It is advisable to use the M 910 by soloists because it shows a

specially optimised frequency response for this kind application.

A distance of less than 8 to 12 inches, which is recommended as

minimum distance between lips and microphone, causes a

coloration with an emphasis of lower frequencies, the proximity

effect.

An acoustic filter integrated in the protective basket reduces the pop

sensitivity. The direction of maximum sensitivity is axial, i.e. endwise

to the microphone. This fact and the ergonomic design make these

microphone the right choice for live performance of soloists.

Following the modern trend of technique the transducer is equipped

with a gold plated polyester membrane.

The newly developed transformerless impedance transducer having

a balanced output stage guarantees a high output capability and low

intrinsic noise. Together with the good qualities of the microphone

capsule a higt brillance of the live performance is reached. A 10 dB

attenuator is installed to reduce the sensitivity of the microphone

when placed near extremely loud sound sources. And a low

frequency roll-off switch will reduce the proximity effect when close

miking. The two switches are sunk placed in the middle of the

amplifier.

At the lower end of the amplifier the microphone is equipped with a

3-pin XLR connector fitting to the microphone cable C 70. These

microphones use 48 volt phantom powering according to the

international standards DIN 45596 and ICE 26815.

large diameter pressure gradient transducer

M 900 with cardioid polar pattern

M 910 with hypercardioid polar pattern

Studio Condenser Microphones for extraordinary

demands with a future oriented design

M 900 M 910

Delivery

Microphone M 900 in wooden case L x B x H

Order-No. 211140

275 x 90 x 70 mm

dark bronze

Microphone M 910 in wooden case L x B x H

Order-No. 211141

275 x 90 x 70 mm

dark bronze

M I C R OT E C H G E F E L L

F Ü R S T U D I O - U N D M E S S T E C H N I K

K O N D E N S A T O R M I K R O F O N E

SEIT 1928

MICROTECH GEFELL GMBH GEORG NEUMANN PLATZ D-07926 GEFELL TEL. ++49 (0)36649 / 882-0 FAX ++49 ( 36649 / 882 11- - 0)

INTERNET http://www.microtechgefell.de e-mail info@microtechgefell.de

Frequency responses M 900

20 50 100 200 500 1000 2000 5000 10000 20000 Hz

- 20

- 10

+10

0°

180°

20 50 100 200 500 1000 2000 5000 10000 20000 Hz

- 20

- 10

+10

0°

135°

30°

60°

150°

180°

210°

240°

300°

330°

0°

-10

-20

270°

90°

120°

4 kHz

10 kHz

30°

60°

150°

180°

210°

240°

300°

330°

0°

-10

-20

270°

90°

120°

125 Hz

1 kHz

4 kHz

10 kHz

125 Hz

1 kHz

hypercardioid

Pressure gradient transducer

40 ... 18000 Hz

14 mV/Pa

-10 dB

150 Ω

22 dB

15 dB - A

72 dB

79 dB

135 dB

145 dB

120 dB

3 mA

229 g

218 mm x 47/28 mm

Polar patterns

Acoustical operating principle

Frequency range

Sensitivity at 1 kHz

Switch position "reduced bass roll-off" at 90 Hz

Equivalent loudness level CCIR

468-4

DIN EN 60 651

CCIR-weighted

(re. 1 Pa at 1 kHz) A-weighted

Max. SPL for THD 0,5 %≤

with 10 dB preattenuation

Total dynamic range of the microphone amplifier

Current consumption (P 48, DIN 45596, IEC 268-15)

Output connector

Weight

Dimensions (L x )∅

Specifications M 900 M 910

Certifikate

Transformerless Studio Condenser Microphone

Rated impedance

Signal-to-noise-ratio

3-pin XLR connector

goldplated contacts

dark bronze

Finish

cardioid

40 ... 18000 Hz

17 mV/Pa

-10 dB

150 Ω

21 dB

13 dB - A

73 dB

81 dB

133 dB

143 dB

120 dB

3 mA

229 g

218 mm x 47/28 mm

dark bronze

Windscreen, anthrazite Order-No.

, black Order-No. 600018

Clamp, black Order-No. 600014

Order-No. 202314

anthracite Order-No. 600004

Table stand, Order-No. 212306

Table stand for 2 microphones Order-No. 202309

with Double mount, Order-No. 202332

Power supply Order-No. 202101

Order-No. 202212

202403

Popscreen

Elastic suspension, dark bronze

Elastic suspension,

dark bronze

Connection cable

W 90

PO 70

MKV 8

AT 8410 a

N 200

C 70

EA 90

TS 90

TS 68

TD 93

Accessories, optional

only for delivered by MTG

due to inherent noise

Frequency responses M 910
