 fold here  fold here  fold here  fold here  fold here  fold here

OPERATION

PREPARING THE LAUNDRY/SELECTING A PROGRAM

ADDING LAUNDRY

Damage from incorrect installation

and connection.

Installing and connecting the washing ma-

chine incorrectly will cause serious dam-

age to property.

See “Installation”.

Damage resulting from failure to re-

move the shipping struts.

Failure to remove the shipping struts can

result in damage to the washing machine

and to adjacent cabinetry or appliances.

Remove the shipping struts as described

in “Installation and connection”.

4steps must be completed to put the

washing machine into operation.

1. Remove the shipping struts.

2. Set up Miele@home.

3. TwinDos commissioning.

4. Start the calibration program.

For additional information, please refer to

the separate operating instructions sup-

plied.



     

Operating the sensor buttons

The sensor buttons react to fingertip con-

tact. If a sensor button is illuminated, it can

be selected.

If a sensor button is brightly lit, this means:

currently selected

If a sensor button is dimly lit, this means:

selection possible

Control field

Temperature sensor buttons

for selecting the temperature.

Spin Speed sensor buttons

for selecting the final spin speed.

Sensor buttons for TwinDos and

Options

You can deactivate or activate TwinDos

dispensing for a wash program and add

options to the program.

Indicator lights

Faults affecting the water inlet

and drainage

Excess detergent used

Reminder about Sanitize informa-

tion or TwinDos cleaning

The Add laundry function cannot

be selected.

CapDosing sensor buttons

Fabric care (e.g., fabric softener,

proofing agent)

Additives (e.g., detergent en-

hancers)

Detergent (for the main wash

only)

Time display

After the program has started, the pro-

gram runtime will appear on the display

in hours and minutes.

Sensor buttons  

For the Delay start function.

Start Add laundry/ sensor button

Touching the /Start Add laun-

drysensor button starts the se-

lected program. The sensor but-

ton lights up constantly.

Once the program has been

started, the /Start Add laun-

drysensor button allows you to

add laundry.

Optical interface

This is used by the Service department

as a transmission point.

Program selector

For selecting programs and for switch-

ing the machine off. The washing ma-

chine is switched on when you select a

program, and switched off by turning

the program selector to the position.

Environmentally friendly washing

- Make use of the maximum load that the

wash program can accommodate. This

will keep energy and water consumption

to a minimum in relation to the size of the

load.

- Use the program for small, lightlyExpress

soiled loads.

- Modern detergents make it possible to

wash at lower temperatures (e.g.,

70°F/20°C). Using the corresponding

temperature settings will save energy.

- Washing at low temperatures and/or us-

ing liquid detergents can cause bacteria

and odors to build up in the washing ma-

chine. Miele therefore recommends

cleaning the washing machine once ev-

ery month.

When the indicator light lights up on

the control field and appears on the

time display, the washing machine must

be cleaned.

1. Preparing the laundry

Empty all pockets.

Damage due to foreign ob-

jects.

Nails, coins, paper clips, and so

on can cause damage to gar-

ments and components in the

machine.

Check the laundry before wash-

ing and remove any such foreign

objects.

Sort the laundry by color and by care label. Most gar-

ments have a textile care label in the collar or side

seam.

Pre-treat stains and badly soiled areas.

2. Selecting a program

1. Selecting the standard programs with the program

selector dial

Turn the program selector to the

required program. The selected

program will be shown in the

display. This will then be re-

placed by the standard display.

2. Selecting programs via the

MobileStart program selector position and the

Miele app

To use MobileStart , the washing machine must be

logged on to the WiFi network and Remote control must

be switched on.

Turn the program selector to the

MobileStart position.

 appears on the time display.

The washing machine can now be operated with the Miele

app.

 







Detergent drawer

Control panel

Drain filter

Door

TwinDos dispensing

3. Loading the washing machine

Opening the door

Take hold of the door and pull it

open.

Unfold the laundry and load

loosely into the drum.

Closing the door

Make sure that no items are

caught between the door and

the seal.

Shut the door gently.

4. Selecting program settings

Selecting a temperature and spin speed

The wash program’s pre-set temperature and spin speed

light up brightly. The choice of temperatures and spin

speeds selectable for the wash program light up dimly.

Touch the sensor button for the temperature desired. It

will then light up brightly.

Touch the sensor button for the spin speed desired. It

will then light up brightly.

Selecting options

The selection of options available for the wash program

lights up dimly.

Touch the sensor button for the required option. It will

then light up brightly.

Tip: You can select multiple options for a single wash pro-

gram.

5. Add detergent

There are several options for adding deter-

gent to the washing machine.

TwinDos

TwinDos dispensing is automatically acti-

vated on all programs in which dispensing

is possible. The TwinDos sensor button

lights up brightly. The TwinDos Whitessen-

sor button lights up dimly in some wash

programs.

Changing TwinDos dispensing

You can change the suggested color com-

position of the laundry.

Touch theTwinDos Whites sensor button

if required.

Deactivating TwinDos dispensing

Touch the brightly litTwinDos Whites or

TwinDos Colors sensor button.

Both sensor buttons are dimmed and dis-

pensing is deactivated.

CapDosing

If you selected CapDosing when setting the

program, detergent will be dispensed via

the capsule for this wash program.

Using powder detergent

The detergent drawer contains an insert for

liquid detergent in the compartment.

This insert must be removed to use powder

detergent. It is not possible to use powder

detergent in the compartment.

Filling with detergent

This washing machine requires particularly

efficient detergent. Add detergent in accor-

dance with the value in the pull-down

dosage display.

Ensure that TwinDos dispensing is deacti-

vated.

Pull out the deter-

gent drawer and

add detergent to

the compart-

ments.





Chlorine bleach for removing

stains or liquid detergent for the

pre-wash

Detergent for the main wash,

including Soak if selected





Fabric softener, liquid starch, or

caps

Using chlorine bleach

Damage due to chlorine bleach.

Textiles may be discolored or their fibers

damaged.

Only use chlorine bleach on suitable tex-

tiles.

Chlorination must be activated in the set-

tings before chlorine bleach is first used.

The option must not be se-Pre-wash

lected.

Pour of bleachmax. 1/4 cup (60ml)

into the chamber.

The chlorine bleach is added automatically

10minutes before the end of the main

wash.

6. Start the program

Touch the flashing /Start Add laundry

sensor button.

The door will lock and the wash program

will start.

Adding laundry during a program

sequence

Laundry can be added or removed at any

time, provided that the symbol is not illu-

minated on the control field.

Touch the / sensor but-Start Add laundry

ton.

Rotating bars appear on... ... 

the time display.

If the word appears on the time dis-

play, the door can be opened.

Open the door and add or remove laun-

dry.

Close the door.

Touch the / sensor but-Start Add laundry

ton.

The wash program will continue.

Changing a program (safety lock)

A program, temperature, spin speed, or se-

lected options cannot be changed once the

machine has been successfully started.

This prevents the machine being operated

unintentionally, e.g., by children.

Canceling a program

You can cancel a wash program at any time

after it has started.

Turn the program selector to the posi-

tion.

Turn the program selector to any posi-

tion.

Rotating bars ap-  ...  ...  or 

pear on the time display. The water is

pumped away and the door lock is then re-

leased.

7. Program end

The door is locked in the Anti-crease

phase.

Turn the program selector to the posi-

tion.

appears on the time display and the

indicator light goes out. The door will be

unlocked.

Tip: After the Anti-crease phase, the door

will unlock automatically.

Take hold of the

door and pull it

open.

Remove the laun-

dry.

Items left in the drum could discolor other

items in the next wash or become discol-

ored themselves.

Remove all items from the drum.

Check the folds in

the door seal for

any foreign ob-

jects.

Tip: Leave the door slightly open.

If you used a capsule, remove it from the

detergent drawer.

Tip: Leave the detergent drawer slightly

open.

Delay Start/SmartStart

You can delay the start of a program from

30minutes up to a maximum of 24hours.

This allows you to make use of night-time

economy electricity rates, for example.

Selecting Delay Start

Select the wash program required.

Touch the

sensor but-

ton.

Touch the or sensor button re- 

peatedly until the required Delay Start

time appears on the time display.

- In the case of settings below 10hours,

the Delay Start time changes in incre-

ments of 30minutes.

- In the case of settings above 10hours,

the delay-start period changes in incre-

ments of 1hour.

Touch the flashing /Start Add laundry

sensor button.

The Delay Start process starts and counts

down on the time display.

SmartStart – Setting the time period

If the SmartGrid programmable func-

tion is activated, the function of the sensor

button changes. The time display no

longer shows the Delay Start period; in-

stead, it shows the time period in which

your washing machine can be started au-

tomatically. The procedure for setting this

is the same as for setting the time for De-

lay Start. For additional information, please

refer to the separate operating instructions

supplied.

Options

Options are selected and deselected us-

ing the relevant sensor buttons in the con-

trol field.

SoftSteam

In order to reduce creasing, the laundry

undergoes a smoothing process at the

end of the program. Reducing the maxi-

mum load by 50% will give a better result.

Please note the load information in the

display. Small loads achieve a better re-

sult.

without

SoftSteam

with

SoftSteam

Full load Half load

Half load Small load

Small load Very small load

The garments must be suitable for drying

in a tumble dryer and suitable for 

ironing . 

Buzzer

A buzzer sounds at the end of the pro-

gram. The buzzer sounds until the wash-

ing machine is switched off.

Before the first use Operation Preparing the laundry Selecting a program Starting a program Delay Start/Options

 fold here  fold here  fold here  fold here  fold here  fold here

en-US M.-Nr. 11 622 830WWD 660

 fold here  fold here  fold here  fold here  fold here  fold here

PROGRAM OVERVIEW

CLEANING AND CARE

FREQUENTLY ASKED QUESTIONS...

Program overview Detergent Cleaning and care Frequently asked questions...

Program Temperature Speed Load

Normal Warm+Hot+, Hot, , Warm, Cold , Max Full load (17.6lb/8kg)

Cotton, linen, and mixed-fiber fabrics made of both cotton and linen.

Delicates Warm+Hot+, , Hot , Warm, Cold , Slow, , (6.6lb/3kg)Med   Small load

For delicate fabrics made from synthetic fibers.

Sanitize Sani Max Full load, High, ,   (17.6lb/8kg)

Cotton or linen fabrics with direct skin contact or for which special hygiene requirements apply.

Handwash Warm+, Warm, Cold , Med, Slow, , (4.4lb/2kg)High   Small load

For delicate fabrics which are only suitable for hand washing.

Dress Shirts Warm+Hot+, , Hot , Warm, Cold , Slow, , (4.4lb/2kg)Med   Small load

Pre-treat collars and cuffs depending on the level of soiling.

Darks/Denims Warm+, Warm, Cold , Med, Slow, , (4.4lb/2kg)High   Small load

Black and dark garments made from cotton, mixed fibers, and denim.

MobileStart

The Miele app is used to select programs and operate the appliance.

Express Warm High Half load Warm+, , Cold , Med, Slow, ,   (7.7lb/3.5kg)

Cotton fabrics that have hardly been worn or are only very lightly soiled.

Extra White Hot+ Max Full load , High, ,   (17.6 lb/8kg)

For white fabrics made of cotton or linen without special hygiene requirements.

Outdoor Warm+, Warm, Cold , Slow, , (5.5lb/2.5kg)Med   Small load

Performance outerwear (e.g., jackets and pants) made from membrane fabric such as Gore-Tex®, SYMPATEX®, WINDSTOPPER®, etc.

Proofing Warm+ Med Small load, , , , High, , Slow, ,   (5.5lb/2.5kg)

Treating microfiber fabric, ski wear, or table linens/drapes made from mainly synthetic fibers to provide a finish which is resistant to water and dirt.

Drain/Spin Cold Max Full load, Med, Slow,  (17.6lb/8kg)

Drain only: set spin speed to .

Make sure you select the appropriate spin speed.

Detergents recommended by Miele

Miele

UltraPhase1 and 2

Miele Capsules



Normal   –

Delicates    –

Sanitize   –

Handwash – – 

Dress Shirts   –

Darks/Denims  – –

Express  – –

Extra White   –

Outdoor – – –

Proofing – – –

 Recommendation Special-purpose detergents (e.g., WoolCare)

–No recommendation Fabric care (e.g., fabric softener)

Additives (e.g., booster)

Cleaning the detergent drawer

Washing at low temperatures and the use

of liquid detergent can lead to a build-up

of bacteria in the detergent drawer.

Clean the entire drawer at regular inter-

vals for hygiene reasons, even if you are

using the TwinDos system exclusively.

Pull out the deter-

gent drawer until a

resistance is felt.

Press down the release button and, at

the same time, pull the drawer com-

pletely out of the machine.

Removing and cleaning the insert for

liquid detergents

An insert for liquid detergents is located in

the compartment of the detergent

drawer.

Remove the in-

sert. Clean the in-

sert thoroughly

with warm water.

Cleaning the siphon inside the

compartment

Compartment 1 has a siphon for better dis-

pensing of the chlorine bleach.

Remove the re-

lease catch.

Remove the

siphon and clean

under warm run-

ning water.

Cleaning the siphon inside the

compartment

Remove the

siphon from the

compartment

and clean under

warm running wa-

ter.

Clean all compartments with warm wa-

ter.

Cleaning the detergent-drawer housing

Use a bottle brush

to remove deter-

gent residues and

limescale from the

jets inside the de-

tergent-drawer

housing.

Replace the detergent drawer.

Tip: Leave the detergent drawer slightly

open to allow it to dry.

Sanitize info (cleaning the drum)

Washing at low temperatures and/or using

liquid detergent can cause bacteria and un-

pleasant odors to build up in the washing

machine. Use the program to cleanSanitize

the washing machine. Clean the drum no

later than the point at which the indicator

light and light up on the time display.

PrProblem

oblem

oblemoblem P

PPossible cause and solution

ossible cause and solution

ossible cause and solutionossible cause and solution

The control field remains

dark.

There is no power to the machine.

Check whether the plug is plugged in.

Check whether the fuse has tripped.

The washing machine has switched off automatically to

save energy.

Switch the washing machine on again by turning the pro-

gram selector.

  and alternate on the

time display.

The door is not closed properly. The door lock could not

engage.

Close the door again.

Start the program again.

If the fault message appears again, contact Miele Ser-

vice.

After the appliance is

switched on, appears

on the time display.

An update is available for the washing machine. See “Pro-

grammable functions – RemoteUpdate” for more in-

formation.

The fault indicator

light lights up. and  

alternate on the time dis-

play and the buzzer

sounds.

The drain is blocked or restricted.

The drain hose has been fixed too high.

Clean the drain filter and the drain pump.

The maximum drain height is 1m.

The fault indicator

light lights up. and  

alternate on the time dis-

play and the buzzer

sounds.

The water intake is blocked or restricted.

Check whether the faucet is turned on properly.

Check whether the inlet hose is kinked.

Check whether there is sufficient water pressure.

The filter in the water intake is blocked.

Clean the filter.

The fault indicator

light lights up. and

 alternate on the time

display and the buzzer

sounds.

The water protection system has reacted.

Close the faucet.

Contact Miele Service.

  and alternate on the

time display and the

buzzer sounds.

There is a fault.

Disconnect the washing machine from the power supply.

Unplug the appliance or switch off the breaker.

Wait before reconnecting the wash-at least 2minutes

ing machine to the power supply.

Switch the washing machine on again.

Restart the program.

If the fault message appears again, contact Miele Ser-

vice.

PrProblem

oblem

oblemoblem P

PPossible cause and solution

ossible cause and solution

ossible cause and solutionossible cause and solution

 lights up on the time

display.

The program selector was moved to a different position af-

ter the program had started.

Turn the program selector back to the original position.

The indicator light

lights up.

Excessive foam has built up during washing.

Use less detergent next time and follow the manufac-

turer’s instructions on dosage given on the packaging.

The indicator light lights

up and appears on the

time display.

When washing, a wash program using a temperature of

Hot+ has not been run for a long time.

Run the program using the Miele MachineSanitize

Cleaner or a universal powder detergent.

The washing machine is cleaned which prevents bacteria

and odor buildup.

  and alternate on the

time display.

The option which runs at the end of the pro-SoftSteam

gram could not be carried out properly.

Check whether the washing machine is aligned correctly

(see “Installation – Leveling the machine”).

Check whether the maximum drain height of 3.3 ft (1m)

has been exceeded.

If the fault message appears again, contact Miele Service.

The washing machine can still be used, but without the Soft-

Steam option.

The sensor button

flashes.

The UltraPhase1 cartridge is empty.

Replace the UltraPhase1 cartridge while the washing

machine is switched on.

The sensor button

flashes.

The UltraPhase2 cartridge is empty.

Replace the UltraPhase2 cartridge while the washing

machine is switched on.

The indicator light lights

up and appears on the

time display.

TwinDos has not been used for too long a time. It is possi-

ble that detergent has dried inside the hoses.

Immediately carry out the TwinDos maintenance pro-

gram as described in “Cleaning and care – TwinDos

maintenance”.

Quick Start Guide

Washing machine

This Quick Start Guide is not a substitute for the operating instructions supplied with the

appliance! It is essential to familiarize yourself with the washing machine before using it for

the first time. Please read the operating instructions carefully and pay particular attention

to the IMPORTANT SAFETY INSTRUCTIONS.

en-US

M.-Nr. 11 622 830 / 02

 fold here  fold here  fold here  fold here  fold here  fold here

Produkt Specifikationer

Mærke:	Miele
Kategori:	Vaskemaskine
Model:	WWD660 WCS TDos Front

Har du brug for hjælp?

Hvis du har brug for hjælp til Miele WWD660 WCS TDos Front stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Vaskemaskine Miele Manualer

Miele WWD660 WCS TDos Front Manual

22 Juli 2025

Miele WED 385 WCS Manual

8 Juli 2025

Miele PFD 104 SCVi Manual

6 Juli 2025

Miele WEE385 WCS Manual

6 Juli 2025

Miele WCD020 WPS Manual

6 Juli 2025

Miele WED385 WCS Manual

5 Juli 2025

Miele WEA125 WCS Manual

5 Juli 2025

Miele WEG885 WCS Manual

5 Juli 2025

Miele WWA120 WCS Active Manual

5 Juli 2025

Miele WQ 1000 WPS Nova Edition Manual

5 Juli 2025

Vaskemaskine Manualer

Nyeste Vaskemaskine Manualer

Smeg WNP84SEAUK Manual

23 Juli 2025

Cecotec Bolero DressCode 615 Manual

23 Juli 2025

Equator 826 Manual

23 Juli 2025

Benavent LBM821400AINV Manual

23 Juli 2025

Midea MF11EW70BA10 Manual

22 Juli 2025

Haier HWQ90B416FWB-UK Manual

22 Juli 2025

Haier HWQ90B416FWBR-UK Manual

22 Juli 2025

Haier HWQ90B416FWBR-S Manual

22 Juli 2025

Midea MF11EW100BA10 Manual

22 Juli 2025

Bomann WA 7161 Manual

22 Juli 2025
