Side 1/4

CRS326-24G-2S+IN

CRS326-24G-2S+INCRS326-24G-2S+IN

CRS326-24G-2S+IN

CRS326-24G-2S+INCRS326-24G-2S+IN

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

The Installation of the equipment must comply with local and national electrical codes.

This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.

This product is intended to be installed indoors. Keep this product away from water, fire, humidity or hot environments.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed.

Quick start

Connect two powering units to the AC source using power cords.

The Initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility.

Use Winbox to connect to the default IP address of 192.168.88.1 from any port, with the username and no password

admin

(or, for some models,

. If IP is no available choose the Neighbors tab and connect to the device using the MAC check user and wireless passwords on the sticker)

address.

We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best

performance and stability. The device needs to have an active internet connection.

To upgrade manually go to our download page https://mikrotik.com/download

Choose packaged based on your device model.

Download to your PC.

Upload packages to the Files menu in WinBox and reboot the device.

Set up your password to secure the device.

Mounting

The device is designed to use indoors and it can be placed on the desktop.

The device has no protection from water contamination, please ensure the placement of the device in a dry and ventilated environment.

We recommend Cat6 cables for our devices.

Mounting and configuration of this device should be done by a qualified person.

Extension slots and ports

24 of Gigabit Ethernet ports.

Two 10G SFP+ ports.

1x RJ45 console port (set at 115200bits/s, 8 data bits, 1 stop bit no parity).

Please visit wiki pages for MikroTik SFP module compatibility and configuration table: https://wiki.mikrotik.com/wiki

/MikroTik_SFP_module_compatibility_table

Powering

The device accepts power in the following ways:

Ethernet port accepts passive PoE 10-30 V DC .

Direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) accepts 10-30 V DC.

The power consumption under maximum load can reach 24 W.

Connecting to a PoE Adapter:

Connect the Ethernet cable from the device to the PoE+DATA port of the PoE adapter;

Connect an Ethernet cable from your local network (LAN) to the PoE adapter;

Connect the power cord to the adapter, and then plug the power cord into a power outlet.

Booting process

The device supports booting RouterOS (for complete routing and switching configuration) or SwOS (for only using as a switch). By default, the device will

boot RouterOS, but you can reboot into the other operating system in the following ways:

From SwOS: In the System menu, click the "Boot RouterOS" button on the bottom of the page.

From RouterOS: in the System, RouterBOARD menu, click "Settings" and there select "Boot OS".

It is also possible to select the OS and configure other boot settings via the serial console menu.

Reset button

The RouterBOOT reset button has the following functions. Press the button and apply the power, then:

Release the button when green LED starts flashing, to reset RouterOS configuration to defaults.

Release the button when the LED turns solid green to clear all configuration and defaults.

Release the button after LED is no longer lit (~20 seconds) to cause a device to look for Netinstall servers (required for reinstalling RouterOS over

the network).

Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed before power is applied to the device.

Useful for RouterBOOT debugging and recovery.

Operating system support

The device supports dual boot SwOS software version 2.9 and RouterOS v6. The specific factory-installed version number is indicated in the RouterOS

menu /system resource. Other operating systems have not been tested.

https://wiki.mikrotik.com/wiki/SwOS

Included Parts

Produkt Specifikationer

Mærke:	Mikrotik
Kategori:	Ikke kategoriseret
Model:	CRS326-24G-2S+IN
Bredde:	285 mm
Dybde:	144 mm
Højde:	44 mm
Produktfarve:	Hvid
Driftstemperatur (T-T):	-40 - 60 °C
Ethernet LAN-datahastigheder:	1000 Mbit/s
Intern hukommelse:	512 MB
Certificering:	CE/RED, EAC, ROHS
Strømforbrug (maks.):	21 W
DC indgangsspænding:	10 - 30 V
Indgangsstrøm:	1.2 A
Flashhukommelse:	16 MB
Strøm over Ethernet (PoE):	Ja
Hukommelsestype:	DDR3-SDRAM
Indbygget processer:	Ja
Switch-type:	Administreret
10G understøttelse:	Ja
VLAN understøttelse:	Ja
Port-spejlning:	Ja
Basis omskiftning RJ-45 Ethernet porte, antal:	24
Basis omskiftning RJ-45 Ethernet porttype:	Gigabit Ethernet (10/100/1000)
Filtrering af MAC-adresser:	Ja
MAC adresselabel:	- entries
Switch kapacitet:	- Gbit/sek.
Stativ-montering:	Ja
Antal SFP modulslots:	2
Begrænsning af hastighed:	Ja
Strømforsyning inkluderet:	Ja
IP-routing:	Ja
Power over Ethernet (PoE) spænding:	30 V
Antal strømforsyninger:	2
Power over Ethernet (PoE) -type understøttet:	Passive PoE
