Woobm-USB

The Woobm is a WiFi-to-serial bridge. This device enables wireless access to RouterBOARD devices which have a

USB port, but do not have wireless interfaces. The device operates in 2GHz 802.11b/g/n wireless mode, and

supports both client and access point modes, which can be protected with a WPA wireless password.

Powering

The device accepts powering from the USB port of the RouterBOARD device.

Setup

1. Plug the Woobm into the USB port of a RouterBOARD device.

2. Set your computer IP configuration to automatic (DHCP).

3. From your PC or smartphone, connect to the wireless network name “WoobmAP”.

4. Once connected to the wireless network, open http://192.168.4.1 in your web browser since there is no ,

password by default, you will be logged in automatically.

Configuration

The Woobm runs a special operating system where you can configure it’s basic functionality, the configuration is

accessible through a web interface. To connect to the RouterBOARD device, the following methods are available:

1. Click on “Terminal” in the Woobm web configuration interface.

2. Open a Telnet connection to the Woobm device from your computer, you will be directly connected to the

RouterBOARD device.

For more detailed instructions, please see full Woobm software documentation on http://mt.lv/help

Buttons and jumpers

The Woobm has one button, which has the following functions:

Reset: remove the device from the USB port, press the button, plug in the device, while holding the button.

Release the button when the LED light starts flashing red to restore factory defaults.

WPS: press the button once, while it is working. This will enable WPS for 5 seconds.

Operating system support

The device supports Woobm software only. It can be updated, by uploading a newer .BIN file through the web

configuration page.

See mikrotik.com for more information. Contact 28-Nov-17support@mikrotik.com

Federal Communication Commission Interference Statement

FCC ID: TV7WBM

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could

void the user’s authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.This device and its antenna must not be co-located or operation in

conjunction with any other antenna or transmitter.

IMPORTANT: Exposure to Radio Frequency Radiation. 13 cm minimum distance has to be maintained between the

antenna and user. Under such configuration, the FCC radiation exposure limits set forth for an

population/uncontrolled environment can be satisfied.

Antenna Installation. WARNING: It is installer's responsibility to ensure that when using the authorized antennas in

the United States (or where FCC rules apply); only those antennas certified with the product are used. The use of

any antenna other than those certified with the product is expressly forbidden in accordance to FCC rules CFR47

part 15.204. The installer should configure the output power level of antennas, according to country regulations and

per antenna type. Professional installation is required of equipment with connectors to ensure compliance with

health and safety issues.

Industry Canada

IC: 7442A-WBM

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following

two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,

including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.

L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)

l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en

compromettre le fonctionnement.

See mikrotik.com for more information. Contact 28-Nov-17support@mikrotik.com

Produkt Specifikationer

Mærke:	Mikrotik
Kategori:	Ikke kategoriseret
Model:	Woobm-USB
Bredde:	55 mm
Dybde:	19 mm
Højde:	8 mm
Produktfarve:	Hvid
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Forbindelsesteknologi:	Trådløs
Bedste Wi-Fi standard:	Wi-Fi 4 (802.11n)
Netværksstandarder:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Antennedesign:	Intern
Udgangsspænding:	5 V
Harmoniseret systemkode (HS):	85176990
Værtsgrænseflade:	USB
Grænseflade:	WLAN
Intern:	Ingen
Antenne:	Ja
Maksimal dataoverførselshastighed:	- Mbit/s
Processormodel:	Ja
Indbygget processer:	Ja
Båndbredde (første):	2.4 GHz
Forstærkning:	1.5 dBi
