Side 1/4
Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com
INS-XPR-5592-DL-19
09-04-2019
Instruction Manual
XPR-5592
THE XPR-5592 IS APPROVED FOR USE
CLASS I DIV 1 GRPS A-D T4
CLASS II & III DIV1 GRPS E-G T135°C
CLASS I ZONE 0 GROUP IIC T4 Ga
-20°C ≤ Tamb ≤ +40°C
3.7V/Cell Li-ion
Bayco Products, Inc. XPR-5592
FLOODLIGHT FOR USE IN HAZARDOUS LOCATIONS
For use with Bayco Li-ion Battery Pack 5592-BATT only
640 S. Sanden Blvd., Wylie, TX 75098
0359
INTRINSICALLY SAFE
SECURITE INTRINSEQUE
E 467756
ELECTRICAL SAFETY
ID 4003544
WARNINGS - INTRINSICALLY SAFE
• WARNING: Use only the approved Nightstick 5592-BATT Lithium-ion rechargeable battery pack or the
approved non-rechargeable batteries listed below.
• WARNING: To prevent ignition of a hazardous atmosphere, do not open the battery compartment
or attempt to exchange any of the supplied battery packs while in the hazardous environment. This
task must ONLY be performed in an area known to be non-hazardous.
WARNING: To prevent ignition of a hazardous atmosphere, the approved Nightstick 5592-BATT
Lithium-ion rechargeable battery pack must only be charged in an area known to be non-hazardous.
• WARNING: To reduce the risk of explosion, do not mix new non-rechargeable batteries with used
non-rechargeable batteries, or mix non-rechargeable batteries from different manufacturers.
• WARNING: Substitution of components may impair intrinsic safety.
SPECIAL INSTRUCTIONS FOR INTRINSIC SAFETY
For personal safety, always con rm the rating of any known hazardous or potentially hazardous
location where the Angle Light is to be used.
CAUTION
• Rechargeable Lithium-ion batteries must be used and charged properly. Improper use can result
in serious injury,  re, or death.
• Do not leave the battery in direct sunlight or use or store the battery inside cars in hot weather.
• Do not expose the battery to water or salt water, or allow the battery to get wet.
• Do not store the battery with metallic objects that may cause a short circuit.
• Immediately discontinue use of the battery if the battery emits an unusual smell, feels hot, changes
color, changes shape or appears abnormal in any way.
• Keep out of the reach of children.
INITIAL USE
Warning: To prevent ignition of a hazardous atmosphere, do not attempt to charge this
product in the hazardous environment. This task must ONLY be performed in an area known
to be non-hazardous.
Fully charge the XPR-5592 before the  rst use, or if the battery is new or has been unused for several
months. The maximum charge time required is approximately 6-7 hours.
DAILY USE
WARNING: TO PREVENT IGNITION OF A HAZARDOUS ATMOSPHERE, DO NOT ATTEMPT TO
CHARGE THIS PRODUCT IN THE HAZARDOUS ENVIRONMENT. THIS TASK MUST ONLY BE
PERFORMED IN AN AREA KNOWN TO BE NON-HAZARDOUS.
• Use only the supplied Nightstick AC or DC adapter. For best performance, charge the XPR-5592
when the light starts to dim.
• Connect the AC or DC adapter into the bottom of the light.
• The total time to full charge the XPR-5592 varies depending on the remaining charge in the
battery pack.
• For the light to be waterproof, the charging port must be well covered by the screw cap. (Image 1)
OPERATION
CAUTION: BECAUSE THE XPR-5592 HAS A MAGNETIC BASE, IT IS LIKELY THAT IT WILL BE
PLACED IN AN ELEVATED POSITION ABOVE THE GROUND. THEREFORE CAUTION SHOULD
BE USED TO BE CERTAIN THAT THE MAGNET IS SECURELY ATTACHED TO THE METAL
SURFACE BEFORE RELEASING THE LIGHT. IT IS ALSO ADVISED THAT EXTRA CARE BE
TAKEN WHEN ADJUSTING OR MOVING THE CORD SO THAT THE WORK LIGHT DOES NOT
COME LOOSE AND FALL TO THE GROUND.
The XPR-5592 has a single three-position toggle switch with black boot. Operation as seen from
the back of the light:
• Center position: Off
• Right position: High-brightness
• Left position: Low-brightness
Image 2Image 1 Image 3
SETTING UP THE WORK LIGHT ON A TRIPOD
Opening the tripod leg set:
Fully unfold the tripod leg set and slide the center collar down until it locks into place.
WARNING: Do NOT attempt to use the tripod leg set unless the legs are fully extended and
locked into place. This is the ONLY position that the leg set can be used in.
Closing the tripod leg set:
Press the release button on the side of the center collar and then raise the center collar up until
the tripod leg set is fully retracted.
Adjusting the column sections:
The tripod has two adjustable sections of the column that can be used to customize the working
height of the work light. Each section is locked into place by means of a cam lock lever. (Image 2) To
adjust the height of either section, release the cam lock lever for that section, extend the column to the
desired length and the re-lock the cam lock lever.
Removing the light from the tripod:
The product is designed so that the light can be removed from the tripod. To remove the light, grasp
the lights handle with one hand, and grasp the top of the tripod stand with the other hand a pull the
magnet apart from the mounting plate.
Installing the light onto the tripod:
CAUTION: Before installing the light on to the tripod, be certain that the leg set is fully extended
and locked in place and that both of the two column cam lock levers are securely locked.
To install the light head on to the tripod, simply line up the light heads magnetic base with the
tripods mounting plate (Image 3) allowing the magnet to secure itself to mounting plate. Be sure place
the light head directly onto the center of the mounting plate so that the light head is securely mounted.
WARRANTY
1 YEAR WARRANTY
Bayco Products, Inc. warrants this product to be free from defects in workmanship and materials to the
original purchaser for 1 year from the date of purchase, and includes the LEDs, housing, lenses, electronics,
switches, rechargeable batteries and chargers. Bulbs (other than LEDs) are covered for 90 days from the
date of purchase.
We will repair or replace this product should we determine it to be defective. This is the only warranty,
expressed or implied, including any warranty of merchantability or tness for a particular purpose.
For a complete copy of the warranty, go to www.nightstick.com/nightstick-product-support/warranties.
Retain your receipt for proof of purchase.
