User Manual

Features

·Unibody die-cast, lightweight and rugged

·Dual-source headlamp with CREE XP-G2 LED and two F5 red LEDs

·Powered by two AA batteries for a maximum output up to 300 Lumens

·High efficiency circuit board provides up to 160 hours runtime

·Integrated “Precision Digital Optics Technology” provides extreme

reflector performance

·Five brightness levels and three concealed special modes to select

from

·Red LEDs provide constant/flashing illumination

·Displays battery voltage with red light (accurate to 0.1V)

·Features intelligent memory effect

·Innovative single button two-stage switch is remarkably user-friendly

(Chinese Patent: ZL201120062948.1)

·Tilting mechanism provides 90°vertical movement to eliminate

illumination blind zones

·A custom catoptrics-based system produces an extremely wide 100°

beam angle

·Featuring Advanced Temperature Regulation (ATR) technology to

dynamically adjust output performance according to its internal

temperature

·Comfortable chafe-free and breathable nylon headband

·Toughened ultra-clear mineral glass with anti-reflective coating

·Constructed from aero-grade aluminum alloy

·Waterproof in accordance with IP67

·Impact resistant to 1.5 meters

Dimensions

Size: 3.54” x 2.18” x 1.98” (90mm x 55.4mm x 50.4mm)

Head diameter: 0.94” (24mm)

Weight: 2.17oz (61.4g) (without battery)

Accessories

Spare O-ring

Battery Options

Output & Runtime

Note: Each time batteries are inserted, the red LEDs will blink to indicate

battery voltage. Please refer to the “Power Tips” section in this manual

for details.

Caution: DO NOT direct the beam towards human or animal eyes when

using HA20.

On/O Operations

To turn HA20 on: Press the switch all the way down until a “Click” is

heard;

To turn HA20 off: Press the switch all the way down again until a “Click”

is heard.

Brightness Levels

With HA20 turned on, press the switch partway down to cycle through

brightness levels: ultralow, low, medium, high-turbo. HA20 has memory

effect for brightness levels. Each time it is turned on, HA20 will enter the

brightness level last used.

Special Modes(Police Warning/Location

Beacon/SOS)

With HA20 turned on, press the switch all the way down for over one

second to enter police warning mode. Press the switch partway down to

cycle through location beacon-SOS-police warning modes. To exit, press

the switch all the way down to turn HA20 off.

Constant/Flashing Red Illumination

With the light turned off, press the switch partway down for over one

second to enter constant red illumination mode (7 hours and 25 minutes

runtime at 16 Lumens);

In red illumination mode, press the switch partway down to switch

between constant and flashlight red illumination. To exit, press the switch

all the way down to turn HA20 off.

Power Tips

Upon battery installation, the red LEDs will blink to indicate battery

voltage (accurate to 0.1V). For example, when battery voltage is 2.4V,

red LEDs blink twice, followed by a 1.5 second pause, and blink four

Thanks for purchasing NITECORE!

The All-Round Flashlight Expert

HA20

Operating Instructions

HA20 utilizes a two-stage switch to enable various operations based on

finger pressure.

Battery Installation

Insert two AA batteries with the positive (+) and negative (-) ends

corresponding to the diagram below. Align the cover .

TYPE

Nominal voltage

Compatible

Primary AA battery AA 1.5V Y (Recommended)

Rechargeable AA battery AA 1.2V Y (Recommended)

Primary AA Lithium battery L91 1.5V Y

NOTICE

The above data has been measured in accordance with the international

flashlight testing standards ANSI/NEMA FL1 using 2 x 1.2V 2400mAh AA

batteries under laboratory conditions. The data may vary slightly during

real-world use due to battery type, individual usage habits and

environmental factors.

TURBO HIGH MID LOW ULTRALOW

LUMENS

300

LUMENS

160

LUMENS

LUMEN

min

17h 160h

110m

(Beam Distance)

1.5m

(Impact Resistant)

3050cd

(Peak Beam Intensity)

IP67

(

Dust & Water Resistant)

)

SYSMAX Industry Co., Ltd.

TEL: +86-20-83862000

FAX: +86-20-83882723

E-mail: info@nitecore.com

Web: www.nitecore.com

Address： Rm1401-03, Glorious Tower, 850 East Dongfeng

Road, Guangzhou, China 510600

Warranty Service

All NITECORE® products are warranted for quality. Any defective /

malfunctioning NITECORE® product can be repaired free of charge for a

period of 60 months (5 years) from the date of purchase. Beyond 60

months (5 years), a limited warranty applies, covering the cost of labor

and maintenance, but not the cost of accessories or replacement parts.

The warranty is nullified in all of the following situations:

1. The product(s) is/are broken down, reconstructed and/or modified by

unauthorized parties.

2. The product(s) is/are damaged through improper use.

3. The product(s) is/are damaged by leakage of batteries.

For the latest information on NITECORE® products and services, please

contact a local NITECORE® distributor or send an email to

service@nitecore.com

※All images, text and statements specified herein this user manual are

for reference purpose only. Should any discrepancy occurs between this

manual and information specified on www.nitecore.com, information on

our official website shall prevail. Sysmax Industry Co., Ltd. reserves the

rights to interpret and amend the content of this document at any time

without prior notice.

ALL-ROUND Flashlight Expert

times.

With HA20 turned off, pressing the switch partway down will have red

LEDs indicate battery power levels:

1. Three times for battery levels over 50%;

2. Twice for battery levels below 50%;

3. Once for battery levels close to depletion (below 10%).

Advanced Temperature Regulation

(ATR)

Advanced temperature regulation (ATR) technology allows HA20 to

dynamically adjust output performance based on its internal temperature.

This prevents damage from overheating and prolongs its working life.

Changing Batteries

Batteries should be replaced when any of the following occurs: The

output appears to be dim or unresponsive.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a

thin coatingof silicon-based lubricant.

Thanks for purchasing NITECORE!

Please nd us on facebook: NITECORE Flashlights

20150909
