Side 1/1

440

White Light

TURBO

White Light

HIGH

White Light

MID

White Light

LOW

White Light

LOWER

2×CR1231×18650

LUMENS

280

LUMENS

160

LUMENS

min

260

min

400

190m

(Beam Distance)

9000cd

(Peak Beam Intensity)

1.5m

(Impact Resistant)

IPX-8, 2m

(Waterproof AND Submersible)

Features

• Featuring five individual light sources: two main LEDs plus secondary red,

green and blue LEDs.

• Five selectable modes of output (red, green, blue, white and ultraviolet)

• Dual side switches offer convenient control of color modes

• Purpose-designed for hunting, police investigation, forensics and identification

applications

• White CREE XP-G2 (R5) LED provides a maximum output of up to 440 lumens

• Ultraviolet LED provides 3000mW at 365nm

• Maximum runtime of up to 400 hours on lowest mode of output

• Integrated “Precision Digital Optics Technology” and Second generation of

‘Crystal Coating Technology’ provides extreme reflector performance

• Equipped with a unique multi-colored (red, green and blue) signaling mode

• Dual side switches control white and colored LEDs independently

• Side switch features integrated power indicator light for displaying remaining

battery power (patented)

• Instant-On functionality: enter turbo mode directly

• Physical reverse polarity protection mechanism (patented)

• Stainless steel titanium-plated clip

• Stainless steel retaining ring protects the core components from damage

• Toughened ultra-clear mineral glass with anti-reflective coating

• Constructed from aero-grade aluminum alloy

• HAIII military grade hard-anodized finish

• Waterproof in accordance with IPX-8 (two meters submersible)

• Impact resistant to 1.5 meters

• Tail stand capability

Dimensions

Length: 143mm (5.63”)

Head Diameter: 40mm (1.57”)

Tail Diameter: 25.4mm (1”)

Weight: 138grams (4.87oz) (without battery)

Accessories

Quality holster, clip, tactical ring, lanyard, spare tail cap, spare O-ring

Optional accessories

Remote switch (RSW1), Gun Mount (GM02, GM03, GM04)

Battery Options

Brightness & Runtime

The All-Round Flashlight Expert

Momentary Illumination

Momentary illumination can be achieved by switching off the flashlight and then

half pressing and holding the tail switch. Simply release the switch to turn the

light off.

Switching ON/OFF

To switch ON: Press the button on the tailcap until a “click” is heard.

To switch OFF: Press the button on the tailcap a second time until a “click” is

heard.

Brightness Selection

Tips: Two side switches control the two main LEDs as well as strobe / beacon/

SOS modes.

With the light turned on at the tailcap, press the left (white) switch repeatedly to

cycle though the following WHITE LED brightness levels: ultra-low, low, medium ,

high and turbo. Once a desired setting is displayed, it will be saved by turning the

light off at the tail switch.

With the light turned on at the tailcap, press the right (color) switch repeatedly to

cycle though the following COLORED LED brightness levels: Ultraviolet Mode ->

secondary red -> secondary green -> secondary blue. Once a desired setting is

displayed, it will be saved by turning the light off at the tail switch.

Instant Turbo / Instant Ultraviolet Mode

With the light turned off, press and hold a side switch and then press the tail

switch to go directly to Turbo Mode or Ultraviolet Mode (left switch for turbo white

and right switch for ultraviolet). This function is designed to provide instant

access to the either the highest output of white light or ultraviolet mode.

NOTE: When using two CR123A batteries in turbo mode, output will

automatically reduce after 20 minutes of use to prevent overheating.

Warning: Avoid exposing the eyes or skin of people or animals to

ultraviolet light.

Special Modes

With the light turned on, press and hold the left (white) switch to activate Strobe

mode. Press and hold in succession to cycle: Location Beacon, SOS, Strobe

mode.

With the light turned on, press and hold the right switch (colored) all the way

down for more than 1 second to active police warning signal. Press the switch

again to turn this mode off.

NOTE: Among all special modes, only strobe mode can be saved.

Power Tips

1. With the light switched on, the blue power indicator will blink once every two

seconds when power levels reach 50%.

2. With the light switched on, the blue power indicator will blink rapidly when

power levels are low.

Changing Batteries

When the power indicator blinks rapidly this indicates the batteries need to be

replaced. Alternatively if the light becomes dim or unresponsive to adjustment this

also indicates batteries need to be replaced.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a thin

coating of silicon-based lubricant.

Warranty Service

All NITECORE

products are warranted for quality. DOA / defective products can

be exchanged for replacement through a local distributor/dealer within the 14

days of purchase. After 14 days, all defective / malfunctioning NITECORE

products will be repaired free of charge for a period of 18 months from the date of

purchase. After 18 months, a limited warranty applies, covering the cost of labor

and maintenance, but not the cost of accessories or replacement parts. The

warranty is nullified in all of the following situations:

1. The product(s) is/are broken down, reconstructed and/or modified by

unauthorized parties.

2. The product(s) is/are damaged through improper use.

3. The product(s) is/are damaged by leakage of batteries.

For the latest information on NITECORE

products and services, please contact

your national NITECORE

distributor or send an email to service@nitecore.com

The Nitecore official website shall prevail in case of any product data changes.

NOTICE

The above data has been

measured in accordance with

the international flashlight

testing standards ANSI/NEMA

FL1 using one x 3.7V

2600mAh Nitecore 18650

battery and 2 x 3V 1550mAh

Nitecore CR123 batteries

under laboratory conditions.

The data may vary slightly

during real-world use due to

battery type, individual usage

habits and environmental

factors.

NITECORE (SYSMAX) is a member of PLATO, participating in and helping to

develop the ANSI FL1 standard of measurement. Product testing data is in

accordance with these internationally recognized scientific standards.

SIZE

Nominal voltage

Compatible

Primary Lithium battery

CR123 3V

Y (Recommended)

18650 Rechargeable Li-ion battery

18650 3.7V

Y (Recommended)

Rechargeable Li-ion battery

RCR123 3.7V

User Manual

CU6

SYSMAX Industry Co., Ltd.

TEL: +86-20-83862000

FAX: +86-20-83882723

E-mail: info@nitecore.com

Web: www.nitecore.com

Address Rm1407-08, Glorious Tower, 850 East Dongfeng Road, ：

Guangzhou, China 510600

Operation Instructions

Battery Installation

Insert one 18650 battery or two CR123 /

RCR123 batteries with the positive pole

pointing forward (toward the light head).

WARNING

1. Ensure batteries are inserted with the

positive (+) end pointing to the head. The

Chameleon will not operate with

incorrectly inserted batteries.

2. Ensure when turning the Chameleon on,

the beam is directed a way from the eyes

of people or animals.

Thanks for purchasing NITECORE!

Please follow our facebook for

more info: NITECORE Flashlights

Produkt Specifikationer

Mærke:	Nitecore
Kategori:	Lommelygte
Model:	Chameleon CU6
Bredde:	143 mm
Vægt:	138 g
Produktfarve:	Sort
Lampe type:	LED
Batterilevetid (maks.):	400 t
Batteritype:	18650/CR123
Antal lamper:	- Lampe( r)
Lysfarve:	Blue, Red, White
Lommelygte type:	Hånd lommelygte
Lysstråle afstand (maks.):	190 m
Lommelygte tilstande:	SOS mode, Strobe mode
Lysstrøm:	440 lm
LED type:	CREE XP-G2 R5
Lysstyrke:	9000 Candella
Hoved, diameter:	40 mm
