Side 1/1

HIGH MID LOW

LUMENS

150

LUMENS

430

LUMENS

min

LOWER

520

min

310

278m

(Beam Distance)

19321cd

(Peak Beam Intensity)

IPX-8, 2m

(Waterproof AND Submersible)

1.5m

(Impact Resistant)

1×

18650

2×CR123

User Manual

Features

• Premium CREE XP-G2 (R5) LED

• Maximum output of 430 lumens

• Integrated “Precision Digital Optics Technology” provides extreme reflector

performance

• Boasts a peak beam intensity of 19,321cd and a throw distance of up to 278

meters

• High efficiency circuit board provides up to 520 hours runtime

• Side switch interface provides one-handed operation and easy access to all

flashlight functions

• Side switch features a power indicator light displays remaining battery power

(patented)

• Power indicator’s secondary function displays battery voltage (accurate to

0.1V)

• Intelligent memory function stores preferred brightness setting

• Integrated impact resistance mechanism with reverse polarity protection

(patented)

• Flashlight head retaining ring protects the core components from damage

• Toughened ultra-clear mineral glass with anti-reflective coating

• Constructed from aero grade aluminum alloy with HAIII military grade

hard-anodized finish

• Waterproof in accordance with IPX-8 (two meters submersible)

• Impact resistant to 1.5 meters

• Stainless steel titanium-plated two-way clip included

• Tail stand capability

Dimensions

Length: 151mm (5.94”)

Head Diameter: 40mm (1.57”)

Tail Diameter: 25.4mm (1”)

Weight: 132grams (4.66oz)(without battery)

Thanks for purchasing NITECORE!

SYSMAX Industry Co., Ltd.

TEL: +86-20-83862000

FAX: +86-20-83882723

E-mail: info@nitecore.com

Web: www.nitecore.com

Address Rm1407-08, Glorious Tower, 850 East Dongfeng Road, ：

Guangzhou, China 510600

Brightness & Runtime

ALL-ROUND Flashlight Expert

Accessories

Quality holster, clip, tactical

ring, lanyard, spare tail cap,

spare O-ring

Battery Options

Please follow our facebook for

more info: NITECORE Flashlights

Operation instructions

Battery installation

Insert one 18650 battery or two CR123

batteries with the positive pole pointing

forward (toward the light head).

WARNING

1. Ensure batteries are inserted with the

positive (+) end pointing to the head.

The P15 will not operate with incorrectly

inserted batteries.

2. Ensure when turning the P15 on, the

beam is directed away from the eyes of

people or animals.

Momentary illumination

Momentary illumination can be achieved by switching off the flashlight and

then half pressing and holding the tail switch. Simply release the switch to

turn the light off.

Switching ON/OFF

To switch ON: Press the button on the tailcap until a “click” is heard.

To switch OFF: Press the button on the tailcap a second time until a “click” is

heard.

General Operations

With the light turned on, press the side switch in quick succession to cycle

through the following brightness levels: ultra-low, low, medium and high. Once

a desired setting is displayed, it may be saved by turning the light off at the

tail switch.

Note: For user safety and to prevent overheating / failure, the P15 will

automatically switch to a lower mode after three minutes of use at its highest

level of output.

Special Modes

With the light turned on, press and hold the side switch to activate Strobe

mode. Press and hold once again to access Location Beacon mode and

repeat once more for SOS mode. To exit any one of these modes simply

press the side switch to be returned to your previously used brightness level.

NB: Strobe mode is the default special mode and is the only special mode

that has a memory function. If the light is turned off at the tail switch while in

strobe mode, strobe will resume when the light is next turned on. SOS and

Location Beacon modes have no memory function.

Power Tips

1. With the light switched on, the power indicator will blink once every two

seconds when power levels reach 50%.

2. With the light switched on, the power indicator will blink rapidly when power

levels are low.

3. With the light turned off, press and hold the side switch while

simultaneously pressing the tail switch to display the battery voltage

(accurate to ±0.1V) with a series of blinks. For example, when the battery

voltage is at a maximum charge of 4.2V, the power indicator will blink 4

times in quick succession, followed by a one second pause and two more

blinks, indicating a total battery voltage of 4.2V.

Changing Batteries

When the power indicator blinks rapidly this indicates the batteries need to be

replaced. Alternatively if the light becomes dim or unresponsive to adjustment

this also indicates batteries need to be replaced.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a thin

coating of silicon-based lubricant.

Warranty Service

All NITECORE

products are warranted for quality. DOA / defective products

can be exchanged for replacement through a local distributor/dealer within the

14 days of purchase. After 14 days, all defective / malfunctioning

NITECORE

products will be repaired free of charge for a period of 18

months from the date of purchase. After 18 months, a limited warranty

applies, covering the cost of labor and maintenance, but not the cost of

accessories or replacement parts. The warranty is nullified in all of the

following situations:

1. The product(s) is/are broken down, reconstructed and/or modified by

unauthorized parties.

2. The product(s) is/are damaged through improper use.

3. The product(s) is/are damaged by leakage of batteries.

For the latest information on NITECORE

products and services, please

contact your national NITECORE

distributor or send an email to

service@nitecore.com

The Nitecore official website shall prevail in case of any product data changes.

NOTICE

The above data has

been measured in

accordance with the

international flashlight

testing standards

ANSI/NEMA FL1 using

one x 3.7V 2600mAh

Nitecore 18650 battery

and 2 x 3V 1550mAh

Nitecore CR123

batteries under

laboratory conditions.

The data may vary

slightly during

real-world use due to

battery type, individual

usage habits and

environmental factors.

NITECORE (SYSMAX) is a member of PLATO, participating in and helping to

develop the ANSI FL1 standard of measurement. Product testing data is in

accordance with these internationally recognized scientific standards.

P15

SIZE

Nominal voltage

Compatible

Primary Lithium battery

CR123 3V

Y (Recommended)

18650 Rechargeable Li-ion battery

18650 3.7V

Y (Recommended)

Rechargeable Li-ion battery

RCR123 3.7V
