Side 1/2

使用头灯

双开关按键

开关键控制主灯白色光源操作，

R键控制红色光源操作。

1.开启的3秒内，连续按下开关按键，头灯即可按：超低亮→中亮→高亮→待机,顺序循环切换。

2.在头灯处于点亮状态的3秒内，无任何按键操作，再次按下开关键，头灯关闭并进入待机状态。

注：在高亮状态下工作45分钟后，头灯将降低亮度以防止内部温度过热。

使用特殊档位(SOS/信标)

在头灯关闭状态下，长按开关键3秒后，头灯进入SOS功能。3秒内，每次单击开关键，头灯按

照：SOS→信标→待机，顺序切换。3秒内无任何按键操作，再次单击直接进入待机。

使用红光工作

在头灯关闭状态下，按下R键，红光开启（13流明）。开启3秒内再次按下，头灯将按

照：红光照明→警示慢闪→待机，顺序循环切换。若3秒内无任何操作，亦可单击R键关闭红光。

锁定/解锁

在头灯关闭状态下，同时按下双按键，位于开关键的红色指示灯闪烁一次提示头灯锁

定。锁定后无法开启照明，锁定状态下按任意按钮红色指示灯均闪一下以作提示。如需解锁，

再次按下双按键。

电量提示

在头灯关闭状态下，按下开关键 1秒，位于开关键的电量提示灯将闪烁提示剩余电量：

闪烁三次表示电量大于50%，闪烁两次表示电量少于50%，闪烁一次表示电量少于10%将近

耗尽。注：当电池电量不足，头灯会出现亮度变暗或者无法调光的情况。此时，应对头灯

进行充电。

充电

本产品自带USB充电功能。掀开头灯机身的USB保护盖，把USB

充电线一端连接至USB插孔，另一端接上电源（适配器、电脑

或其他充电设备）即可充电。充电时间约2小时。

充电提示：当头灯处于正常充电状态时，位于开关按键背面

的红色指示灯将长亮；充电完成后，绿色指示灯亮起。

注意事项

请根据适用的当地法律和法规处置设备/电池。

保固

NITECORE 产品拥有售后保固服务。在购买本产品的15天内，如果有任何质量问题均可向经®

销商要求免费更换。在购买本产品的24个月内享受免费保固服务。在超过24个月免费保固

期后，本产品享有终身有限度保固服务，如需要更换重要部件则需收取成本费用。

本保固规则不适用于以下情况：

1. 人为破坏，拆解，改装本产品。

2. 错误操作导致产品损坏。

如对奈特科尔产品有任何疑问，欢迎联系当地的代理商或发邮件到4008869828@nitecore.cn

※ 本说明书的所有图片、陈述及文字信息仅供参考，请以官网www.nitecore.cn实际信

息为准。广州希脉创新科技有限公司拥有对说明书内容的最终解释权和修改权。

产品特性

·轻巧便携式小头灯

·NU10:采用5颗高性能LED

·NU10 CRI：高显色性灯珠，CRI≥90

·红白双光源组合

·内置可充电锂电池，最长续航时间150小时

·自带智能锂电池充电电路，Micro-USB

直充

·双按键开关设计，单手即可操作

·具备3档亮度和两种特殊功能可选（SOS，

信标）

·开关按键内藏电量指示灯，可提示电池剩

余电量

·泛光照明系统，60°照明角度调节

·灯体采用PC材料制造，坚固耐用

·超轻设计，方便携带

·1米防摔能力

体积

尺寸：60.5mm×35mm×29mm（含支架）

重量：65克（含电池）

配件

USB线，头灯带，支架

·1·

·3·

NU10/NU10 CRI

使用说明书

亮度&时间

· ·2

奈特科尔—全能照明专家

注:以上数据按照国际手电筒测量标准

ANSI/NEMA FL1所述之测量方法，所使用电

池为：内置锂电池（3.7V 900mAh）。不同

使用环境可能会对以上数据产生影响。

使用主灯白光工作

在头灯关闭状态下，按下开关键，主灯白光开启并进入亮度调节模式：

7小时

160流明 160流明 160流明

35米15米

坎德拉 21

坎德拉

310

坎德拉

3米9米

IP66（防护等级）

1米（防跌落高度）

高亮

35流明

中亮

1流明

超低亮

13流明

红光 SOS 信标

8小时

45分钟

150小时 5小时

15分钟

7小时

115流明 115流明 115流明

30米14米

1.5

坎德拉

220

坎德拉

2米9米

IP66（防护等级）

1米（防跌落高度）

高亮

22流明

中亮

1流明

超低亮

13流明

红光 SOS 信标

8小时

45分钟

150小时 5小时

15分钟

NU10

NU10 CRI

广州希脉创新科技有限公司

咨询热线：+86-20-83862000

销售邮箱：info@nitecore.com

网址：www.nitecore.cn

地址：广东省广州市天河区高普路1021号5楼6355号

邮编：510653

NU18101022

更多信息请关注新浪微博：NITECORE奈特科尔

Features

·Lightweight portable headlamp

·NU10：Fitted with 5 high performance LEDs

·NU10 CRI: High colour rendering capability, CRI≥90

·White and red dual outputs

·Built-in Li-ion battery provides runtime up to 150 hours

·Onboard USB charging circuit

·Dual switch design for easy one-handed operation

·3 brightness levels and 2 special modes (SOS, location beacon)

·Built-in power indicator

·Flood-illumination with 60° adjustable angle

·Made from durable PC materials

·Impact resistant to 1 metre

Dimensions

Size: 2.38” ×1.38” ×1.15”

Weight: 2.29oz(with battery)

Output & Runtime

Operating Instructions

Dual Switch

The power switch controls the white light, and the R switch controls the red light.

White Light Illumination

With the light turned off, press the power switch to turn the white light on:

1. Within 3 second from the white light activation, pressing the power switch

repeatedly will cycle through Low-Mid-High-Standby.

2. Pressing the power switch after the white light has been left on in any setting

for more than 3 second will turn the light off.

Note: The NU10 will step down from “High” to the next available output after it has been

on that mode for 45 minutes, this is designed to prevent overheating.

Special Modes(SOS mode / LocationBeacon)

With the light turned off, hold down the power switch for 3 second to enter SOS mode,

press the power switch again within 3 second interval switches the NU10 from

SOS-Beacon-Standby (pressing the power switch again when no action is taken after 3

second turns the light off).

Red Light Illumination

With the light turned off, press the R switch to turn the red light (13 lumens) on, pressing

the R switch again repeatedly within 3 second to cycle through Red illumination-Red

flashing-standby, press the R switch when no action is taken after 3 second will turn the

red light off.

The All-Round Flashlight Expert User Manual

NU10/NU10 CRI

SYSMAX Innovations Co., Ltd.

TEL:+86-20-83862000

FAX: +86-20-83882723

E-mail: info@nitecore.com

Web: www.nitecore.com

Address： Unit 6355, 5/F, No. 1021 Gaopu

Road,Tianhe District, Guangzhou,

510653, Guangdong, China

Please find us on facebook:

NITECORE Flashlight

Made in China

NU18101022

Thanks for purchasing NITECORE!

Lockout/Unlock

Hold down both the power switch and R switch until the built-in power indicator blinks

once to enter lockout mode, all 5 main LEDs will be rendered inoperative in lockout mode,

to unlock, hold down both switches until the power indicator blinks once again.

Power Tips

The built-in power indicator is designed to provide an approximation for remaining battery

level, with the light turned off, hold down the power switch for 1 second, the power

indicator under the power switch will blink to indicate battery level: 3 blinks represent

battery level above 50%, 2 blinks represent battery level below 50%, 1 blink represents

battery level below 10%.

Note: Recharge the NU10 when output appears to be dim or unresponsive.

Recharge

The NU10 comes with a USB cord included. Raise the micro-USB port cover on the NU10

to expose the charging port, connect the port to a power supply with the USB cord

provided. Fully charges the product take approximately 2 hours.

Warnings

Dispose of the device/batteries in accordance with applicable local laws and regulations.

Warranty Details

All NITECORE products are warranted for quality. Any defective /malfunctioning

NITECORE Tube can be repaired free of charge for a period of 24 months from

the date of purchase. Beyond 24 months, a limited warranty applies, covering

the cost of labor and maintenance, but not the cost of accessories or

replacement parts. The warranty is nullified in either or both of the following

situations:

1. The product(s) is/are broken down, reconstructed and/or modified by

unauthorized parties.

2. The product(s) is/are damaged through improper use.

For the latest information on NITECORE products and services, please contact ®

a local NITECORE distributor or send an email to service@nitecore.com.®

※All images, text and statements specified herein this user manual are for

reference purpose only. Should any discrepancy occurs between this manual

and information specified on www.nitecore.com, information on our official

website shall prevail. SYSMAX Innovations Co., Ltd. reserves the rights to interpret

and amend the content of this document at any time without prior notice.

Accessories

USB cord, head band, holder

NU10 CRI

NU10

Note: The built-in power indicator will be lit to

indicate charging in progress, and will turn green

when the process is completed.

NOTICE: Stated data has been

measured in accordance with the

international flashlight testing standards

ANSI/NEMA FL1 using an integrated

and fully charged 3.7V 900mAh

rechargeable Li-ion battery under

laboratory conditions. End-user results

may vary due to individual usage habits

and environmental conditions.

NOTICE: Stated data has been

measured in accordance with the

international flashlight testing standards

ANSI/NEMA FL1 using an integrated

and fully charged 3.7V 900mAh

rechargeable Li-ion battery under

laboratory conditions. End-user results

may vary due to individual usage habits

and environmental conditions.

HIGH MID

LUMENS LUMENS LUMEN LUMENS LUMENS LUMENS

IP66

(Rated)

(Impact Resistant)

160 160 160

35m15m

3 21cd cd60cd310cd

3m9m

35 1 13

SOS Beacon

45min

150h5h

15min

HIGH MID ULTRALOW RED

HIGH MID

LUMENS LUMENS LUMEN LUMENS LUMENS LUMENS

IP66

(Rated)

(Impact Resistant)

115 115 115

30m14m

1.5 21cd cd46cd220cd

2m9m

22 1 13

SOS Beacon

45min 150h5h

15min

HIGH MID ULTRALOW RED
