User Manual

Features

· Purpose-designed for law enforcement, hunting and tactical

applications.

· The world’s first line of flashlights to feature third generation SSR

(smart selector ring) technology

· Smoothly and rapidly select brightness levels and function by rotating a

smart selector ring

· Utilizes the latest CREE XM-L (XM-L2 T6) LED for a maximum output of

up to 750 lumens

· Second generation of ‘Crystal Coating Technology’ along with ‘Precision

Digital Optics Technology’ provide extreme reflector performance

· Boasts a peak beam intensity of 6,000cd and a throw distance of up to

155 meters (ANSI FL1)

· High efficiency circuit board provides up to 450 hours runtime on lowest

output level

· Equipped with unique multi-colored (red and blue) tactical / signaling

lights

· Infinite brightness adjustment from 0.1 to 750 lumens

· Six rapidly switchable functions to select from

· Reverse polarity protection

· Stainless steel titanium-plated two-way clip

· Stainless steel retaining ring protects core components from damage

· Toughened ultra-clear mineral glass with anti-reflective coating

· Constructed from aero grade aluminum alloy

· Robust HAIII military grade hard-anodized

· Waterproof in accordance with IPX-8 (two meters submersible)

· Impact resistant to 1.5 meters

· Tail stand capability

Dimensions

Length: 136mm (5.35”)

Head diameter: 25.4mm (1”)

Tube diameter: 24.3mm (0.96”)

Weight: 77g (2.72oz)(without battery)

Accessories

Quality holster, removable clip, lanyard, spare tail cap button and spare

O-ring

Battery Options

NOTE:

1. Ensure batteries are inserted with the positive (+) end pointing to the

head. The SRT5 will not operate with incorrectly inserted batteries.

2. Please do NOT light directly to the eyes, which will hurt the eyes.

Switching ON/OFF

To switch ON: Press the button on the tailcap until a “click” is heard.

To switch OFF: Press the button on the tailcap a second time until a

“click” is heard.

Momentary Illumination

Momentary illumination can be achieved by switching the flashlight off

and then half pressing and holding the tail switch. Release switch to turn

the light off.

Adjusting Output

With the light turned on, slowly rotate the Smart Selector Ring (adjacent

to the bezel) in a counter-clockwise direction to cycle through the

following brightness levels: beacon -> SOS -> police warning signal ->

blue mode -> red mode -> lower mode -> infinite brightness modes ->

turbo mode -> strobe mode. These modes may be cycled through in

reverse by rotating the Smart Selector Ring in a clockwise direction.

Thanks for purchasing NITECORE!

ALL-ROUND Flashlight Expert

NITECORE (SYSMAX) is a member of PLATO, participating in and

helping to develop the ANSI/NEMA FL1 standard of measurement.

Product testing data is in accordance with these internationally

recognized scientific standards.

NOTICE

The above data has been measured in

accordance with the international

flashlight testing standards

ANSI/NEMA FL1 using one x 3.7V

2600mAh Nitecore 18650 battery and

2 x 3V 1550mAh Nitecore CR123

batteries under laboratory conditions.

The data may vary slightly during

real-world use due to battery type,

individual usage habits and

environmental factors.

Infinite brightness adjustment varies

from 0.1 to 750 lumens and is

manually adjusted by rotation of the

Smart Selector Ring. Subsequently,

runtimes will vary anywhere from 105

minutes to 450 hours depending on

chosen level of output.

Battery Installation

Insert one 18650 battery or two CR123 batteries with the positive pole

pointing forward (toward the light head).

SIZE

Nominal voltage

Compatible

Primary Lithium battery CR123 3V Y (Recommended)

18650 Rechargeable Li-ion battery 18650 3.7V Y (Recommended)

Rechargeable Li-ion battery RCR123 3.7V Y

Output & Runtime

TURBO

LUMENS

750*

min

LOWER

LUMENS

0.1*

450

360

155m (Beam Distance)

6000cd

(Peak Beam Intensity)

IPX-8, 2m

(Waterproof

AND Submersible)

1.5m

(Impact Resistant)

2×CR1231×18650

SYSMAX Industry Co., Ltd.

TEL: +86-20-83862000

FAX: +86-20-83882723

E-mail: info@nitecore.com

Web: www.nitecore.com

Address： Rm1407-08, Glorious Tower, 850 East Dongfeng Road,

Guangzhou, China 510600

Warranty Service

All NITECORE® products are warranted for quality. DOA / defective

products can be exchanged for replacement through a local

distributor/dealer within the 14 days of purchase. After 14 days, all

defective / malfunctioning NITECORE® products will be repaired free of

charge for a period of 18 months from the date of purchase. After 18

months, a limited warranty applies, covering the cost of labor and

maintenance, but not the cost of accessories or replacement parts. The

warranty is nullified in all of the following situations:

1. The product(s) is/are broken down, reconstructed and/or modified by

unauthorized parties.

2. The product(s) is/are damaged through improper use.

3. The product(s) is/are damaged by leakage of batteries.

To guarantee a swift and effective customer service, Nitecore suggest

you to contact the point of purchase for assistance.

For the latest information on NITECORE® products and services, please

contact your national NITECORE® distributor or send an email to

service@nitecore.com

The Nitecore official website shall prevail in case of any product data

changes.

Please follow our facebook for more info: NITECORE Flashlights

ALL-ROUND Flashlight Expert

Note: When using the SRT5 in infinite brightness mode, runtime will

increase when lower levels of output are selected. On its lowest setting,

the SRT5 will run continuously for up to 450 hours and on its highest

setting continuously for up to one hour and 45 minutes.

NB:

For user safety and to prevent overheating / failure, the SRT5 will

automatically switch to high mode after three minutes of use in Turbo

mode. Slowly rotate the Smart Selector Ring or press the tail switch again

to reactivate turbo mode when needed.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a

thin coating of silicon-based lubricant.

Thanks for purchasing NITECORE!
